  • Page 1 Page 2-17 Installation Manual IP Access Control Device Fingerprint A1122 Series Seite 18-33 Installationsanleitung IP Zutrittskontrollgerät Fingerprint A1122 Serie Page 34-49 Manuel d‘installation Système de contrôle d‘accès IP Fingerprint Série A1122 Páginas 50-65 Manual de instalación Sistema de control de acceso IP Fingerprint...
  • Page 2 Failure to observe this You can always find the most up-to-date version of the regulation could result in the risk of serious installation manual on www.doorbird.com/support damage to health or fatal injury due to electric shocks. To make things easier we use the term “device” for the product “IP Access Control Device A1122”...
  • Page 3 ̵ Places subject to dust, oil, chemicals, hydrogen WARNING sulfide (hot spring). ̵ Places subject to moisture and humidity • Do not install or make any wire terminations extremes, such as bathrooms, cellars, while power supply is plugged in. It can cause greenhouses, etc.
  • Page 4 • Use only accessories that comply with this service due to any other causes outside of technical specification of the device. These can our responsibility; or if an error or missing data be provided by Bird Home Automation GmbH. occurs during transmission. •...
  • Page 5 Transportation When transporting the device, use the original NOTICE packaging or equivalent to prevent damage to the device. Warranty Information For information about the device warranty, see www.doorbird.com/warranty...
  • Page 6 7) Screw connection terminal 3) Bluetooth transceiver 8) SETUP Button (SET) of the device to e.g. 4) Status icons with Diagnostic LEDs configure the WiFi interface of the device using 5) Security screw the DoorBird App The flush-mounted model may differ optically.

  • Page 7: Installation

    Need help with the installation? Be sure to watch our installation videos which can be found on Switch off the power to all wires leading to http://www.doorbird.com/support the assembly location, e.g. power supply for the device or an electrical door opener.

  • Page 8: Disassembling The Front Panel

    ASSEMBLING THE MOUNTING HOUSING The product is available as a surface-mounted and flush-mounted version. In the flush-mounted version, the front panel is slightly larger to better cover the hole in the wall, and the mounting housing (backbox) is made entirely of metal instead of plastic. Flush-mounted model 138,00 mm 5.43 in...

  • Page 9: Network Connection Options

    If you have only two wires available at Network cable (recommended, maintenance free) the assembly location, you may use the “DoorBird 2-Wire Ethernet PoE Converter Install a network cable (which is plugged into a network switch / router A1071”, sold separately. It allows you to...

  • Page 10: Prepare Power Supply

    To power the device via a PoE-Switch (e.g. D-Link DGS-1008P) or PoE- the data throughput or the stability of Injector (e.g. DoorBird Gigabit PoE Injector A1093), use a CAT.5 cable or the network connection and power sup- higher in accordance with the PoE standard IEEE 802.3af Mode A.

  • Page 11: Connecting The Device

    OPTION 3 Power supply using a DIN rail power supply unit Alternatively to the mains adapter, we offer DIN rail power supplies in our online shop, which can be installed by a specialist. The network connection is then made via a network cable or alternatively via WiFi. CONNECTING THE DEVICE It is possible to connect the cables and wires to the device conveniently and safely via the labeled screw connection terminal.
  • Page 12 You can configure the default state of the relay (open/close) via the DoorBird App. These ports can be used to connect e.g. an electric door opener. The device does not supply power to the connected device.

  • Page 13: Activate The Device

    Please take care when connecting the cables and wires. Connecting the cables and wires the wrong way NOT IC E may damage the device. Wires without insolation material must not protrude out of the green screw connection terminal, it may lead to electrical short and damage the device. ASSEMBLE THE DEVICE TO THE MOUNTNG HOUSING (BACKBOX) If you use the surface- or flush-mounted version, assemble the front panel with the attached Main Eletrical Unit carefully using the orange (Torx+Pin) screw driver provided with the wall mounting-bracket / mounting...

  • Page 14: Downloading And Installing The App

    If you use WiFi for connecting the device to your Internet Router, first go to the DoorBird App > ”WiFi • If a previously registered finger is not recognized, Setup“ and follow the instructions.

  • Page 15: Diagnostic-Led

    MAINTENANCE FOR DOORBIRD PRODUCTS Cleaning and maintenance instructions Fingerprint LED All DoorBird door stations are made of high-quality materials and are designed for a durable lifetime. Since door stations are usually installed in unprotected outdoor areas, they are exposed to adverse weather...
  • Page 16 After the cleaning with clear water wipe with damp cloth and rub dry to avoid lime traces. Lime residues can be avoided by using demineralised water. Stainless steel PVD coated PVD coated, chrome-plated or gold-plated surfaces are recommended to be cleaned with a grease- dissolving detergent and clear water or with a clean and dust-free microfibre cloth.

  • Page 17: Legal Notes

    General remarks updates cannot be undone. Since the products and software of Bird Home Automation GmbH are not explicitly customer-specific 1. DoorBird is a registered trademark of Bird Home Automation products, a customer cannot deny an automatic update if the GmbH.
  • Page 18 FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 19 IC Caution: This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. To maintain compliance with RF exposure guidelines, this equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body.
