User Guide
BE9300 Tri-Band Wi-Fi 7 Router
MR47BE
© 2023 MERCUSYS 1910080105 REV1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MR47BE and is the answer not in the manual?

Questions and answers

Related Manuals for Mercusys MR47BE

Summary of Contents for Mercusys MR47BE

  • Page 1 User Guide BE9300 Tri-Band Wi-Fi 7 Router MR47BE © 2023 MERCUSYS 1910080105 REV1.0.0...
  • Page 2 5470 MHz -5725 MHz (30dBm) 5945MHz -6425 MHz (23dBm) EU Declaration of Conformity Mercusys hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863. The original EU declaration of conformity may be found at http://www.mercusys.com/en/ce.
  • Page 3 (UAS) are not permitted. UKCA Mark UK Declaration of Conformity Mercusys hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. The original UK Declaration of Conformity may be found at https://www.mercusys.com/support/ukca/...
  • Page 4 前述合法通信，指依電信管理法規定作業之無線電通信。 低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 應避免影響附近雷達系統之操作。 高增益指向性天線只得應用於固定式點對點系統。 安全 諮詢 及注意事 項 Ǵ 請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。 Ǵ 清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。 Ǵ 注意防潮，請勿將水或其他液體潑灑到本產品上。 Ǵ 插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。 Ǵ 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。 Ǵ 不要私自拆開機殼或自行維修，如產品有故障請與原廠或代理商聯繫。 限用物質含有情況標示聲明書 設備名稱：BE9300 Tri-Band Wi-Fi 7 Router 型號（型式）：MR47BE Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Unit H e x a v a l e n t...
  • Page 5 備考 1. " 超出 0.1 wt %" 及 " 超出 0.01 wt %" 系指限用物質之百分比含量超出百分比 含量基準值。 備考 2. " ○ " 系指該項限用物質之百分比含量未超出百分比含量基準值。 備考 3. " − " 系指該項限用物質為排除項目。 Safety Information Ǵ Keep the device away from water, fire, humidity or hot environments. Ǵ Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
  • Page 6 Polarity of d.c. power connector For indoor use only Dangerous voltage Caution, risk of electric shock Energy efficiency Marking Protective earth Earth Frame or chassis Functional earthing Caution, hot surface Caution Operator’s manual Stand-by “ON”/”OFF” (push-push) Fuse Fuse is used in neutral N RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE).
  • Page 7 Disconnection, all power plugs Switch of mini-gap construction µ Switch of micro-gap construction (for US version) Switch of micro-gap / micro-disconnection construction (for other versions except US) ε Switch without contact gap (Semiconductor switching device)

  • Page 8: Table Of Contents

    2. 3. 2. Method 2: Via MERCUSYS App ....... . .
  • Page 9 4. 5. 5. Wireless Schedule ............34 4.
  • Page 10 4. 13. 9. Time ..............92 4.

  • Page 11: Conventions

    Wi-Fi 7 clients (with MLO turned on) connecting to the 5 GHz and 6 GHz bands of a MERCUSYS Wi-Fi 7 router (with MLO turned on) simultaneously and to the 5 GHz or 6 GHz bands of a Wi-Fi 6/6E router (without the MLO function).

  • Page 12: Chapter 1. Introduction

    1. 1. Product Overview Mercusys Wi-Fi 7 router MR47BE takes full advantage of the 6 GHz band, with up to 320 MHz channels, 4K-QAM, and MLO(Multi-Link Operation), improving Wi-Fi speeds to 9.3 Gbps. You can experience unlimited 8K streaming and lightning-fast downloading.

  • Page 13: Rear Panel

    Chapter 1 Introduction 1. 2. 2. Rear Panel The following items are located on the rear panel (View from left to right). Item Description Press and hold this button for more than 5 seconds to reset the router. RESET/WPS Button Press for 1 second to use the WPS function.

  • Page 14: Chapter 2. Connect To The Internet

    Chapter 2 Connect to the Internet Chapter 2. Connect to the Internet 2. 1. Position Your Router • The product should not be located in a place where it will be exposed to moisture or excessive heat. • Place the router in a location where it can be connected to multiple devices as well as to a power source.

  • Page 15: Set Up The Router

    Chapter 2 Connect to the Internet *Image may differ from actual product. INTERNET Power adapter Power adapter Router Modem 1 ) Turn off the modem, and remove the backup battery if it has one. 2 ) Connect the modem to the router’s WAN port with an Ethernet cable. 3 ) Turn on the router, and then wait about 2 minutes for it to restart.
  • Page 16 Connect to the Internet 3. Follow the Quick Setup to complete the setup. 4. To enjoy a more complete service from Mercusys (remote management, Mercusys DDNS, and more.), log in with your Mercusys ID to bind the cloud router. Note: If you don’t have an account, create one first.

  • Page 17: Method 2: Via Mercusys App

    Connect to the Internet 2. 3. 2. Method 2: Via MERCUSYS App 1. Scan the QR code to download the MERCUSYS app from the Apple App Store or Google Play. 2. Launch the app and log in with your Mercusys ID.
  • Page 18 Chapter 2 Connect to the Internet 4. Enjoy! Connect to the network and enjoy the internet.

  • Page 19: Chapter 3. Log In To The Router

    Follow the steps below to log in to your router. 1. Set up the TCP/IP Protocol in Obtain an IP address automatically mode on your computer. 2. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you created. Note:...

  • Page 20: Chapter 4. Configure The Router In Wireless Router Mode

    This chapter presents how to configure the various features of the router working as a wireless router. It contains the following sections: • Operation Mode • Quick Setup • Network • Mercusys ID • Wireless • NAT Forwarding • Parental Controls • QoS • Security •...

  • Page 21: Quick Setup

    Chapter 4 Configure the Router in Wireless Router Mode 4. 2. Quick Setup 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Quick Setup. 3. Follow the step-by-step instructions to complete the setup.
  • Page 22 Chapter 4 Configure the Router in Wireless Router Mode • Internet - This field displays the current settings of the internet, and you can configure them on the Advanced > Network > Internet page. • Status - Indicates whether the router has been connected to the internet. •...

  • Page 23: Internet

    Service Provider - The Dynamic DNS service provider you have signed up for. 4. 3. 2. Internet 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Network > Internet.
  • Page 24 Chapter 4 Configure the Router in Wireless Router Mode • Get IP with Unicast DHCP - A few ISPs’ DHCP servers do support the broadcast applications. If you cannot get the IP address normally, you can choose this option (it is rarely required). Static IP If your ISP provides a static or fixed IP address, subnet mask, default gateway and DNS setting, please select Static IP.
  • Page 25 Chapter 4 Configure the Router in Wireless Router Mode • Service Name - The service name should not be configured unless you are sure it is necessary for your ISP. In most cases, leaving these fields blank will work. • Access Concentrator Name - The access concentrator name should not be configured unless you are sure it is necessary for your ISP.
  • Page 26 Chapter 4 Configure the Router in Wireless Router Mode L2TP If your ISP provides L2TP connection, please select L2TP. • Username/Password - Enter the username and password provided by your ISP. These fields are case-sensitive. • VPN Server IP/ Domain Name - Enter the VPN server’s IP address or domain name provided by your ISP.
  • Page 27 Chapter 4 Configure the Router in Wireless Router Mode • On Demand - In this mode, the internet connection will be terminated automatically after a specified inactivity period (Max Idle Time) and be re-established when you attempt to access the internet again. •...
  • Page 28 Chapter 4 Configure the Router in Wireless Router Mode PPTP If your ISP provides PPTP connection, please select PPTP. • Username/Password - Enter the username and password provided by your ISP. These fields are case-sensitive. • VPN Server IP/ Domain Name - Enter the VPN server’s IP address or domain name provided by your ISP.

  • Page 29: Mac Clone

    4. 3. 3. MAC Clone 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Network > Internet and locate the MAC Clone section.

  • Page 30: Nat

    IP address to communicate with devices on the internet, which protects the local network by hiding IP addresses of the devices. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router.

  • Page 31: Iptv/Vlan

    Note: Enable Flow Controller may cause internet drop with some devices. 4. 3. 7. IPTV/VLAN 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Network > IPTV/VLAN.

  • Page 32: Dhcp Server

    Chapter 4 Configure the Router in Wireless Router Mode 1 ) Tick the IGMP Proxy and IGMP Snooping checkbox, then select the IGMP Version, either V2 or V3, as required by your ISP. 2 ) Check the Wireless Multicast Forwarding status. When enabled, the multicast packets will be forwarded automatically.
  • Page 33 LAN IP addresses for specified client devices. • To specify the IP address that the router assigns: 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Network > DHCP Server and locate the DHCP Server section.

  • Page 34: Dynamic Dns

    MAC and IP address of the client device. • To check the DHCP client list: 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Network > DHCP Server and locate the DHCP Client List section. You can see the device information of the list.

  • Page 35: Static Routing

    Chapter 4 Configure the Router in Wireless Router Mode It is recommended to select Mercusys so that you can enjoy superior DDNS service of Mercusys. To use Mercusys DDNS service, log in with your Mercusys ID and register new domain names.
  • Page 36 1. Change the routers’ LAN IP addresses to two different IP addresses on the same subnet. Disable Router B’s DHCP function. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for Router A. 2. Go to Advanced > Network > Routing and locate the Static Routing section.

  • Page 37: Mercusys Id

    4. 4. Mercusys ID 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Mercusys ID. 3. Log in with your Mercusys ID. You can manage the account information and bind more accounts to manage the network.

  • Page 38: Wireless

    Wireless 4. 5. 1. Wireless Settings 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Wireless > Wireless Settings. 3. Configure the wireless settings for the wireless network and click SAVE.
  • Page 39 Chapter 4 Configure the Router in Wireless Router Mode...
  • Page 40 Chapter 4 Configure the Router in Wireless Router Mode • TWT - Target Wake Time allows 802.11ax routers and clients to negotiate their periods to transmit and receive data packets. Clients only wake up at TWT sessions and remain in sleep mode for the rest of the time, which significantly extend their battery life.

  • Page 41: Mlo Network

    1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Wireless or Advanced > Wireless > Wireless Settings, and locate the MLO Network section.

  • Page 42: Guest Network

    In addition, you can customize guest network settings to ensure network security and privacy. • Create a Guest Network 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Wireless or Advanced > Wireless > Guest Network.

  • Page 43: Iot Network

    Chapter 4 Configure the Router in Wireless Router Mode 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Wireless > Guest Network. Locate the Guest Permissions section.

  • Page 44: Wireless Schedule

    The wireless function can be automatically off at a specific time when you do not need the wireless function. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Wireless > Wireless Schedule.

  • Page 45: Wps

    The WPS function cannot be configured if the wireless function of the router is disabled. Please make sure the wireless function is enabled before configuration. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router.
  • Page 46 Chapter 4 Configure the Router in Wireless Router Mode 2. Enter the PIN of your device and click CONNECT. Then your device will get connected to the router. • Connects via the Router’s PIN 1. Keep the WPS Status as Enabled and select Router’s PIN. 2.

  • Page 47: Additional Settings

    Press the router’s WPS button. Within two minutes, enable WPS on your personal device. 4. 5. 7. Additional Settings 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Wireless > Additional Settings.

  • Page 48: Nat Forwarding

    LAN and realize some specific functions. The Mercusys router includes four forwarding rules. If two or more rules are set, the priority of implementation from high to low is Port Forwarding, Port Triggering, UPNP and DMZ.
  • Page 49 Home 1. Set your PC to a static IP address, for example 192.168.1.100. 2. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 3. Go to Advanced > NAT Forwarding > Port Forwarding.

  • Page 50: Port Triggering

    Chapter 4 Configure the Router in Wireless Router Mode 5. Click VIEW COMMON SERVICES and select HTTP. The External Port, Internal Port and Protocol will be automatically filled in. 6. Click VIEW CONNECTED DEVICES and select your home PC. The Device IP Address will be automatically filled in.

  • Page 51: Upnp

    Follow the steps below to configure the port triggering rules: 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > NAT Forwarding > Port Triggering.
  • Page 52 Router If necessary, you can follow the steps to change the status of UPnP. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > NAT Forwarding > UPnP and toggle on or off according to your needs.

  • Page 53: Dmz

    How can I do that? 1. Assign a static IP address to your PC, for example 192.168.1.100. 2. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 3. Go to Advanced > NAT Forwarding > DMZ and enable DMZ.

  • Page 54: Parental Controls

    2 hours every day and block internet access during bed time (10 PM to 7 AM) on weekdays. How can I do that? 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Parental Controls.
  • Page 55 Chapter 4 Configure the Router in Wireless Router Mode Note: Only devices that have previously been connected to your router’s network are listed here. If you are unable to find the device you want to add, connect it to your network and then try again. 4 ) Click NEXT.

  • Page 56: Qos

    Chapter 4 Configure the Router in Wireless Router Mode 1 ) Enable Time Limits on Monday to Friday and Saturday & Sunday then set the allowed online time to 2 hours each day. 2 ) Enable Bed Time on School Nights (Sun to Thur) and use the up/down arrows or enter times in the fields.

  • Page 57: Security

    Ensure a fast connection of my computer while I play online games for the next 2 hours. How can I do that 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router.

  • Page 58: Firewall

    This function is enabled by default. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Security > Firewall, and configure the parameters as you need. It’s recommended to keep the default settings.
  • Page 59 Chapter 4 Configure the Router in Wireless Router Mode 7 ) Click Add and select devices you want to be blocked. You can see the devices have been added to the list. To allow specific device(s): 1 ) Select Allow List and click SAVE. 2 ) Add devices to the list.

  • Page 60: Ip & Mac Binding

    Chapter 4 Configure the Router in Wireless Router Mode • Add unconnected devices Click Add Manually and enter the Device Name and MAC Address of the device you want to be allowed. Done! Now you can block or allow specific client devices to access your network (via wired or wireless) using the Deny List or Allow List.
  • Page 61 Chapter 4 Configure the Router in Wireless Router Mode 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Security > IP & MAC Binding. 3. Enable IP & MAC Binding.

  • Page 62: Alg

    1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > Security > Device Isolation.

  • Page 63: Vpn Server & Client

    VPN client software on the remote device. Please follow the steps below to set up an OpenVPN connection. Step1. Set up OpenVPN Server on Your Router 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. Note: •...
  • Page 64 Chapter 4 Configure the Router in Wireless Router Mode • The first time you configure the OpenVPN Server, you may need to Generate a certificate before you enable the VPN Server. 2. Go to Advanced > VPN Server > OpenVPN, and enable VPN Server. 3.

  • Page 65: Pptp Vpn

    VPN connection. Step 1. Set up PPTP VPN Server on Your Router 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > VPN Server > PPTP, and enable PPTP.
  • Page 66 Chapter 4 Configure the Router in Wireless Router Mode 4. Set the PPTP connection permission according to your needs. • Select Allow Samba (Network Place) access to allow your VPN device to access your local Samba server. • Select Allow NetBIOS passthrough to allow your VPN device to access your Samba server using NetBIOS name.
  • Page 67 Chapter 4 Configure the Router in Wireless Router Mode 3. Select Connect to a workplace and click Next. 4. Select Use my Internet connection (VPN).
  • Page 68 Chapter 4 Configure the Router in Wireless Router Mode 5. Enter the internet IP address of the router (for example: 218.18.1.73) in the Internet address field. Click Next. 6. Enter the User name and Password you have set for the PPTP VPN server on your router, and click Connect.

  • Page 69: L2Tp/Ipsec Vpn

    Chapter 4 Configure the Router in Wireless Router Mode 7. The PPTP VPN connection is created and ready to use. 4. 10. 3. L2TP/IPSec VPN L2TP/IPSec VPN Server is used to create a L2TP/IPSec VPN connection for remote devices to access your home network.
  • Page 70 Remote Devices Step 1. Set up L2TP/IPSec VPN Server on Your Router 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > VPN Server > L2TP/IPSec, and enable L2TP/IPSec.
  • Page 71 Chapter 4 Configure the Router in Wireless Router Mode 7. Click Add. 1 ) Enter the Username and Password to authenticate devices to the L2TP/IPSec VPN Server. 2 ) Click ADD. Step 2. Configure L2TP/IPSec VPN Connection on Your Remote Device The remote device can use the Windows or Mac OS built-in L2TP/IPSec software or a third- party L2TP/IPSec software to connect to L2TP/IPSec Server.
  • Page 72 Chapter 4 Configure the Router in Wireless Router Mode 3. Select Connect to a workplace and click Next. 4. Select Use my Internet connection (VPN).
  • Page 73 Chapter 4 Configure the Router in Wireless Router Mode 5. Enter the internet IP address of the router (for example: 218.18.1.73) in the Internet address field, and select the checkbox Don’t connect now; just set it up so I can connect later.
  • Page 74 Chapter 4 Configure the Router in Wireless Router Mode 7. Click Close when the VPN connection is ready to use 8. Go to Network and Sharing Center and click Change adapter settings.
  • Page 75 Chapter 4 Configure the Router in Wireless Router Mode 9. Find the VPN connection you created, then double-click it. 10. Enter the User name and Password you have set for the L2TP/IPSec VPN server on your router, and click Properties.
  • Page 76 Chapter 4 Configure the Router in Wireless Router Mode 11. Switch to the Security tab, select Layer 2 Tunneling Protocol with IPsec (L2TP/IPSec) and click Advanced settings. 12. Select Use preshared key for authentication and enter the IPSec Pre-Shared Key you have set for the L2TP/IPSec VPN server on your router.

  • Page 77: Wireguard Vpn

    Step 1. Set up WireGuard VPN Server on Your Router 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > VPN Server > WireGuard, and enable WireGuard.
  • Page 78 Chapter 4 Configure the Router in Wireless Router Mode 4. Select your Client Access type. Select Home Network Only if you only want the remote device to access your home network; select Internet and Home Network if you also want the remote device to access internet through the VPN Server.
  • Page 79 App to scan the QR Code to connect to this server. • For other devices (e.g. Mercusys WireGuard VPN client), click EXPORT to save the WireGuard VPN configuration file which will be used by the remote device to access your router.

  • Page 80: Use Vpn Client To Access A Remote Vpn Server

    Home Devices Router (VPN Client) VPN Servers 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > VPN Client. Note: Firmware update may be required to support VPN Client.
  • Page 81 Chapter 4 Configure the Router in Wireless Router Mode 3 ) Enter the VPN information provided by your VPN provider. • OpenVPN: Enter the VPN username and password if required by your VPN provider, otherwise simply leave them empty. Then import the configuration file provided by your VPN provider.
  • Page 82 Chapter 4 Configure the Router in Wireless Router Mode • PPTP: Enter the VPN server address (for example: 218.18.1.73) and the VPN username and password provided by your VPN provider. • L2TP/IPSec VPN: Enter the VPN server address (for example: 218.18.1.73), VPN username and password, and IPSec pre-shared key provided by your VPN provider.
  • Page 83 Chapter 4 Configure the Router in Wireless Router Mode 4 ) Save the settings. 5 ) In the server list, Enable the VPN server you need. 5. Add and manage the devices that will use the VPN function. 1 ) In the Device List section, click Add. 2 ) Choose and add the devices that will access the VPN server you have configured.

  • Page 84: Ipv6

    This function allows you to set up an IPv6 internet connection using the information provided by your ISP (internet service provider). 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > IPv6.
  • Page 85 Chapter 4 Configure the Router in Wireless Router Mode • Dynamic IP(SLAAC/DHCPv6): Click Advanced Settings to input further information if your ISP requires. Save the settings and click RENEW. • PPPoE: By default, the router uses the IPv4 account to connect to the IPv6 server. Click Advanced Settings to input further information if your ISP requires.
  • Page 86 Chapter 4 Configure the Router in Wireless Router Mode • 6to4 Tunnel: An IPv4 internet connection type is a prerequisite for this connection type. Please manually set up your internet connection first. Click Advanced Settings to input further information if your ISP requires. Save the settings and click CONNECT. •...

  • Page 87: Set Up Ipv6 Firewall Rules

    This feature is available only when you’ve set up an IPv6 connection. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router.

  • Page 88: Easymesh With Seamless Roaming

    Note: Routers and range extenders must be compatible with EasyMesh. Firmware upgrades may be required. 4. 12. 1. Add a Router as a Satellite Device 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router.
  • Page 89 Chapter 4 Configure the Router in Wireless Router Mode 3. Click ADD SATELLITE DEVICES, select Mercusys Router, then click NEXT 4. Follow the page instructions to prepare your satellite router, then click DONE. 5. Click ADD. When prompted “This device has been added successfully“, click OK, then...

  • Page 90: Add A Range Extender As A Satellite Device

    Chapter 4 Configure the Router in Wireless Router Mode 4. 12. 2. Add a Range Extender as a Satellite Device 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > EasyMesh, and enable EasyMesh.

  • Page 91: Manage Devices In The Easymesh Network

    • To view mesh devices and connected clients in the network: 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Network Map. 3. Click to view all mesh devices, and click to view all connected clients.
  • Page 92 • Back up your router’s configurations before firmware update. • Do NOT turn off the router during the firmware update. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > System > Firmware Update.

  • Page 93: Backup & Restore

    1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router.
  • Page 94 RESTORE. 2. Wait a few minutes for the restoring and rebooting. To reset the router except your login password and Mercusys ID: 1. In the Factory Default Restore section, click RESTORE. 2. Wait a few minutes for the resetting and rebooting.

  • Page 95: Change Password

    • We strongly recommend you back up the current configuration settings before resetting the router. 4. 13. 3. Change Password 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > System > Administration, and focus on the Change Password section.

  • Page 96: Local Management

    4. 13. 5. Local Management 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > System > Administration, and focus on the Local Management section.
  • Page 97 Chapter 4 Configure the Router in Wireless Router Mode • Allow all LAN connected devices to manage the router: Select All Devices for Local Managers. • Allow specific devices to manage the router: 1. Select Specified Devices for Local Managers and click SAVE. 2.

  • Page 98: Remote Management

    Chapter 4 Configure the Router in Wireless Router Mode 4. 13. 6. Remote Management 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > System > Administration, and focus on the Remote Management section.

  • Page 99: System Log

    4. 13. 7. System Log 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > System > System Log, and you can view the logs of the router.
  • Page 100 Chapter 4 Configure the Router in Wireless Router Mode 3. Click SAVE TO LOCAL to save the system logs to a local disk. 4. If you want to send the system log to your mailbox, click MAIL LOG and configure the mail settings.

  • Page 101: Diagnostics

    Diagnostic is used to test the connectivity between the router and the host or other network devices. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > System > Diagnostics.

  • Page 102: Time

    The router can automatically update the time from an NTP server via the internet. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > System > Time & Language.
  • Page 103 Chapter 4 Configure the Router in Wireless Router Mode 1. In the System Time section, select the way in which the router gets its time: Get from Internet, Get from Managing Device, Manually. 2. Select your local Time Zone. 3. Enter the address or domain of the NTP Server I or NTP Server II. 4.

  • Page 104: Language

    4. 13. 10. Language This function allows you to set the language for the system. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > System > Time & Language.

  • Page 105: Led Control

    The LED of the router indicates its activities and status. You can enable the Night Mode feature to specify a time period during which the LED is off. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router.

  • Page 106: Cwmp Settings

    You may configure this function under your ISP’s instructions. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to Advanced > System > CWMP Settings.
  • Page 107 Chapter 4 Configure the Router in Wireless Router Mode • CWMP - Toggle on to enable the CWMP function. • Inform - Enable to send an inform message to the ACS periodically. • Inform Interval - Enter the time interval when the Inform message will be sent to the ACS. The default value is 3600 seconds.

  • Page 108: Chapter 5. Configure The Router In Access Point Mode

    • LED Control 5. 1. Operation Mode 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to System > Operation Mode. 3. Select the working mode as needed and click SAVE.

  • Page 109: Quick Setup

    Configure the Router in Access Point Mode 5. 2. Quick Setup 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to System > Quick Setup. 3. Follow the step-by-step instructions to complete the setup.
  • Page 110 Chapter 5 Configure the Router in Access Point Mode To allow specific device(s): 1 ) Select Allow List and click SAVE. 2 ) Add devices to the list. • Add connected devices Click Select From Device List and select the devices you want to be allowed. •...

  • Page 111: Firmware Upgrade

    • Back up your router’s configurations before firmware update. • Do NOT turn off the router during the firmware update. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to System > Firmware Update.

  • Page 112: Backup & Restore

    1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router.
  • Page 113 Chapter 5 Configure the Router in Access Point Mode To backup configuration settings: Click BACK UP to save a copy of the current settings in your local computer. A “.bin“ file of the current settings will be stored in your computer. To restore configuration settings: 1.

  • Page 114: Administration

    Administration 5. 6. 1. Change Password 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to System > Administration, and focus on the Change Password section. 3. Enter the old password, then a new password twice (both case-sensitive). Click SAVE.

  • Page 115: Local Management

    5. 6. 3. Local Management 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to System > Administration, and focus on the Local Management section.

  • Page 116: System Log

    Connected Devices list, or enter the MAC address of the device manually. 4. Specify a Description for this entry. 5. Click SAVE. 5. 7. System Log 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router.
  • Page 117 Chapter 5 Configure the Router in Access Point Mode 2. Go to System > System Log, and you can view the logs of the router. 3. Click SAVE TO LOCAL to save the system logs to a local disk. 4. If you want to send the system log to your mailbox, click MAIL LOG and configure the mail settings.

  • Page 118: Diagnostics

    Diagnostic is used to test the connectivity between the router and the host or other network devices. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to System > Diagnostics.

  • Page 119: Time

    This function allows you to set the time manually or to configure automatic time synchronization. The router can automatically update the time from an NTP server via the internet. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router.
  • Page 120 Chapter 5 Configure the Router in Access Point Mode 2. Go to System > Time & Language. • To set System Time: 1. In the System Time section, select the way in which the router gets its time: Get from Internet, Get from Managing Device, Manually.

  • Page 121: Language

    5. 10. Language This function allows you to set the language for the system. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router. 2. Go to System > Time & Language.

  • Page 122: Led Control

    The LED of the router indicates its activities and status. You can enable the Night Mode feature to specify a time period during which the LED is off. 1. Visit http://mwlogin.net, and log in with your Mercusys ID or the password you set for the router.

  • Page 123: Faq

    Q1. What should I do if I forget my wireless password? The default wireless password is printed on the bottom label of the router. If the password has been altered, please connect your computer to the router using an Ethernet cable and follow the steps below: 1.
  • Page 124 4 ) Click LAN settings and deselect the following three options, and click OK. 5 ) Go to Advanced > Restore advanced settings, and click OK.
  • Page 125 • Use another web browser or computer to log in again. • Reset the router to factory default settings and try again. If the login still fails, please contact the technical support. Note: You’ll need to reconfigure the router to surf the internet once the router is reset. Q4.
  • Page 126 Note: Mercusys routers use 192.168.1.1 as their default LAN IP address. It may conflict with the IP range of your existent ADSL modem/router. If so, the router is not able to communicate with your modem and cause you can’t access the Internet. To resolve this problem, we need to change the LAN IP address of the router to avoid such conflict, for example, 192.168.2.1.
  • Page 127 • Restart the modem and the router. 1 ) Power off your modem and the router, and leave them off for 1 minute. 2 ) Power on your modem first, and wait about 2 minutes. 3 ) Power on the router, and wait another 1 or 2 minutes and check the internet access.
  • Page 128 2 ) Exit the wireless configuration tool (the Mercusys Utility, for example). 3 ) Select and right click My Computer on Desktop, and select Manage to open Computer Management window.
  • Page 129 2 ) If you cannot find the PIN or PIN failed, you may choose Connecting using a security key instead, and then type in the Wireless Password/Network Security Key. 3 ) If it continues to show note of Network Security Key Mismatch, it is suggested to confirm the wireless password of your wireless router.

Table of Contents

Save PDF
