Service manual for Washing Machine
water hose connected to the COLD faucet must be connected to the cold water supply intake.
5. Tighten the fittings by hand until they are snug, and then tighten them an additional two-thirds of a turn with
a wrench. Confirm that the water supply hoses are not twisted or bent. If the hoses are twisted or bent, the hoses
can leak and cause electric shock due to the water leakage.
To ensure the correct water usage, connect both the HOT and COLD water faucets. If either or both are not
connected, an error code can occur. If you do not want to use the HOT water supply hose, insert the water intake
cap into the HOT water supply intake hole. In this case, you must select the Tap Cold option for the water
temperature.
6. Turn on the HOT and COLD water supplies and check all the water supply intake connections and the faucets
for water leaks.
STEP 3: Connect the drain hose
1. Put the Drain Hose out of the Clamp.
2. Position the other end of the drain hose.
It can be positioned in three ways.
A. Over the edge of wash basin
Secure the guide to the side of the basin wall with a hook or to the tap with a piece of string to prevent the
drain hose from moving.
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 14 －
