EGO BCX4500 Operator's Manual

56 volt lithium-ion commercial brushcutter
Hide thumbs Also See for BCX4500:
Table of Contents

Advertisement

Quick Links

COMMERCIAL
OPERATOR'S MANUAL
56 VOLT LITHIUM-ION COMMERCIAL
BRUSHCUTTER
MODEL NUMBER BCX4500
WARNING: To reduce the risk of injury, the user must read and understand the
Operator's Manual before using this product. Save these instructions for future reference.
MNL_EGO_BCX4500_AV01.01_230609

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCX4500 and is the answer not in the manual?

Questions and answers

Related Manuals for EGO BCX4500

Summary of Contents for EGO BCX4500

  • Page 1 COMMERCIAL OPERATOR’S MANUAL 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER MODEL NUMBER BCX4500 WARNING: To reduce the risk of injury, the user must read and understand the Operator’s Manual before using this product. Save these instructions for future reference. MNL_EGO_BCX4500_AV01.01_230609...
  • Page 2 Speed Indicator Battery Status Indicator Bluetooth Button ® SPEED Speed Mode Button Power Head Shoulder Strap Loop Lock-off Lever Electric Contacts Trigger Switch Latch Battery Ejector Wing Bolt Battery-Release Button Bike Handle Sealing Screw Gear Case Shaft Shaft-locking Hole Guard Outer Flange 3-tooth Blade Strap Buckle...
  • Page 3 Clamp Wire Loop Blade Sheath Blade Motor Shaft 3-tooth Blade Inner Flange Flange Cover Gear Case Outer Flange Motor Shaft Slot in the Inner FLange Aligned Shaft-locking Holes Inner FLange Bulge Allen Key Outer Flange...
  • Page 4 Mouting Slot...
  • Page 5 Speed Mode Button Speed Indicator Battery- Bluetooth ® Status Indicator SPEED Indicator Lock-off Lever Speed Mode Button Trigger Switch Motor Shaft 3-tooth Blade Inner Flange Flange Cover Outer Flange Slot in the Inner FLange Inner Flange Bulge Motor Shaft Outer Flange Flange Cover Flange...
  • Page 6 Trimmer Head Hex Key Upper Cover String Trimmer Guard Icon Brushcutter Guard Motor Shaft 3-tooth Blade Sealing Screw Inner Flange Gear Case Flange Cover Outer Flange Shaft-locking Hole Slot in the Inner FLange...
  • Page 7 Power Head Sealing Screw...

  • Page 8: Safety Instructions

    We recommend a Wide Vision Safety Mask bystanders machine and bystanders be for use over eyeglasses or standard safety glasses with shall be at at least 15 m. side shields. least 15 m. Guaranteed sound power Noise level. 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...
  • Page 9 Bluetooth SIG, inc. (GFCI) protected supply. Use of a GFCI reduces the and any use of such marks by EGO is under license. risk of electric shock. GENERAL MACHINE SAFETY WARNINGS Personal safety ◾...
  • Page 10 Never service damaged battery packs. Service ◾ Use the machine, accessories and machine bits of battery packs should only be performed by the etc. in accordance with these instructions, taking manufacturer or authorized service providers. 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...
  • Page 11 Only use replacement cutters, lines, cutting heads machine. Holding the machine with both hands will and blades specified by the manufacturer. Incorrect avoid loss of control. replacement parts may increase the risk of breakage and injury. 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...

  • Page 12: Specifications

    Blade thrust can increase the risk of injury due to the machine moving unexpectedly. Blade thrust Brushcutter blade ABB1203-2 can be controlled by the operator if proper precautions are taken. ◾ If the blade binds, or when interrupting a cut 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...

  • Page 13: Packing List

    Any such alteration or modification is NOTICE: The string trimmer guard is not included (EGO misuse and could result in a hazardous condition leading AD4500, sold separately). to possible serious personal injury.

  • Page 14: Operation

    Wear heavy, long pants, boots and gloves. Do not wear loop fixed on the shaft (Fig. F2). short pants or sandals or go barefoot. 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...

  • Page 15: Using The Brushcutter

    In the event WARNING: Always remove the battery pack from the an unexpected object or woody stock is encountered, this machine during work breaks and after finishing work. practice could minimize the blade thrust reaction. 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...
  • Page 16 The machine is overheated. Cool the machine Speed indicator Solid orange until the temperature drops below 80°C. See (the illustration “Machine High-Temperature Protection” below. shows the high speed) The machine is overloaded. See “Machine Flashing orange Overload Protection” below. 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...
  • Page 17 This brushcutter can be converted into a string trimmer overheating damage. The battery-status indicator will using the EGO kit AH3810 (Sold Separately). The glow solid orange. Release the trigger and wait until the required steps are: overheated battery cools down and the indicator turns ◾...

  • Page 18: Line Replacement

    (Fig. K2). to the ground. Do not force the trimmer. Allow the very 3. Install the strimmer guard included in the EGO kit tip of the line to do the cutting (especially along walls). Cutting with more than the tip will reduce cutting AH3810 with the two bolts and washers from the efficiency and may overload the motor.

  • Page 19: General Maintenance

    “MOUNTING THE BLADE” section. sheath on the blade before storing or transporting the machine. Use caution to avoid the sharp teeth of the blade (Fig. P). ◾ Clean the machine thoroughly before storing it. 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...

  • Page 20: Protecting The Environment

    If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being. 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...

  • Page 21: Troubleshooting

    “ LINE REPLACEMENT ” in manual for EGO kit AH3810. ◾ Remove the battery and pull the lines while ◾ The line is too short alternately pressing down on and releasing the bump head. 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...
  • Page 22 When trimming, the ◾ ◾ line-cutting blade on The line-cutting blade has become Sharpen the line-cutting blade with a file or the guard cannot cut dull. replace it with a new blade. the line 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...

  • Page 23: Warranty Policy

    The warranty applies to the original purchaser and applies only to purchases made from authorised EGO Dealers, which can be confirmed on the website store locator. For avoidance of doubt, 3rd party online stores such as eBay, Gumtree, Amazon, etc. are excluded.
  • Page 24 Commercial Tools: LBX6000, BCX3800, STX3800, HTX7500, CSX3000, PPX1000, PSX2500, PTX5100, BHX1001, STX4500, 5 years 2 years BCX4500, EDX2000, HTX5300-P, HTX5300-PA, LBPX8000 Commercial Backpack Battery: BAX1501 3 years 2 years Commercial Charger: CHX5500E 3 years 2 years 56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500...
