Summary of Contents for NEFF R8580X2ES
- Page 1 TUMBLE DRYER en Installation and operating instructions R8580X2ES...
- Page 2 Caution! To meet the high quality demands required by Neff, every tumble dryer that This signal word indicates a possibly leaves our factory is carefully checked to dangerous situation. Not heeding the ensure that it functions correctly and is in caution can cause property and/or perfect condition.
-
Page 3: Table Of Contents
Contents e n I n s t a l l a t i o n a n d o p e r a t i n g i n s t r u c t i o n s Intended use....4 Operating the appliance . -
Page 4: Intended Use
Intended use Intended use Safety instructions The following safety information This appliance is intended for private ■ I n t e n d e d u s e S a f e t y i n s t r u c t i o n s and warnings are provided to domestic use only. - Page 5 Safety instructions Do not allow children to Warning ■ clean or maintain this Risk of suffocation! appliance unsupervised. If allowed to play with the Keep children under 3 years packaging/plastic film or ■ and pets away from this packing components, children appliance.
-
Page 6: Installation
Safety instructions Installation Warning Risk of electric shock/fire/ Warning material damage/damage to Risk of electric shock/fire/ the appliance! material damage/damage to If the appliance's mains cable is the appliance! altered or damaged, this may If the appliance is not installed result in electric shock, short properly, this may lead to a circuiting or fire due to... -
Page 7: Operation
Safety instructions Incorrectly placing (stacking) Warning ■ this appliance on top of a Risk of injury! washing machine may result The appliance is very heavy. ■ in injury, material damage Lifting it may result in injury. and/or damage to the Do not lift the appliance on appliance. - Page 8 Safety instructions Do not use the appliance if During the last part of the ■ ■ industrial chemicals have drying cycle, the laundry in been used to clean the the drum is not heated laundry. (cooling cycle). This is to ensure that it remains at a Warning temperature at which it will...
- Page 9 Safety instructions If you operate the appliance Warning ■ without a fluff filter, or if the Risk of injury! fluff filter is defective, this If you support your weight/sit ■ may result in damage to the on the appliance door when appliance.
-
Page 10: Cleaning/Maintenance
Safety instructions If the appliance overheats, it Repairs and any other work ■ ■ may not be able to operate on the appliance must only properly, or this may result in be conducted by our material damage or damage customer service or by an to the appliance. - Page 11 Safety instructions Warning Risk of injury/material damage/damage to the appliance! The use of spare parts and accessories supplied by other brands is dangerous and may result in injury, material damage or damage to the appliance. For safety reasons, use genuine spare parts and accessories only.
-
Page 12: Environmental Protection
Environmental protection Energy-saving tips Environmental protection Spin the laundry before drying. ■ The drier the laundry, the shorter the drying time will be, thus Packaging/old appliance consuming less energy. E n v i r o n m e n t a l p r o t e c t i o n Load the dryer with the maximum ■... -
Page 13: Installation And Connection
Installation and connection Caution! Installation and Risk of injury connection As the dryer is heavy, you could ■ injure yourself by trying to lift it. Scope of delivery Do not lift the dryer on your own. I n s t a l l a t i o n a n d c o n n e c t i o n You could cut your hands on the ■... -
Page 14: Changing The Condensation Drain
Installation and connection The dryer is levelled using the Proceed as follows to change the ■ threaded feet. condensation drain: Remove the accessories from the Check the alignment of the Note: dryer drum. appliance with a spirit level and correct if necessary. Change the height by turning the appliance feet. - Page 15 Installation and connection Fasten the other end of the drain hose with the remaining accessories, depending on the connection situation (A, B or C). Caution! Accumulated water can be drawn back into the dryer and may cause material damage. Check that the water drains away from the wash basin quickly. The drain must not be sealed or blocked.
- Page 16 Installation and connection Pull out the condensation container Slide in the condensation container fully. until it clicks into place. Turn the condensation container The condensation is now discharged via 180° onto its underside and remove the drain hose into the waste-water the stopper that is fitted.Turn the system or into a wash basin condensation container back over...
-
Page 17: Optional Accessories
Installation and connection Optional accessories Transport and frost protection Order optional accessories from the Empty the condensate container. after-sales service: Select any programme using the programme selector. Washer-dryer stack connection set: Press the Start button. ■ To save space, the dryer can be Wait for 5 minutes. -
Page 18: The Main Points In Brief
The main points in brief The main points in brief T h e m a i n p o i n t s i n b r i e f Load the laundry and close Switch on the dryer. Select a programme and, the door. -
Page 19: Getting To Know Your Appliance
Getting to know your appliance Getting to know your appliance Dryer G e t t i n g t o k n o w y o u r a p p l i a n c e ( Condensate container 0 Control and display panel 8 Drum interior light (depending on the model) @ Dryer door... -
Page 20: Control Panel
Getting to know your appliance Control panel All buttons are sensitive and only need to be touched briefly. Note: ( Use the programme selector to switch the dryer on and off and to select the programme. 0 Programmes ~ Page 23. 8 Start button for starting or interrupting the programme ~ Page 25. -
Page 21: Display Panel
Getting to know your appliance Display panel Display panel Buttons in the display panel Anti-Crease selected. ” Fine adjustment of the dryness – level. ( Select the degree of dryness. Timed programme selected. 0 Select the drying time. "Ready in" time selected. 8 Select the Ready in time. -
Page 22: Laundry
Laundry Some detergents and care products, ■ Laundry e.g. starch or softeners, contain particles which may be deposited on P reparing the laundry the moisture sensor. This may impair L a u n d r y the sensor function and in Warning consequence the drying result. -
Page 23: Programmes And Buttons
Programmes and buttons Programmes and buttons Programmes P r o g r a m m e s a n d b u t t o n s Programme and fabrics Maximum load and programme settings/info Name of the programme The maximum load is based on the dry weight of the fabrics Which fabrics is the programme suitable for? Possible programme settings... - Page 24 Programmes and buttons Lana con cesto (Woollens in the basket) r 1.5 kg Fabrics made from wool or a wool blend that are suitable for tumble drying. Only dry the fabrics using the basket for woollens Note: ~ Page 26. Camisas/Blusas (Shirts/Blouses) ’...
-
Page 25: Buttons
Programmes and buttons Buttons Buttons Explanations and notes Not all buttons and their functions can be selected in all programmes. Note: Ajuste secado If the laundry is too damp after drying, you can finely adjust the dryness level e.g. (Degree of dry- Cupboard Dry. -
Page 26: Operating The Appliance
Operating the appliance Operating the appliance Loading laundry and O p e r a t i n g t h e a p p l i a n c e switching on the dryer The dryer must be correctly Note: positioned and connected, ~ Page 13. -
Page 27: Drying With The Basket For Woollens
Operating the appliance Drying with the basket for b) Pullover woollens Insert the feet of the basket for woollens into the holes on the fluff filter. c) Sports shoes Place sports shoes in the basket for woollens without the insert. Pull out the tongues of the shoes and remove the insoles or heel cushions. -
Page 28: Setting A Programme
Operating the appliance Place the insert or the sports shoes Setting a programme in the basket for woollens. If you have activated the Caution! Note: childproof lock, you must deactivate it Risk of material damage to before you can set a programme, see the fabrics. -
Page 29: Programme Sequence
Operating the appliance Programme sequence Cancelling the programme The programme status is indicated in The programme can be interrupted at the display field. any time; to pause, open the dryer door or press the Start button. e.g. Expected programme duration in hours and minutes. -
Page 30: Clean The Fluff Filter
Operating the appliance Clean the fluff filter Open both filters and remove all the fluff. During drying, fluff and hair from Note: the laundry is trapped by the fluff filter. If the fluff filter is blocked or dirty, this reduces the flow of air, which prevents the dryer from achieving its maximum performance. -
Page 31: Emptying The Condensate Container
Operating the appliance Emptying the condensate Pour out the condensation water. container Notes You can drain off the condensation ■ into the waste-water system using an optional condensation drain . For installation, see ~ Page 14. If you drain the condensation using ■... -
Page 32: Signal Setting
Signal setting The volume of the audible signal at Signal setting the end of the programme is shown in the display. You can change the following settings: S i g n a l s e t t i n g The spin speed that is used for ■... -
Page 33: Noises
Noises The condensation is pumped into > Noises the condensate container by a pump. This generates pumping noises. During drying, particularly in the N ote: N o i s e s initial phase, operation of the appliance results in noise from the compressor and pump. -
Page 34: Cleaning
Cleaning Cleaning the moisture sensor Cleaning The dryer is equipped with a Note: C leaning the dryer and the stainless-steel moisture sensor. The C l e a n i n g control panel moisture sensor measures how damp the laundry is. After long periods of usage the moisture Warning sensor may become covered by a fine... -
Page 35: Cleaning The Filter In The Condensate Container
Cleaning Cleaning the filter in the condensate container The filter in the condensate Note: container cleans the condensation water that is used during the dryer's automatic cleaning cycle. Pull out the condensate container horizontally. Pour out the condensation water. Remove the filter. Clean the filter under warm, running water or in the dishwasher. -
Page 36: Faults And What To Do About Them
Faults and what to do about them Faults and what to do about them F a u l t s a n d w h a t t o d o a b o u t t h e m Faults Cause/remedy ð... - Page 37 Faults and what to do about them Faults Cause/remedy Drying time too long? The fluff filter may be dirty and cause a longer drying time. Clean the fluff fil- ■ ter. If the air inlet on the dryer is blocked or not freely accessible, this may ■...
-
Page 38: After-Sales Service
After-sales service After-sales service After-sales service A f t e r - s a l e s s e r v i c e If you cannot rectify the fault yourself (faults, what to do?), please contact our after-sales service. We will always find an appropriate solution to avoid unnecessary visits by engineers. -
Page 39: Consumption Values
Consumption values Consumption values Consumption values table C o n s u m p t i o n v a l u e s Programme Spin speed used for Duration** Energy consumption** spinning the laundry Cottons 8 kg 4 kg 8 kg 4 kg Cupboard Dry*... -
Page 40: Technical Data
Technical data Technical data Dimensions: T e c h n i c a l d a t a 85 x 60 x 60 cm Height x width x depth Weight: Approx. 56 kg Maximum load: 8 kg Condensate container: 4.6 l Connected voltage: 220 - 240 V Connected load:... - Page 44 Repair order and advice in the event of faults 0344 892 8989 Calls charged at local or mobile rate. 01450 2655 0.03 € per minute at peak. Off peak 0.0088 € per minute. You can find the contact information for all countries in the attached after-sales service directory: *9001170073*...
