POWER REQUIREMENTS
Utilizes included 9V DC, 100-240V universal auto-switching
power supply, 200mA, center negative. Tech 21 Model #DC9.
For instructions how to change the prong assembly, see
page 8.
For replacements, contact your local dealer/distributor, or Tech 21.
Note: Also operable with earlier Tech 21 Models #
Maximum power consumption: approx 32mA.
WARNINGS:
• Attempting to repair unit is not recommended and may void warranty.
• Missing or altered serial numbers automatically void warranty. For your own
protection: be sure serial number labels on the unit's back plate and exterior
box are intact, and return your warranty registration card.
ONE YEAR LIMITED WARRANTY. PROOF OF PURCHASE
REQUIRED. Manufacturer warrants unit to be free from defects in materials
and workmanship for one (1) year from date of purchase to the original pur-
chaser and is not transferable. This warranty does not include damage resulting
from accident, misuse, abuse, alteration, or incorrect current or voltage. If unit
becomes defective within warranty period, Tech 21 will repair or replace it
free of charge. After expiration, Tech 21 will repair defective unit for a fee.
ALL REPAIRS for residents of U.S. and Canada: Call Tech 21 for Return
Authorization Number. Manufacturer will not accept packages without
prior authorization, pre-paid freight (UPS preferred) and proper insurance.
FOR PERSONAL ASSISTANCE & SERVICE:
Contact Tech 21 weekdays from 9:00 AM to 5:00 PM, EST.
Hand-built in the U.S.A. using high-quality components
sourced domestically and around the globe.
T: 973-777-6996 • E: info@tech21nyc.com
W: tech21nyc.com
©2023 Tech 21 USA, Inc.
#
DC4 and
DC2.
Advertisement
Related Manuals for Tech 21 SansAmp Street Driver 48 TECH 21 NYC
Summary of Contents for Tech 21 SansAmp Street Driver 48 TECH 21 NYC
- Page 1 If unit becomes defective within warranty period, Tech 21 will repair or replace it free of charge. After expiration, Tech 21 will repair defective unit for a fee. ALL REPAIRS for residents of U.S. and Canada: Call Tech 21 for Return Authorization Number.
-
Page 2: Product Overview
Each product is thoughtfully and respectfully designed by B. Andrew Barta With each Tech 21 product, the controls are designed to give you the himself with the player in mind. He continually strives to offer player- flexibility to obtain your desired sound. -
Page 3: Balanced Xlr Output
1/4” INPUT: 1megOhm high impedance input, same as traditional tube APPLICATIONS amps. WITH A BASS AMP RIG: -As a Pre-Amp: Run the 1/4” Output of the SansAmp directly into the 1/4” UNIVERSAL OUTPUT: Unbalanced low Z output. SansAmp’s power amp input, a.k.a. “effects return” (if applicable), of an amp. This will technologically advanced Universal Output is physically compatible for any bypass the tone-coloring pre-amp section of the amp rig. - Page 4 OVERVIEW OF CONTROLS SPEAKER SIMULATION The all-analog SansAmp Tube Amplifier Emulation technology encompasses the DRIVE entire signal chain, from pre-amp to power amp to speaker simulation. An Adjusts the overall amount of gain and overdrive. Similar to when the output integral part of the circuitry, the SansAmp speaker simulation will complement section of a tube amp is being pushed.
-
Page 5: Universal Power Supply
UNIVERSAL POWER SUPPLY NOTEWORTHY NOTES & CONSIDERATIONS The SansAmp Street Driver 48 is shipped with a power supply set Frank Bello Street Driver 48 Signature SansAmp is an up with a U.S. prong assembly. To change the prong assembly to interactive tool. - Page 6 SansAmp Street Driver 48 Sample Settings SansAmp Street Driver 48 Sample Settings (IN) (OUT) FRANK FRANK BELLO 1 BELLO 4 (MAIN) (DIRTIEST BASTARD) FRANK (RUSH) BELLO 2 (CLEAN DIRT) FRANK (MAIDEN) BELLO 3 (DIRTIER)
- Page 7 SansAmp Street Driver 48 Sample Settings SansAmp Street Driver 48 Custom Settings (IN) (IN) (IN) (OUT) (OUT) (OUT) CHEAP TRICK NAME: JACKSON NAME: Sample settings are a general guide to get you started and may vary depending on your individual playing style and/or gear. Use your ears to adjust accordingly.
- Page 8 SansAmp Street Driver 48 Custom Settings SansAmp Street Driver 48 CustomSettings (IN) (OUT) NAME: NAME: NAME: NAME: NAME: NAME:...
Need help?
Do you have a question about the SansAmp Street Driver 48 TECH 21 NYC and is the answer not in the manual?
Questions and answers
Phantom & Ground Connect XLR- When would i use this button "in" active? Phantom to me is used with mic phantom power....not guitar power?
The Phantom & Ground Connect XLR button should be set to "in" when you are plugging your bass into the SansAmp and taking the XLR Output to a mixer, and there is no other grounded equipment connected in the setup.
