Toshiba SX-2801 Quick Reference Manual

QUICK
CALLER ID CORDLESS TELEPHONE
REFERENCE
SX-2801
GUIDE
Read the Owner's Manual for details.
SETTING UP THE BASE UNIT
Raise the antenna to vertical position.
Single-Line
Telephone Jack
Fasten the AC Telephone Line Code
(RJ11C)
adaptor cord.
Power Outlet
(AC 120V, 60Hz)
AC Adaptor
NOTE: Plug the AC adaptor firmly into the base unit and the AC 120V outlet.
CHARGING THE BATTERY PACK
1
Red Remove the battery cover by sliding it down.
Black
2
Plug the battery pack cord into its socket, observing
the correct polarity.
3
Place the battery pack . Then close the battery
compartment cover.
4
Place the handset on the base unit. You can place
the handset with the dialpad facing up or down.
IMPORTANT
Charge the battery pack for at least 12 to 16 hours.
IN USE/
CHARGE
Charging contacts LED
UCZZ69719BZ RC009799 Printed in China
SETTING / USING THE PHONE
Setting The Dial Mode
Depending on your dialing system, set the mode as follows:
1
Press and hold until you hear a confirmation tone.
FLASH
2
To set the dial mode for pulse dialing, press / . Or to set the dial mode
# PULSE
for tone dialing press TONE/ .
A confirmatin tone sounds to indicate the setting is complete.
Dial Mode:Pulse Dial Mode:Tone
Tone - Press Tone - Press
Pulse - Press #
Pulse - Press #
TONE/ # / PULSE
Pulse Dialing
Tone Dialing
Area Code
1
Press FUNCTION , then press 3 .
2
Press SELECT and enter a 3-digit area code.
3
Press SELECT , then press FUNCTION .
FLASH
Making a Call
TALK
1
Dial the phone number.
SELECT
2
Press TALK .
3
3
Press TALK to hang up.
TONE/
Answering a Call
FUNCTION
Press TALK and speak.
NOTE: To indicate Caller ID data, let the
phone ring twice before you answer the call.
CALLER ID SERVICE
Setting Up Caller ID
To use Caller ID/Caller ID on Call Waiting features, you must subscribe to both Caller
ID/Caller ID on Call Waiting services provided by your local telephone company.
,
TALK
FLASH
SELECT
CID
1
3
MEM
DELETE
FUNCTION
Selecting Caller ID Options
1
Press FUNCTION .
2
Press , , or 2 to move the pointer to CIDCW.
3
Press SELECT to change the option setting.
4
Press FUNCTION and return the handset to the base.
See page 15 and 16 in the owner's manual for more information.
Making a Call with Caller ID Data
1
Press CID , then press or to display the number you want to dial.
2
Press TALK , then displayed number will be dialed.
Note: For long distance calls, you need a prefix "1" and the area code.
Press L.D./1 and LOCAL/3 to add or cancel "1" and the area code
before press TALK .
Storing Caller ID Data to Speed-Dial Memory
1
Press CID , then press or to display the number you want to store into
Speed-dial memory.
2
Press , then press , or enter a memory location number.
MEM
3
Press SELECT . A confirmation beep sounds and the Caller ID data is stored.
Press CID to return to standby mode.
Deleting Caller ID Data
1
Press CID , then press or to display the Caller ID number you want to
delete from the memory.
2
Press DELETE , then press or to select Yes or No.
3
Press SELECT or DELETE .
4
Press CID to return to standby mode.
Call Waiting Options
1
When you receive a call waiting call, press FUNCTION for a list of options.
2
Press or to select an option.
3
Press SELECT to confirm.
4
TALK
Press or return the handset to the base to end the call.
See page 33 in the owner's manual for more information.
For more detailed instructions and examples, please refer to the owner's manual.
