F-150EX-09 Installation Guide
Ford 150 Extra Cab 2009 - 2015
(Loaded/Amplified)
STEP 1:
Flip up the passenger side rear seat and place the
enclosure on the floor as shown above.
STEP 3:
From the driver side, attach the second bracket to the
enclosure as shown. Use the same screws from Step 2.
STEP 2:
Attach the mounting bracket to the enclosure as shown
using (2) 2" screws to attach the bracket to the floor, and (1)
M6 bolt to attach the bracket to the enclosure.
STEP 4:
Make all final wire connections (See Page 2) and fold the
seat down. Your installation is complete. Enjoy your new
bass in a small space.
