Summary of Contents for NEFF R8581X2ES
- Page 1 TUMBLE DRYER en Installation and operating instructions R8581X2ES...
- Page 2 Your new tumble dryer Display rules : Warning! You have opted for a tumble dryer manufactured by Constructa. This combination of symbol and signal word indicates a possibly dangerous Please take a few minutes to read and situation. Not heeding the warning can become familiar with the advantages of cause death or injuries.
-
Page 3: Table Of Contents
Contents e n I n s t a l l a t i o n a n d o p e r a t i n g i n s t r u c t i o n s Drying with the basket Intended use. -
Page 4: Intended Use
Intended use Intended use Safety instructions The following safety information This appliance is intended for private ■ I n t e n d e d u s e S a f e t y i n s t r u c t i o n s and warnings are provided to domestic use only. - Page 5 Safety instructions Do not allow children to Warning ■ clean or maintain this Risk of suffocation! appliance unsupervised. If allowed to play with the Keep children under 3 years packaging/plastic film or ■ and pets away from this packing components, children appliance.
-
Page 6: Installation
Safety instructions The mains plug must be Installation ■ freely accessible at all times. Warning If this is not possible, in Risk of electric shock/fire/ order to comply with the material damage/damage to relevant safety regulations, a the appliance! switch (2-pole switch-off) If the appliance is not installed must be built into the properly, this may lead to a... - Page 7 Safety instructions Incorrectly placing (stacking) Warning ■ this appliance on top of a Risk of fire/material damage/ washing machine may result damage to the appliance! in injury, material damage The use of extension cords or and/or damage to the power strips may result in fire appliance.
-
Page 8: Operation
Safety instructions Warning Operation Risk of injury! Warning The appliance is very heavy. ■ Risk of explosions/fire! Lifting it may result in injury. Laundry that has come into Do not lift the appliance on contact with solvents, oil, wax, your own. wax remover, paint, grease or The appliance has sharp Ri s k of i n j u ry! - Page 9 Safety instructions If there is coal dust or flour in Warning ■ the air around the appliance, Risk of poisoning/material this may cause an explosion. damage! Make sure that the area Condensation water is not around the appliance is kept suitable for drinking and may clean when it is in operation.
-
Page 10: Cleaning/Maintenance
Safety instructions If you pour the wrong Caution! ■ quantity of detergent or Material damage/damage to cleaning agent into the the appliance appliance, this may result in If the amount of laundry in ■ material damage or damage the appliance exceeds its to the appliance. - Page 11 Safety instructions When removing the mains Warning ■ plug from the socket, always Risk of injury/material take hold of the plug itself damage/damage to the and never the mains cable, appliance! otherwise this may damage The use of spare parts and the mains cable.
-
Page 12: Environmental Protection
Environmental protection Energy-saving tips Environmental protection Spin the laundry before drying. ■ The drier the laundry, the shorter the drying time will be, thus Packaging/old appliance consuming less energy. E n v i r o n m e n t a l p r o t e c t i o n Load the dryer with the maximum Dispose of packaging in an ■... -
Page 13: Installation And Connection
Installation and connection You could cut your hands on the ■ Installation and sharp edges of the dryer. Do not hold the dryer by the sharp edges. connection Protruding parts on the dryer may ■ break off when it is lifted or pushed. Scope of delivery Do not move the dryer by holding on I n s t a l l a t i o n a n d c o n n e c t i o n... -
Page 14: Optional Accessories
Installation and connection Optional accessories Transport and frost protection Order optional accessories from the Empty the condensate container. after-sales service: Select any programme using the programme selector. Washer-dryer stack connection set: Press the Start button. ■ To save space, the dryer can be Wait for 5 minutes. -
Page 15: The Condensation Water
Draining the condensation water Disconnect the hose from the ΠDraining the connecting piece and put it in the "parked" position. condensation water Condensation will form in the appliance D r a i n i n g t h e c o n d e n s a t i o n w a t e r as it dries the laundry. - Page 16 Draining the condensation water Take the drain hose from the accessories and secure it to the free connecting piece. Fasten the other end of the drain hose with the remaining accessories, depending on the connection situation (A, B or C). Caution! Accumulated water can be drawn back into the dryer and may cause material damage.
- Page 17 Draining the condensation water Pull out the condensation container Slide in the condensation container fully. until it clicks into place. Turn the condensation container The condensation is now discharged via 180° onto its underside and remove the drain hose into the waste-water the stopper that is fitted.Turn the system or into a wash basin condensation container back over...
-
Page 18: The Main Points In Brief
The main points in brief The main points in brief T h e m a i n p o i n t s i n b r i e f Load the laundry and close Switch on the dryer. Select a programme and, the door. -
Page 19: Getting To Know Your Appliance
Getting to know your appliance Getting to know your appliance Dryer G e t t i n g t o k n o w y o u r a p p l i a n c e ( Condensate container 0 Control and display panel 8 Drum interior light (depending on the model) @ Dryer door... -
Page 20: Control Panel
Getting to know your appliance Control panel ( Use the programme selector to switch the dryer on and off and to select the programme. 0 Programmes ~ Page 23. 8 Start button for starting or interrupting the programme ~ Page 25. @ Buttons ~ Page 25. -
Page 21: Display Panel
Getting to know your appliance Display panel Display panel Buttons in the display panel Anti-Crease selected. ë Fine adjustment of the dryness ê level. ( Select the degree of dryness. Timed programme selected. 0 Select the drying time. "Ready in" time selected. 8 Select the Ready in time. -
Page 22: Laundry
Laundry – Clean the moisture sensor Laundry regularly ~ Page 34. P reparing the laundry Sorting washing according to: L a u n d r y Warning c Suitable for tumble drying Risk of explosion/fire! a Dry at normal temperature Remove any cigarette lighters and ` Dry at low temperature matches from pockets. -
Page 23: Programmes And Buttons
Programmes and buttons Programmes and buttons Programmes P r o g r a m m e s a n d b u t t o n s Programme and fabrics Maximum load and programme settings/info Name of the programme The maximum load is based on the dry weight of the fabrics Which fabrics is the programme suitable for? Possible programme settings... - Page 24 Programmes and buttons Secado con cesto (Woollens in the basket) r 1.5 kg Fabrics made from wool or a wool blend that are suitable for tumble drying. Only dry the fabrics using the basket for woollens Note: ~ Page 26. Camisas/Blusas (Shirts/Blouses) ’...
-
Page 25: Buttons
Programmes and buttons Buttons Buttons Explanations and notes Not all buttons and their functions can be selected in all programmes. Note: Ajuste secado If the laundry is too damp after drying, you can finely adjust the dryness level e.g. (Degree of dry- Cupboard Dry. -
Page 26: Operating The Appliance
Operating the appliance Operating the appliance Loading laundry and O p e r a t i n g t h e a p p l i a n c e switching on the dryer The dryer must be correctly Note: positioned and connected, ~ Page 13. - Page 27 Operating the appliance Lean the basket for woollens against c) Sports shoes the upper notch. Place sports shoes in the basket for woollens without the insert. Pull out the tongues of the shoes and remove the insoles or heel cushions. Roll up a towel and place it under the sports shoes to create an inclined surface.
-
Page 28: Setting A Programme
Operating the appliance Use the programme selector to Use the programme selector to set select the programme for the basket the required programme. The default for woollens or a time programme. programme settings for the selected Set the drying time. programme appear in the display Thin woollen pullover: panel. -
Page 29: Starting The Programme
Operating the appliance Starting the programme Changing the programme or adding laundry Press the Start button. You can remove or add laundry and If you want to lock the Note: change or alter the programme at any programme to prevent it from being time during drying. -
Page 30: Removing Laundry And Switching Off The Dryer
Operating the appliance Removing laundry and Pull apart the two-part fluff filter. switching off the dryer Remove the laundry. Turn the programme selector to the "off" position. Open both filters and remove all the fluff. Clean the fluff filter During drying, fluff and hair from Note: the laundry is trapped by the fluff filter. -
Page 31: Emptying The Condensate Container
Operating the appliance Emptying the condensate Push in the condensate container until you feel it lock back into place container in the dryer. By default, the condensation from the appliance runs into the condensation container. Alternatively, you have the option of discharging the condensation water supplied depending on the model. -
Page 32: Signal Setting
Signal setting The volume of the audible signal at Signal setting the end of the programme is shown in the display. You can change the following settings: S i g n a l s e t t i n g The spin speed that is used for ■... -
Page 33: Noises
Noises The condensation is pumped into > Noises the condensate container by a pump. This generates pumping noises. During drying, particularly in the N ote: N o i s e s initial phase, operation of the appliance results in noise from the compressor and pump. -
Page 34: Cleaning
Cleaning Cleaning the moisture sensor Cleaning The dryer is equipped with a Note: C leaning the dryer and the stainless-steel moisture sensor. The C l e a n i n g control panel moisture sensor measures how damp the laundry is. After long periods of usage the moisture Warning sensor may become covered by a fine... -
Page 35: Cleaning The Filter In The Condensate Container
Cleaning Cleaning the filter in the condensate container The filter in the condensate Note: container cleans the condensation water that is used during the dryer's automatic cleaning cycle. Pull out the condensate container horizontally. Pour out the condensation water. Remove the filter. Clean the filter under warm, running water or in the dishwasher. -
Page 36: Faults And What To Do About Them
Faults and what to do about them Faults and what to do about them F a u l t s a n d w h a t t o d o a b o u t t h e m Faults Cause/remedy ë... - Page 37 Faults and what to do about them Faults Cause/remedy Drying time too long? The fluff filter may be dirty and cause a longer drying time. Clean the fluff fil- ■ ter. If the air inlet on the dryer is blocked or not freely accessible, this may ■...
-
Page 38: After-Sales Service
After-sales service After-sales service After-sales service A f t e r - s a l e s s e r v i c e If you cannot rectify the fault yourself (faults, what to do?), please contact our after-sales service. We will always find an appropriate solution to avoid unnecessary visits by engineers. -
Page 39: Consumption Values
Consumption values Consumption values Consumption values table C o n s u m p t i o n v a l u e s Programme Spin speed used for Duration** Energy consumption** spinning the laundry Cottons 8 kg 4 kg 8 kg 4 kg Cupboard Dry*... -
Page 40: Technical Data
Technical data Technical data Dimensions: T e c h n i c a l d a t a 85 x 60 x 60 cm Height x width x depth Weight: Approx. 56 kg Maximum load: 8 kg Condensate container: 4.6 l Connected voltage: 220 - 240 V Connected load:... - Page 44 Repair order and advice in the event of faults 0344 892 8989 Calls charged at local or mobile rate. 01450 2655 0.03 € per minute at peak. Off peak 0.0088 € per minute. You can find the contact information for all countries in the attached after-sales service directory: *9001288275*...
