Connecting To A Mono Monitor Jack - Crate Studio Module SM5-HP User Manual

SM5-HP
Applications:
Connecting to a
Mono Monitor Jack:
Connect the Monitor
output jack of a mix-
ing board (or other
source) to the
Right/Mono jack of
the SM5-HP using a
shielded mono (T/S)
1/4" signal cable. The
signal at the head-
phones will be mono,
with the same signal
on both sides of the
phones.
Five Channel Headphone Amplifier
