OWNER
S MANUAL
2.4GHz DIGITAL SPREAD SPECTRUM CORDLESS TELEPHONE
SG - 1801
The FIRST thing to do after unpacking your new
cordless telephone is:
CHARGE THE BATTERY !
Please read and follow the few instructions on
PAGE 2
BEFORE YOU DO ANYTHING ELSE.

Advertisement

Table of Contents
loading

Related Manuals for Toshiba SG-1801

Summary of Contents for Toshiba SG-1801

  • Page 1 OWNER S MANUAL 2.4GHz DIGITAL SPREAD SPECTRUM CORDLESS TELEPHONE SG - 1801 The FIRST thing to do after unpacking your new cordless telephone is: CHARGE THE BATTERY ! Please read and follow the few instructions on PAGE 2 BEFORE YOU DO ANYTHING ELSE.
  • Page 2 GETTING STARTED: DO THIS FIRST! FIRST, CHARGE THE HANDSET BATTERY! • Set your new phone in an out-of-the-way place near a power outlet where it will not be disturbed. • Plug the AC adaptor into the wall outlet. • Plug the AC adaptor cord into the power jack on the base unit.

  • Page 3: Introduction

    Toshiba America Consumer Products, Inc., takes pride in presenting the new 2.4 GHz digital spread spectrum cordless telephone. The Toshiba cordless telephone features a 16-digit x 3-line dot matrix liquid crystal display (LCD) for caller ID on Call Waiting and speed-dial programming and calling.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Preparation INTRODUCTION ......... .3 Features .
  • Page 5 Steps for entering names and special characters ....24 If you make a mistake while entering a name ....25 Dialing a stored number .

  • Page 6: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury. 1 Read and understand all instructions. 2 Follow all warnings and instructions marked on the product. 3 Unplug this product from the wall outlet before cleaning.

  • Page 7: Save These Instructions

    The RBRC Seal The RBRC (contained in our product) indicates that Toshiba America Consumer Products, Inc. (TACP) is voluntarily participating in an industry program to collect and recycle these batteries at the end of their useful lives, when taken out of service within the United States. The RBRC program provides a convenient alternative to placing used nickel- cadmium batteries into the trash or municipal waste, which is illegal in some areas.

  • Page 8: Location Of Controls

    LOCATION OF CONTROLS HANDSET Headset jack (Memory) button (page 22) button (page 18) TALK button (page 30) L.D./1 (TONE) button (page 20) TONE/ ( ) button (Left arrow button) (page 22 to 26) (Redial/Pause) button RDL/P (page 19) button (page 15 to 16, 33) FUNCTION SUPPLIED ACCESSORIES: Modular Line Cord...

  • Page 9: Base Unit

    Tone/Pulse switch (page 14) Hook IN USE/CHARGE LED PAGE button (page 21) Antenna Charging contacts For purchase of accessories, please call 1-877-644-7373. Owner’s manual Part # RC009816 Quick Reference Guide Rechargeable Battery Pack Part # RC009817 Toshiba TRB-1981 Part # RC009814...

  • Page 10: Installation

    INSTALLATION SETTING UP THE BASE UNIT (DESK TOP MOUNTING) For setting up the base unit follow the instructions below. Snap the bracket’s tab into the notches on the base. Raise the antenna to vertical position. • Plug the AC adaptor firmly into the base unit and the AC 120V outlet. •...

  • Page 11: Setting Up The Base Unit (Wall Mounting)

    SETTING UP THE BASE UNIT (WALL MOUNTING) MOUNTING ON A STANDARD WALL PLATE: Insert the bracket’s tabs into the base’s lower tab slots, then press down on the top of the bracket to snap it into the clip slots. Flip the hook tab over so the tab holds the handset.

  • Page 12: Charging The Battery Pack

    INSTALLATION CHARGING THE BATTERY PACK It is important to charge the battery for 12-16 hours continuously without any interruption before you use the handset for the first time. Black IN USE/ CHARGE Charging contacts NOTES: • Use only the supplied battery pack (TRB-1981 power source 800mAh, 3.6VDC) •...
  • Page 13 After the battery pack is fully charged; Operation While in use (Talk mode) While not in use (Standby mode) When "Low Battery" blinks on the LCD, all handset buttons except are disabled and the battery needs to be charged. If this occurs TALK during a call, you hear short beeps.

  • Page 14: Setting The Tone/Pulse Switch

    INSTALLATION Before using the Handset, make sure to read the following instructions. SELECT/CHANNEL FUNCTION SETTING THE TONE/PULSE SWITCH Set the TONE/PULSE switch to TONE. Place a call. If the call does not connect with the TONE setting, set the TONE/PULSE switch to PULSE. TONE/PULSE switch...

  • Page 15: Setting Or Canceling The Auto Talk Function

    SETTING OR CANCELING THE AUTO TALK FUNCTION If the handset is placed on the base unit, you can answer a call by lifting the handset from the base unit (Auto Talk). If the handset is not on the base unit, you can answer a call by pressing any one of the buttons (Any-key Answer function).

  • Page 16: Setting The Area Code

    INSTALLATION SETTING THE AREA CODE It is necessary to program your area code so that local calls will be displayed properly on caller ID. Press FUNCTION Press to move the pointer to Area Code. Press SELECT/CHANNEL Enter your 3-digit area code. For example, enter “615.” If you enter a wrong number, press Press SELECT/CHANNEL...

  • Page 17: Using The Headset And Belt Clip (Option)

    USING THE HEADSET AND BELT CLIP (OPTION) For purchase of an optional accessory, please call 1-877-644-7373. HEADSET You can use an optional headset (part#: RC 008260) that has a 3/32- inch (2.5mm) plug. NOTES: • The handset's earspeaker and microphone are turned off with a headset connected.

  • Page 18: Basic Operation

    BASIC OPERATION Before using the Handset, make sure to read the following instructions. TALK TONE/ RDL/P MAKING A CALL Handset On The Base 1) Pick up the handset. 2) Press TALK 3) Listen for the dial tone. 4) Dial the number. 1) Pick up the handset.

  • Page 19: 3-Number Redial

    3-NUMBER REDIAL You can redial any of the last three numbers dialed from the handset: Press in standby mode. The last dialed number (Redial 1) RDL/P appears. Each time you press dialed numbers (Redial 1 to Redial 3). After the desired number has been selected, press connected.

  • Page 20: Tone/Pause

    BASIC OPERATION TONE/PAUSE To temporarily switch to tone dial (When the base is set to pulse mode), see page 14. To enter a pause within the dialing sequence EXAMPLE : To make a call “0 pulse mode, press INTERFERENCE OR STATIC If you hear noise during a call, press to select another channel.

  • Page 21: Paging The Handset

    PAGING THE HANDSET To locate the handset while it is off the base, press . The handset beeps for 60 PAGE seconds. To stop paging, press return the handset to the base unit. NOTES: • You cannot page the handset during a call. •...

  • Page 22: Memory Dialing

    MEMORY DIALING You can store up to 20 telephone numbers and their associated names in the memory. NOTES: • Always press a button within 20 seconds or the phone will return to standby. • If you press a wrong button, an error tone sounds and the handset returns to standby mode.
  • Page 23 Press SELECT/CHANNEL To enter a name, use the number keys. • See the steps for storing names and special characters. (see page 24) • If a name is not required, go to step 5. Press SELECT/CHANNEL Enter a telephone number to be stored. NOTES: •...

  • Page 24: Steps For Entering Names And Special Characters

    MEMORY DIALING STEPS FOR ENTERING NAMES AND SPECIAL CHARACTERS Refer to the letters on the number buttons to select the desired letter. Each button selects a character as shown below. Keys For example, to enter “ Pick up the handset and press and hold sounds.

  • Page 25: If You Make A Mistake While Entering A Name

    Press five times. When finished, press Press stored. Press SELECT/CHANNEL IF YOU MAKE A MISTAKE WHILE ENTERING A NAME to move the cursor to the incorrect character. Press to erase the wrong entry, then enter the correct character. To DELETE delete all characters, press and hold DIALING A STORED NUMBER Pick up the handset and press...

  • Page 26: Editing And Deleting Stored Numbers

    MEMORY DIALING EDITING AND DELETING STORED NUMBERS You can delete a number or simply store another one in its place. When you store a new phone number, the data stored in that memory location is deleted automatically. Pick up the handset and press and hold The confirmation tone sounds.
  • Page 27 DELETING THE STORED DATA (1) Press to move the pointer to select (2) Press SELECT/CHANNEL is selected: a confirmation tone sounds and the number is erased. is selected: the LCD returns to the “ ” display. (3) Press , or return the handset to the base unit. MEMORY DIALING DELETE...

  • Page 28: Caller Id/Call Waiting

    CALLER ID/CALL WAITING TALK L.D./1 FUNCTION NOTES • Before you can take advantage of the Caller ID and Call Waiting features, you must subscribe to these services from your local telephone company. • Name and number caller ID only work in conjunction with service provided by your local telephone company.

  • Page 29: Searching Caller Id Memory

    SEARCHING CALLER ID MEMORY To review who has called, follow the steps below. The caller ID memory retains a listing of the 50 most recent callers. Pick up the handset and press If new caller ID data does not exist: If there is new caller ID data: Press to display the latest incoming call.

  • Page 30: Editing Caller Id Data

    CALLER ID/CALL WAITING EDITING CALLER ID DATA You can edit the Caller ID data. Pick up the handset and press repeatedly to display the Caller ID data you want to edit. Press for a long distance call prefix “1” and L.D./1 for area code setting and cancellation.

  • Page 31: Deleting Caller Id Data

    Press SELECT/CHANNEL ID data is stored. Press If you select a memory location which is already stored: Press to select “ SELECT/CHANNEL A confirmation tone sounds and the new data overwrites the old data. The LCD returns to the Caller ID display screen. If you select The LCD returns to the Caller ID display screen.

  • Page 32: Call Waiting

    CALLER ID/CALL WAITING DELETE ALL CALLER ID DATA: Press Press DELETE Press to select Press SELECT/CHANNEL If you select , a confirmation tone sounds and the LCD displays “ If you select , the LCD displays the number of Caller ID calls. Press to return to the standby mode.

  • Page 33: Call Waiting Options

    CALL WAITING OPTIONS Your phone gives you new options for call waiting. At the touch of a button, you can ask the caller to hold, send them to your voice mail service,or conference them into your current call. You may be required to subscribe to a voice mail service, call waiting, and call waiting options to use these features.
  • Page 34 CALLER ID/CALL WAITING The options you can choose are shown below: Option Ask to Hold Tell Busy Take Message Answer / Drop 1 Conference Drop First Drop Last NOTES: • When using each of the options listed above, an extra charge might apply. •...

  • Page 35: Troubleshooting

    Should any problem occur with the unit, use the following simple tests to determine whether or not servicing is required. PROBLEM The handset battery pack • The charging contacts of the handset and base are not clean. does not charge. •...
  • Page 36 TROUBLESHOOTING PROBLEM The handset does not ring • The handset is located away from the base or the battery has been or receive a page. • The digital security code is changed. • The battery is low. The handset does not •...
  • Page 37 PROBLEM When the handset is • This is normal. returned to the base unit → It may be prevented by changing the volume setting to with the volume level set at High, a momentary squeal or howling sound may sometimes be heard. The phone does not •...
  • Page 38 QUICK SETTING / USING THE PHONE CALLER ID CORDLESS TELEPHONE REFERENCE SG-1801 Setting The Tone/Pulse Switch GUIDE Set the TONE/PULSE switch to TONE. Read the Owner’s Manual for details. Place a call. If the call does not connect with the TONE setting, set the...
  • Page 39 AJUSTE/UTILIZACIÓN DEL TELÉFONO REFERENCIA RÁPIDA CALLER ID CORDLESS TELEPHONE SG-1801 Ajuste del selector de tono/pulso Ajuste el selector TONE/PULSE a TONE. Para los detalles, lea el manual de instrucciones (en inglés). Realice una llamada. Si la llamada no se conecta con el ajuste en TONE, INSTALACIÓN DE LA UNIDAD BASE...

  • Page 40: Warranty/Service

    If the unit is still in warranty, the remainder of the warranty period will also be null and void. It is the responsibility of users requiring service to report the need for service to the Toshiba dealer.
  • Page 41 TELEPHONE/TELEPHONE ANSWER MACHINE LIMITED WARRANTY Toshiba America Consumer Products, Inc. (“TACP”), and Toshiba Hawaii, Inc. (“THI”), make the following limited warranties. These limited warranties extend to the original consumer purchaser or any person receiving this set as a gift from the original consumer purchaser and to no other purchaser or transferee.
  • Page 42 We suggest you record the following information and retain for your records along with your bill of sale or equipment document. Model no. Purchase date Dealer address © 2001 TOSHIBA AMERICA CONSUMER PRODUCTS, INC. UCZZ01738BZ RC009816 Serial no. Dealer Printed in China...
