PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
1.77 [44.9]
1.02 [25.9]
.035 - .040 [.89 - 1.02]
.47 [12.0]
.244 - .250 [6.20 - 6.35]
 
1 .245 - .246 [ 6.22 - 6.25]
 
1 .319 - .320 [ 8.10 - 8.13]
8 CAUTION: DO NOT TOUCH SEAL SURFACE WITH TAP WHEN TAPPING HOLE
7 DIMENSIONS "A" & "B" TO SUIT USERS REQUIREMENTS
A
6 KEEP DIMENSION "A" AS SHORT AS POSSIBLE, SEE OPERATING GUIDE FOR OPTIMUM PASSAGE LENGTH
5 THESE DIAMETERS TO BE CONCENTRIC TO WITHIN .001 [.03] TIR
4 SEAL SURFACE SHOULD BE FLAT & FREE OF TOOL MARKS WITH A MINIMUM FINISH OF 63 [1.6] FOR BEST RESULTS
3 DIMENSIONS SHOWN ARE FOR A .850 [21.59] THICK WALL. COUNTERBORE FOR THICKER WALLS
2 RECOMMENDED MOUNTING TORQUE ON .312 [7.93] HEX: 27-32 FT-LB [37-43 N-m]
1
MATERIAL: C-300 MARAGING STEEL
4
3
ELECTRICAL CONNECTOR
COAXIAL 10-32 UNF - 2A
HEAT SHRINKABLE
TUBING GROOVE
.312 [7.92] HEX 2
3/8-24 UNF - 2A
MODEL 065A06 SEAL
 
.318 [ 8.08] O.D.
.010 [.25] THICK
MATERIAL: 316
 .248 - .249 [  6.30 - 6.32]
1
PROTECTIVE CERAMIC COATING
3
FLUSH INSTALLATION
.850 [21.59] 3
.260 [6.60]
MOUNTING HOLE DIMENSIONS
 
3 5 .252± .001 [ 6.40± .03] THRU
1
 .332± .001 [  8.43± .03] TO DEPTH SHOWN
4 5

8 3/8-24 UNF-2B .510 [12.95]
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.01
XXX ±.005
ANGLES  2 DEGREES
CABLE TOLERANCES IN ENGLISH
1"≤ LENGTH < 1' = +1"/ - 0
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
1'≤ LENGTH < 5' = +2"/ - 0
30.5cm ≤ LENGTH < 1.5m
5'≤ LENGTH < 100' = +6"/ - 0
1.5m
30.5m ≤ LENGTH
100'≤ LENGTH = +1'/ - 0
FILLETS AND RADII
.003 - .005
2
REV
REVISED DIMENSION .244-.250, ADDED CERAMIC
C
RECESSED INSTALLATION
MOUNTING HOLE DIMENSIONS

3 5 .252± .001 [
5  .332± .001 [
4
8 3/8-24 UNF-2B
DRAWN CHECKED
DIMENSIONS IN MILLIMETERS
NJF 09/13/22 JDM 09/13/22
[ IN BRACKETS ]
DECIMALS X ± 0.3
XX ± 0.13
TITLE
ANGLES  2 DEGREES
INSTALLATION DRAWING
CABLE TOLERANCES IN METRIC
MODEL 109B01 & 109B02
= +5.1cm/ - 0
≤ LENGTH < 30.5m = +15.2cm/ - 0
PRESSURE SENSOR
= +30.5cm/ - 0
FILLETS AND RADII
0.07 - 0.13
2
1
REVISIONS
DESCRIPTION DIN
53103
COATING NOTE
B
.850 [21.59] 3
.260 [6.60]
"A" 6 7

"B" 7
 
6.40± .03] .850 [21.59]
 8.43± .03] TO DEPTH SHOWN

.510 [12.95]
A
ENGINEER
RF 09/13/22
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
21944
IDENT. NO.
52681
SCALE: 3X SHEET 1 OF 1
