- Page 1 Confidence and control. INSTRUCTION MANUAL SEMI VERTICAL DISPLAYS 3335639-NR, 3335640-NR, 3335641-NR, 3335642-NR, 3335643-NR, 3335644-NR, 3335645-NR, 3335646-NR, 3335647-NR, 3335648-NR. REVISION 2 | 7/08/2023...
-
Page 3: Table Of Contents
CONTENTS 1. PREFIX 2. IMPORTANT NOTES & WARNINGS 3. PACKAGING AND HANDLING 4. PRODUCT OVERVIEW 5. INSTALLATION 6. OPERATION 7. PRODUCT LOADING AND STORAGE 8. MAINTENANCE 9. TROUBLESHOOTING 10. MULTIPLEXING PROCEDURE 11. ALTERNATE CONFIGURATIONS 12. ENVIRONMENTAL AND DISPOSAL NOTES 13. WARRANTY Note: Bromic Refrigeration reserves the right to make changes to specifications, parts, components and equipment without prior notification. -
Page 4: Prefix
1. PREFIX This manual contains important information about the installation, operation, and maintenance of Bromic Semi Vertical Display units. Please pay close attention to the important safety information shown throughout this instruction manual. Any safety information will be accompanied by the following safety alert symbols: DANGER, WARNING, IMPORTANT... -
Page 5: Important Notes & Warnings
2. IMPORTANT NOTES AND WARNINGS • Read all instructions before installing or using this appliance • Retain this manual for future reference • Use this appliance only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock or injury. •... -
Page 6: Packaging And Handling
3. PACKAGING AND HANDLING • This Semi Vertical display contains fragile glass. The unit must always be handled with care. • Adjust the width of forklift tines such that they line up with the structural supports on the Semi Vertical unit before lifting. •... -
Page 7: Product Overview
4. PRODUCT OVERVIEW SVM1000HD-NR SVM1250HD-NR SVM1580HD-NR SVM1875HD-NR SVM2500HD-NR Part Number 3335639-NR 3335640-NR 3335643-NR 3335641-NR 3335642-NR Height, mm 1500 1500 1500 1500 1500 External Width, mm 1022 1334 1580 1959 2584 Dimension Depth, mm Volume Litres Weight Air Circulation Type Fan Forced... - Page 8 SVM1000SD-NR SVM1250SD-NR SVM1580SD-NR SVM1875SD-NR SVM2500SD-NR Part Number 3335639-NR 3335640-NR 3335643-NR 3335641-NR 3335642-NR Height, mm 1500 1500 1500 1500 1500 External Width, mm 1022 1334 1580 1959 2584 Dimension Depth, mm Volume Litres Weight Air Circulation Type Fan Forced Fan Forced Fan Forced Fan Forced Fan Forced...
-
Page 9: Installation
5. INSTALLATION Locating the Cabinet Ensure the following instructions are observed as this is vital for proper and trouble-free operation. • Do not install the cabinet outdoors. • Locate the appliance in a dry and well ventilated place. • The unit must be positioned on a level surface. •... - Page 10 Power Supply • The appliance must not be plugged into a multiple outlet power board. • The appliance is supplied with a flexible power cord fitted with a 3-pin plug. • The socket used must be properly earthed and fuse/RCD protected. •...
-
Page 11: Operation
6. OPERATION Start-up • Connect the appliance to the mains power supply. • The switches (image below) control cabinet cooling, defrost, and lights respectively. Flip all switches on for cabinet operation. • The compressor and condenser fan should operate should operate within 3 minutes after the Refrigeration switch is turned on. -
Page 12: Product Loading And Storage
7. PRODUCT LOADING AND STORAGE IMPORTANT: Run the refrigerator for at least 2 hours before loading. WARNING: : Do not store explosive substances such as aerosol cans with a flammable propellant inside the appliance. Start-up • Clean the interior surface with a soft cloth and warm water before loading. •... - Page 13 General cleaning • The Semi-Vertical display must be wiped down regularly. • Preventing the build-up of oil and sediments will increase the longevity of the unit. Condenser cleaning • A clogged condenser can result reduced cooling performance. • The condenser must be cleaned every 6 weeks. •...
-
Page 14: Troubleshooting
9. TROUBLESHOOTING IMPORTANT: Repairs on the unit must be carried out by an authorised and licensed person only. Contact the manufacturer or an approved service agent for any repairs needed. Symptom Possible Cause(s) Solution Cabinet does not A. No power supply A. -
Page 15: Multiplexing Procedure
10. MULTIPLEXING PROCEDURE The multiplexing procedure can be used to connect multiple Bromic Semi Vertical units together. • A Bromic multiplexing kit must be used for this procedure. • The multiplexing procedure must be performed a licensed technician. Comet PL MULTIPLEXING (CABINET) Drawings Parts... -
Page 16: Alternate Configurations
11. ALTERNATE CONFIGURATIONS The Bromic Semi Vertical cabinet is available in alternate configurations upon special order. Contact your local Bromic sales representative for detailed information. Default Configuration Alternate Configuration Depth options Thin version (790mm depth) Wide version (930mm depth) Door options Hinged doors Sliding doors Open-front (no doors) -
Page 17: Environmental And Disposal Notes
12. ENVIRONMENTAL AND DISPOSAL NOTES These refrigerated cabinets are designed to high standards of environmental protection and recycling convenience. Cyclopentane, an environmentally friendly foaming agent, has been used. Cyclopentane is distinguished by zero ozone depletion potential (ODP) and zero global warming potential (GWP). The refrigerant used and contained within a hermetically tight circuit is environmentally friendly and does not contain chlorine and zero ODP. -
Page 18: Warranty
13. WARRANTY All Bromic products are manufactured to the highest quality standard and are supported by our Extra Care Service Warranty, including guarantees against any material or workmanship defects; guarantees that cannot be excluded under Australian Consumer Law. Warranty Terms vary across the range. Please ensure you are familiar with the Terms and Conditions that apply to the purchase of your Bromic product by referring to the Warranty Policy included with your purchased product. - Page 19 HOW TO PLACE A SERVICE REQUEST • Please call 1300 276 642 to place a warranty service request and let the operator know whether you need Priority A or B service. More information can be found below. • Ensure you have the serial number of your product ready before contacting us. •...
- Page 20 BROMIC REFRIGERATION 10 Phiney Place, Ingleburn (Sydney) NSW 2565 Australia T. 1300 276 642 For further product information bromicrefrigeration.com.au...
