Page 2
Member States on the liability for damages arising from defective products under art. 15 of Law no. 183 of 16 April 1987). Esse-ti reserves the right to modify the characteristics of the products at any time without prior notice.
TABLE OF CONTENTS GENERAL INSTRUCTIONS FOR THE INSTALLER ............4 General Notes........................4 Making the Installation.......................4 DESCRIPTION ........................6 INSTALLATION ........................7 Inserting the SIM card ........................8 Inserting the antenna ..........................9 Module connection..........................9...
• The product must be EXCLUSIVELY used for the purpose it was designed for. Esse-ti shall not be responsible for damages arising from improper use. • The product has been designed in compliance with the regulations in force and must be installed in system that comply with the provisions of law.
Page 5
installation connection telephone terminals telecommunications network that do not comply with the regulations in force is not permitted. Page 5...
• GSM Combi Board; • HelpyL200 Elevator alarm system. The GSM100 TL module can be used in conjunction with the folowing Esse-ti devices: • HelpyL200 TL Elevator alarm system. A normal SIM Card is required. This manual describes the GSM100 and GSM100 TL installation procedure.
INSTALLATION GSM100 NSTALLATION Unscrew the upper screw and remove the cover. ANTENNA CONNECTOR REGISTRATION LED SIM CARD HOUSING RJ45 for module connection Page 7...
GSM100 TL NSTALLATION Unscrew the upper screw and remove the cover. ANTENNA CONNECTOR REGISTRATION LED SIM CARD HOUSING RJ45 for module connection Page 11...
Inserting the antenna Screw the antenna in to the connector on the top of the module. WARNING NEVER connect GSM100 or GSM100 TL module without having installed the antenna. The module may damage. Module connection Insert the provided cable (pin-to-pin cable) in to the RJ45 connector.
Page 10
The module is provided with a 3m. cable. Use a cat.5 or higher cable to connect the GSM100 module at a longer distance. • The GSM100 or GSM100 TL module must be installed in a location where the radio signal allows for using the GSM system. •...
