Antelope Pico Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating Guide
Version 7/25/2019
Antelope Pico HD Camera
© 2019 Antelope Camera Systems

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pico and is the answer not in the manual?

Questions and answers

Related Manuals for Antelope Pico

Summary of Contents for Antelope Pico

  • Page 1 Operating Guide Version 7/25/2019 Antelope Pico HD Camera © 2019 Antelope Camera Systems...
  • Page 2 Operating Guide Version 7/25/2019 © 2019 Antelope Camera Systems All rights reserved. No parts of this work may be reproduced in any form or by any means - graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the written permission of the publisher.

  • Page 3: Table Of Contents

    Contents Table of Contents Foreword Part I Important Safety Instructions Part II Antelope Pico Camera 1 Introduction ........................... 12 2 Pico Camera Interfaces ........................... 13 Back - Pico Camera Head ................................13 3 Pico Camera Connection Chart ........................... 14 4 Setup Procedure ...........................
  • Page 4 4 Overview ........................... 66 5 RCP Display ........................... 67 Memory Capacity Indicator ................................67 Loop Mode Indicator ................................67 Autoplay Mode Indicator ................................67 In / Out Point ................................68 Current Frame ................................68 Timeline ................................68 Antelope Camera Systems...
  • Page 5 ................................81 IP Setup ................................82 USB Firmware Update ................................83 Part VI Connectors 1 Pico Camera Head Connectors ........................... 86 Camera Iris Motor Connector - Hirose 6pin f ................................86 Camera Focus Motor Connector - Hirose 6pin f ................................86 Iris Motor Connector - Hirose 6pin f ................................
  • Page 6 Power Connector 4Pin XLR Male ................................92 LAN Remote Control Port – CAT5 - RJ45 ................................92 Data RS 422 – CAT5 RJ45 ................................92 USB Firmware Update Port ................................92 Part VII Limited Warranties Part VIII Contact Index Antelope Camera Systems...

  • Page 7: Foreword

    High speed is also the strength of our cameras providing speeds of up to 5000 fps. Like the Antelope, being a sentinel and always on guard, our high speed cameras record permanently into ring buffer and provide, with a push of the post trigger button, slow-motion live playback.
  • Page 9 Part...

  • Page 10: Part I Important Safety Instructions

    Operating Guide Important Safety Instructions In these safety instructions the word 'apparatus' refers to the Antelope Pico camera, the Antelope Compact MKII camera, the Colibri Defilcker and the Cobra Link System and an its accessories, including OCP and RCP. 1. Read and understand these instructions.
  • Page 11 Part...

  • Page 12: Part Ii Antelope Pico Camera

    The Antelope PICO records with up to 525 frames per second in native HD. The system is based on a 2/3" CMOS 2K image sensor and guarantees high detail and unsurpassed light sensitivity.

  • Page 13: Pico Camera Interfaces

    Antelope Pico Camera Pico Camera Interfaces 2.2.1 Back - Pico Camera Head 1. Connector I 2. Connector II 3. Connector III 4. Camera Iris Motor Connector 5. Camera Focus Motor Connector 6. Iris Motor Connector 7. Focus Motor Connector Antelope Camera Systems...

  • Page 14: Pico Camera Connection Chart

    Operating Guide Pico Camera Connection Chart Antelope Camera Systems...

  • Page 15: Setup Procedure

    Antelope Pico Camera Setup Procedure 1. Connect the multi colored COAXPress cables to the camera head and the CCU according to the connector numbering and color. Make sure you connect the camera head connector I to connector I/R on the CCU, camera head connector II to connector II/G and connector III to connector III/B on the CCU.

  • Page 16: Specifications

    Power Requirements 15-18 VDC Power Consumption Max 15W Operating Temperature -20 – 40°C Dimensions Camera Head 176 x 40 x 44mm Dimensions CCU 288 x 222 x 89mm Weight Antelope Pico Camera Head 380g Weight CCU 1200g Antelope Camera Systems...
  • Page 17 Part...

  • Page 18: Part Iii Ccu (Camera Control Unit)

    26. HDSDI Slow-Motion Replay Output 1 27. HDSDI Slow-Motion Replay Output 2 28. HS-Link Connection to Camera Head I-RED 29. HS-Link Connection to Camera Head II-BLUE 30. HS-Link Connection to Camera Head III-GREEN 31. Genlock Interface Output Antelope Camera Systems...

  • Page 19: Back - Ccu Interfaces

    Back - CCU Interfaces 40. USB Mini Service Port – For major updates only! 41. Power Indicator LED 42. CCU Status Indicator LED 43. Deflicker Status Indicator LED 44. CCU Touchscreen 45. USB Firmware Update Port 46. On/Off Switch Antelope Camera Systems...

  • Page 20: Touchscreen Ccu

    NOTE: The port addresses of the other connected controllers must be set to the values shown here in the display. USB Firmware Update Antelope Camera System provides firmware updates for its devices to help address any known issues and to add new features. Update the CCU firmware using a USB flash drive: USB memory device requirements: - USB specification 2.0 (or higher) and should not have more in capacity than 4GB.

  • Page 21: Baudrate Setup

    RCP 725 SLAVE ROP 735 D/C 7. Remove the USB flash drive. NOTE: If you have any difficulty carrying out these instructions, please contact Antelope Camera System. Baudrate Setup It is possible to change the data rate in bits per second (baud) for serial data transmission between the control units.

  • Page 22: Ip Setup

    Press ADD next to the IP address to change the IP of the CCU. To enter the new IP address use the on screen keyboard on the bottom on the screen. Use the back button to navigate back and the C button to clear your entry. The mask and gateway settings can be changed accordingly. Antelope Camera Systems...
  • Page 23 Part...

  • Page 24: Part Iv Operational Control Panel (Ocp)

    Operating Guide Operational Control Panel (OCP) The Antelope Operational Control Panel is designed to give instant access to all functions with regards to image processing. It is compatible with the Antelope Pico and Compact cameras. Back - OCP Interfaces 50. Power In Connector (12V) 51.

  • Page 25: Overview

    L. Black Stretch / Flare Button M. White Balance Button N. Gamma Adjustment Button O. User Matrix / Scene Files Button P. X-10 Steps Button Q. Selecting Dial R. Iris Dial / Minimotor Adjust Dial S. OCP Display Antelope Camera Systems...

  • Page 26: Ocp Display

    This feature is very useful to keep settings for different light situations or operating environments. There are additionally four Scene File memory slots available. They allow to store the actual camera setup (values of all settings). This feature is very useful to keep custom settings for different operating environments. Antelope Camera Systems...

  • Page 27: Scene File Settings Menu

    CHOOSE OPTION LOAD <= SAVE DELETE Once you choose a menu item use the Select dial (Q) to select. Selecting MULTIMATRIX PRESETS enters the Multi Matrix Correction Presets (MCC) menu Antelope Camera Systems...

  • Page 28: Multi Matrix Correction Presets (Mcc) Menu

    To delete all the settings for the selected memory slot, just press and hold the Select dial (Q). CONFIRM DELETE Presets => NO By turning the Select dial (Q) you select YES or NO. Confirm your choice by pressing the Select dial (Q) once. Antelope Camera Systems...

  • Page 29: Cam Select

    Allows you to adjust the RGB colors per channel. Red Gain Values range from -500-500 Green Gain Values range from -500-500 Blue Gain Values range from -500-500 Red Pedestal Values range from -500-500 Green Pedestal Values range from -500-500 Blue Pedestal Values range from -500-500 Antelope Camera Systems...

  • Page 30: Iris Button / Motor Control

    Reverse - Allows to change the rotation direction of the applied zoom motor. Values are on/off. Speed - This parameter defines the speed of the zoom motor. Values are 0.1-3.0 Ref.-Calibrate Zoom - Use to calibrate the zoom motor to the actual lens Antelope Camera Systems...
  • Page 31 Note! If Reference (REF.) indicates TODO, you have to calibrate the respective motor : This is done by Selecting REF. with the Select Dial (Q). Then start the calibration by pressing the Select Dial (Q). After the calibration is finished correctly, the display switches from TODO to Done. Antelope Camera Systems...

  • Page 32: Global Menu

    Select dial (Q) you change the settings. Confirm your settings by pressing the Select dial (Q) once. Format Values are 1080i 50 1080i 60 1080i/59.94 1080p 23.98 1080p 24 1080p 25 1080p 29.97 1080p 30 1080p 50 1080p 59 1080p 60 720p 50 720p 59.94 720p 60 Antelope Camera Systems...

  • Page 33: Video Level

    Tri-Level - Tri-Level Sync Crosslock - Crosslock Sync - Make sure you set the right crosslog video format in the Crosslog Signal menu Pal BB - Black Burst PAL Standard NTSC BB - Black Burst NTSC Standard Antelope Camera Systems...

  • Page 34: Crosslog Sig

    For example, the hue and saturation of a shirts red petal can be changed, while keeping other colors unchanged. In addition to such special effects work, this function is also useful for matching color among multiple cameras, or for reproducing the color characteristics of another camera Antelope Camera Systems...

  • Page 35: Status

    SAT:1.00 HUE:0.0 SAT:1.00 HUE:0.0 SAT:1.00 HUE:0.0 SAT:1.00 HUE:0.0 SAT:1.00 HUE:0.0 SAT:1.00 HUE:0.0 SAT:1.00 HUE:0.0 SAT:1.00 HUE:0.0 R/YL SAT:1.00 HUE:0.0 SAT:1.00 HUE:0.0 Color abbreviations: Blue, B+, B++ blue MG-, MG, MG+ magenta R-, R, R+ R/YL, YL- yellow Antelope Camera Systems...

  • Page 36: Multimatrix

    The default function returns all Multi Matrix values to their defaults. Select YES or NO with Select dial (Q). The arrow indicates the active item. By turning the Select dial (Q) you change the settings, then press the Select dial (Q) once. CONFIRM LOAD DEFAULT DEFAULT: =>YES Antelope Camera Systems...

  • Page 37: Black Sun

    Select YES or NO with Select dial (Q). The arrow indicates the active item. By turning the Select dial (Q) you change the settings, then press the Select dial (Q) once. CONFIRM REBOOT CAMERA: =>YES The process to reset the camera will take approximately 20 seconds. Antelope Camera Systems...

  • Page 38: Sleep Mode

    Press the Menu Dial (E) once to stop the sleep mode. 4.10.8 Reset to Factory Defaults The reset to factory defaults function resets the Antelope PICO back to its manufacturer default settings. . Select YES or NO with Select dial (Q). The arrow indicates the active item. By turning the Select dial (Q) you change the settings, then press the Select dial (Q) once.

  • Page 39: System Info

    00000000 xx xxx-xx software release id: 000000:000000 00 0000 00 Controllers Displays the hardware and firmware info about the connected controllers, like RCP, OCP, Splitter and Motors. OCP: v.3.98 RCP: v.3.89 Splitter: v.3,91 M. Box: v.3.91 Antelope Camera Systems...

  • Page 40: Frame Rate And Exposure Menu

    Full Frame (25psf) - full slow motion playback at "normal" speed Full Frame EXT (extended) - plays out video sequence at half speed By choosing the Full Frame EXT setting it is possible to simulate a virtual slow motion playback at up to 700fps. Antelope Camera Systems...

  • Page 41: Gain/Hue Menu

    Increasing the black stretch brings out details and better definition in the shadows, but keeps the absolute black to stay black. Adding some black stretch helps also to lift dark areas up in order to put off possible noise in the black. Values range from -20 -+127 Antelope Camera Systems...

  • Page 42: Flare

    Values are 0-100% Flare RED - Anti-Flare feature compensates for red flares Values are 0-100% Flare Green - Anti-Flare feature compensates for green flares Values are 0-100% Flare Blue - Anti-Flare feature compensates for blue flares Values are 0-100% Antelope Camera Systems...

  • Page 43: Automatic White Balance Button

    Select the Custom menu item by turning the Select dial (Q), then press the Select dial (Q) once. By turning the Select dial (Q) you change the settings. Confirm your settings by pressing the Select dial (Q) once. Antelope Camera Systems...

  • Page 44: Detail / Denoise Menu

    Select dial (Q) once. Deflicker Menu Settings Strength - sets the degree of the deflicker effect Values range from 0-12 The higher this value is set, the less flicker is visible and the cleaner the processed image looks. Antelope Camera Systems...
  • Page 45 If you have a scene with special lights and there are only poor results, please do not hesitate to contact us and send us a sample clip and we will improve our algorithm. Note! When working daylight conditions with no artificial light the deflicker engine must be disabled! Antelope Camera Systems...

  • Page 46: Gamma Presets Button

    The knee helps to prevent over-exposure by limiting signals in high intensity areas of the subject to the dynamic range of your camera. Values are off - Knee function switched off on - Knee function switched on Knee Point Sets the position of the knee point output level. Antelope Camera Systems...

  • Page 47: Preview Button

    CHOOSE OPTION LOAD <= SAVE DELETE Once you choose a menu item use the Select dial (Q) to select. 4.18 Preview Button Pressing the Preview Button (K) provides live camera signal on the reference monitor. Antelope Camera Systems...

  • Page 48: Saturation And Master Black Function

    Press the Master Black Dial (J) once and adjust the master black setting by turning the Master Black Dial (J) . Values range from -2047 - +2048 Please note! While being in the motor menu the Master Black Dial (J) adjusts the focus. Antelope Camera Systems...

  • Page 49: Usb Firmware Update

    Operational Control Panel (OCP) 4.20 USB Firmware Update Antelope Camera System provides firmware updates for its devices to help address any known issues and to add new features. Update the OCP firmware using a USB flash drive: USB memory device requirements: - USB specification 2.0 (or higher) and should not have more in capacity than 4GB.

  • Page 50: Ip Setup

    It is necessary to reboot the OCP in order for new settings to take effect. This can be done by selecting and pressing REBOOT on the bottom right of the menu. Note! The port address is factory set to 715 and should always match the values indicated in the CCU touchscreen display (44). Antelope Camera Systems...

  • Page 51: Engineer Menu

    Mode Values are Encoder - choose this setting for fixed focal lenses without integrated motors Freerun - choose this setting for motors without encoder (e.g. Fishface) DC - choose this setting for zoom lenses with integrated motors Antelope Camera Systems...
  • Page 52 (connected to CCU). Values are Note! If no motor is attached the Zoom Ct. Loc. is - NO - DC Zoom Rel Here you select how the connected external hand rocker operates. Values are Absolute Antelope Camera Systems...

  • Page 53: Expert Deflicker Menu

    1080p 25 1080p 29.97 1080p 30 1080p 50 1080p 60 720p 50 720p 59.94 720p 60 Freq. Shift - Allows to fine tune the deflicker signal processing results. Values range from -233 - +517 (Recommended value is 0) Antelope Camera Systems...

  • Page 54: Matrix

    TFLT is an enhanced denoise filter to reduce the very disturbing line flicker, that occurs in rare cases. TFLT LIVE - reduces the line flicker in the live output Values are ON / OFF Note! It is recommended to keep this setting always off. Antelope Camera Systems...

  • Page 55: Tflt Replay

    Values are ON / OFF Note! This setting should be always ON. Since each sensor receives its own individual noise pattern file, which is stored in the CCU, it is not possible to mix different camera heads and CCUs. Antelope Camera Systems...

  • Page 56: Cam Eng Reset

    The OCP displays DEEP RESET COMPLETE and returns to the menu again after the reset is finished. Note! After performing a deep reset, make sure you switch the Fixed Pattern on again. Also check the Playmode and Multimatrix settings! Antelope Camera Systems...

  • Page 57: Gamma Adv

    Choose RESET to reset all changed values or INTERPOLATE to apply all changes made in this menu. This calculates the new look up tables (LUTs) for the changed parameters. Note! - This has always to be done to apply the samples point changes! Antelope Camera Systems...

  • Page 58: Mem Test

    MEM TEST <= SUCCESS MEM TEST <= FAIL The display should show SUCCESS. FAIL indicates a defective EEPROM module. Note! In case this test indicates FAIL, get in touch with Antelope Camera System GmbH have your unit serviced. Antelope Camera Systems...

  • Page 59: Ocp Menu Overview

    [0% - 100%] BIT DEPTH [8,10] PLAY MODE [interlaced, full frame psf, fullframe extended] GAIN/HUE GAIN [0db - 24db] [-128 - 127] BL. STRETCH/FLARE B. STRETCH [-20 - 127] FLARE RGB [0% - 100%] FLARE RED [0% - 100%] Antelope Camera Systems...
  • Page 60 2 SCENE FILE 3 loads user preset 3 SCENE FILE 4 loads user preset 4 MULTIMATRIX PRESETS NO MATRIX no MM preset SONY MATRIX Sony MM preset GRASS VALLEY MATR. Grass MM preset PANASONIC Panasonic MM preset Antelope Camera Systems...
  • Page 61 [Encoder, FREE RUN, DC] IRIS SPEED [0%-100%] IRIS CT. LOC [CCU, OCP] FOCUS SPEED [0%-100%] FOC. CT. LOC [CCU, OCP] ZOOM SPEED [0%-100%] ZOOM CT. LOC [CCU, OCP] DC ZOOM REL [ABSOLUTE, RELATIVE] MATRIX [-512 - 512] [-512 - 512] Antelope Camera Systems...
  • Page 62 D/C CHECK [ON, OFF] FIXED PATTERN [ON, OFF] CAM ENG RESET deep reset - loads eng factory defaults GAMMA ADV opens 24 point gamma interpolation MEM TEST check EEPROM --> success if ok --> fail if not ok Antelope Camera Systems...

  • Page 63: Part V Remote Control Panel (Rcp)

    Part...

  • Page 64: Important Note

    - go back to the operating menu by pressing the Menue Dial (D) twice Back - RCP Interfaces 60. Power In Connector (12V-18V) 61. Data LAN Remote Control Port (to OCP) 62. RS-422 Remote Control Port (to CCU) 63. USB Firmware Update Port (upper USB Port) Antelope Camera Systems...

  • Page 65: Front - Rcp Interfaces

    Remote Control Panel (RCP) Front - RCP Interfaces 63. USB Firmware Update Port (upper USB Port) Antelope Camera Systems...

  • Page 66: Overview

    Operating Guide Overview The Antelope Remote Control Panel (RCP) is designed to give instant access to all functions with regards to video recording and fast access slow-motion back. It is compatible with the Antelope Pico and Compact Mark II cameras.

  • Page 67: Rcp Display

    If the Loop Mode Indicator (T) is displayed with a red background it indicates that Loop Mode is switched on. 5.5.3 Autoplay Mode Indicator The Autoplay Mode Indicator (S) displays the loop mode status. If the Autoplay Mode Indicator (S) is displayed with a transparent background it indicates that Loop Mode is switched off. Antelope Camera Systems...

  • Page 68: In / Out Point

    Pre-Trigger mode (Pre-Trigger Indicator (U)). The remaining recording time (in Seconds) after pushing the Trigger Button (E) is indicated above the timeline (R) behind the letters PTR. It counts down the remaining recording time until this clip is saved and available for playback. Antelope Camera Systems...

  • Page 69: Jog Dial

    By turning the Select dial (K) you can change the settings. Confirm your changed settings by pressing the Select dial (K) once FPS <= 350 PLAY MODE : F:AUTO DEL.: REBOOT... D/C CHECK BIT DEPTH Antelope Camera Systems...

  • Page 70: Add Auto Del

    Select YES or NO with Select dial (K). The arrow indicates the active item. By turning the Select dial (K) you change the settings, then press the Select dial (K) once. CONFIRM REBOOT CAMERA: =>YES The process to reset the camera will take approximately 20 seconds. Antelope Camera Systems...

  • Page 71: Bit Depth

    Select dial (K) you change the settings. Confirm your settings by pressing the Select dial (K) once. Play Mode Values are Interlaced (50i) Full Frame (25psf) Full Frame EXT (extended) - plays out video sequence in half speed Antelope Camera Systems...

  • Page 72: Workflow Setup

    ON the replay starts immediately after triggering. Values are On / Off Select On or OfFf with Select dial (K). The arrow indicates the active item. By turning the Select dial (K) you change the settings, then press the Select dial (K) once. Antelope Camera Systems...

  • Page 73: Autoplay Starting Frame Setup

    Key 2 – Mark 1 Button (C) Key 3 – Goto 1 Button (I) Key 4 – Goto 2 Button (J) Please note! This Menu item is only available in Full Auto Mode and otherwise it is grayed out! Antelope Camera Systems...

  • Page 74: Sleep Mode

    Antelope Camera Systems recommends to use this option, when the mounted cameras will not be in use for more than one hour.

  • Page 75: Jog Shuttle Speed Setup

    Select the respective item by turning the Select dial (K), then press the Select dial (K) once. The arrow indicates the active item. By turning the Select dial (K) you change the settings. Confirm your settings by pressing the Select dial (K) once. Values are 0-99 Antelope Camera Systems...

  • Page 76: Pre-Trigger Mode

    In this mode, when pushing the Trigger Button (E) 50% of the previous buffered video sequence (duration depends on the available capture time) in the actual memory bank are stored and an additional 50% will be recorded before this clip is then saved and available for playback. Antelope Camera Systems...
  • Page 77 Note! While recording a high-framerate sequence in Pre-Trigger mode you can shift the trigger point to a later trigger point by pushing the Trigger Button (E). With each push of the Trigger Button (E) the the trigger point is newly set. Antelope Camera Systems...

  • Page 78: Operating The Rcp

    Operating the RCP 5.8.1 Memory Bank The Antelope Pico has a user configurable number of memory partitions, they are referred to as “banks”, from 1 up to 4. These banks are represented in the top row of the display (N) by 4 squares (O).

  • Page 79: Trigger Recording

    This feature can only be used with one memory bank. Note! TheTrigger Button (E) is lit red while the camera is recording. Note! Banks which are in use and therefor have the status Play cannot be deleted! Antelope Camera Systems...

  • Page 80: Playback

    (by default the last frame of the bank). The In / Current / Out Indicator (O) displays the starting frame, the currently displayed frame and the end frame of the actual video clip. Antelope Camera Systems...

  • Page 81: Clear Bank / Lock Bank

    Note! Banks which are in use and therefor have the status Play cannot be deleted! Banks can be protected against erasure (locked) by simultaneously pushing the Clear Bank/Lock Bank button (M) and the corresponding Bank Number Button (A). Bank Number Button (A). Antelope Camera Systems...

  • Page 82: Ip Setup

    It is necessary to reboot the OCP in order for new settings to take effect. This can be done by selecting and pressing REBOOT on the bottom right of the menu. Note! The port address is factory set to 725 and should always match the values indicated in the CCU touchscreen display (44). Antelope Camera Systems...

  • Page 83: Usb Firmware Update

    Remote Control Panel (RCP) 5.8.10 USB Firmware Update Antelope Camera System provides firmware updates for its devices to help address any known issues and to add new features. Update the RCP firmware using a USB flash drive: USB memory device requirements: - USB specification 2.0 (or higher) and should not have more in capacity than 4GB.

  • Page 85: Part Vi Connectors

    Part...

  • Page 86: Pico Camera Head Connectors

    Operating Guide Connectors Pico Camera Head Connectors 6.1.1 Camera Iris Motor Connector - Hirose 6pin f Pin 1: M - Pin 2: M + Pin 3: E1 Pin 4: 5V Pin 5: GND Pin 6: 6.1.2 Camera Focus Motor Connector - Hirose 6pin f...

  • Page 87: Ccu Connectors

    Data RS 422 – CAT5 RJ45 Pin 1 RX(+) white/orange Pin 2 orange solid Pin 3 white/green stripe Pin 4 RX(-) blue solid Pin 5 TX(+) white/blue stripe Pin 6 green solid Pin 7 white/brown stripe Pin 8 TX(-) brown solid Antelope Camera Systems...

  • Page 88: Remote Control Port Ii - Hirose 10Pin F

    Pin 9: Mid Pot Focus Pin10: NC Pin11: GND Pin12: 3.3V 6.2.7 Motor Connector - Hirose 6pin f Pin 1: M - Pin 2: M + Pin 3: E1 Pin 4: 5V Pin 5: GND Pin 6: Antelope Camera Systems...

  • Page 89: I/O Connector - Hirose 5Pin F

    6.2.10 USB Firmware Update Port Pin 1: Vcc Pin 2: Data - Pin 3: Data + Pin 4: GND Pin 5: Housing Note! The USB-Port is a maintenance port only. This port is NOT used for general operation. Antelope Camera Systems...

  • Page 90: Ocp Connectors

    Pin 1: RX (+) or A Pin 2: RX (-) or B Pin 3: TX (+) or Y Pin 4: TX (-) or Z Pin 5: NC Pin 6: NC Pin 7: NC Pin 8: NC Pin 9: NC Pin10: NC Antelope Camera Systems...

  • Page 91: Tally / Preview Connector- Hirose 4Pin M

    USB Firmware Update Port Pin 1: Vcc Pin 2: Data - Pin 3: Data + Pin 4: GND Pin 5: Housing Note! The USB-Port is a maintenance port only. This port is NOT used for general operation. Antelope Camera Systems...

  • Page 92: Rcp Connectors

    USB Firmware Update Port Pin 1: Vcc Pin 2: Data - Pin 3: Data + Pin 4: GND Pin 5: Housing Note! The USB-Port is a maintenance port only. This port is NOT used for general operation. Antelope Camera Systems...
  • Page 93 Part...

  • Page 94: Part Vii Limited Warranties

    Operating Guide Limited Warranties Antelope Camera Systems GmbH (hereafter AntelopeCS) warrants this product free from defects in material and workmanship under the following terms. Labor and parts are warranted for two years from the date of the first customer purchase. Only the first purchase customer may enforce this warranty.
  • Page 95 This warranty gives you specific legal rights, and you may also have other rights, which vary from place to place. NOTE: All products returned to Antelope Camera Systems for service must have prior approval. This may be obtained from your dealer. This equipment complies the requirements of: EN-50081: "Electromagnetic compatibility (EMC);...
