- Page 1 LED TV UF67** www.lg.com (M4 X L14) P/No: MFL68762112 (1504-REV01) Printed in Korea...
- Page 5 ANTENNA / CABLE IN OPTICAL DIGITAL AUDIO OUT MONO AUDIO VIDEO MONO...
- Page 7 40UF673T-TK 43UF673T-TK 49UF673T-TK 55UF673T-TK 65UF673T-TK 40UF673Y-TK 43UF673Y-TK 49UF673Y-TK 55UF673Y-TK 65UF673Y-TK 906 x 576 x 218 971 x 625 x 218 1104 x 704 x 261 1240 x 781 x 261 1460 x 903 x 273 (mm) 906 x 524 x 56.7 971 x 570 x 56.4...
- Page 9 OWNER’S MANUAL Safety and Reference LED TV* * Disclaimer LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. www.lg.com *MFL68761002* P/NO : MFL68761002 (1504-REV03) Printed in Korea...
- Page 10 India region only. (Below sentence is not applicable for above 1920 X 1080 resolution TV models.) ATTENTION: This product is qualified for the BEE Star rating in the ‘Home’ Mode. The Objectives of Star Labeling Program is designed to promote energy efficient products and practices. When the television is initially set up, it is designed to meet the BEE Star Labeling requirements while maintaining optimum picture quality.
-
Page 11: Safety Instructions
Safety instructions Please read these safety precautions carefully before using the product. Make sure to connect Mains cable to compliant AC mains socket with WARNING Grounded earth pin. (Except for devices which are not grounded on earth.) Otherwise possibility you may be electrocuted or injured. Do not place the TV and/or remote control in the following Insert power cable plug completely into wall socket otherwise if not environments:... - Page 12 Do not plug too many electrical devices into a single multiple electrical Do not put or store inflammable substances near the product. There is a outlet. Otherwise, this may result in fire due to over-heating. danger of combustion/explosion or fire due to careless handling of the inflammable substances.
- Page 13 Only use an authorized AC adapter and power cord approved by discretion. Fire or electric shock accident can occur. LG Electronics. Otherwise, this may result in fire, electric shock, Contact the service centre for check, calibration or repair. malfunction or product deformation.
- Page 14 Batteries should not be exposed to excessive heat. For example, keep away from direct Sunlight , open fireplace and electric heaters . Do not place non-rechargeable batteries in charging device. If you install the TV on a stand, you need to take actions to prevent the product from overturning.
- Page 15 Take care not to touch the ventilation openings when watching the TV When cleaning the product and its components, unplug the power for long periods as the ventilation openings may become hot. This does first and wipe it with a soft cloth. Applying excessive force may cause not affect the operation or performance of the product.
- Page 16 Refer all servicing to qualified service personnel. Servicing is required Displaying a still image (e.g., broadcasting channel logo, on-screen when the apparatus has been damaged in any way, such as power menu, scene from a video game) for a prolonged time may cause supply cord or plug is damaged, liquid has been spilled or objects have damage to the screen, resulting in retention of the image, which is fallen into the apparatus, the apparatus has been exposed to rain or...
-
Page 17: Viewing 3D Imaging (Only 3D Models)
Symptoms which require discontinuation or refraining from watching 3D contents • Make sure to use LG 3D glasses. Otherwise, you may not be able to view 3D videos properly. • Do not watch 3D contents when you feel fatigue from lack of sleep, • ... -
Page 18: Separate Purchase
And the TV should be turned off if it will not be watched for some time, as this will reduce energy consumption. LG Audio Device • The energy consumed during use can be significantly reduced if the level of brightness of the picture is reduced, and this will reduce the overall running cost. -
Page 19: Lifting And Moving The Tv
Lifting and moving the TV Using the joystick button Please note the following advice to prevent the TV from being scratched (Image shown may differ from your TV.) or damaged and for safe transportation regardless of its type and size. You can simply operate the TV functions, pressing or moving the joystick • ... -
Page 20: Mounting On A Table
Using the kensington security NOTE system • When your finger over the joystick button and push it to the up, down, left or right, be careful not to press the joystick button. If you (This feature is not available for all models.) press the joystick button first, you may not be able to adjust the • ... -
Page 21: Mounting On A Wall
LG recommends that wall mounting be performed by a qualified professional installer. We recommend the use of LG’s wall mount bracket. When you do not use LG’s wall mount CAUTION bracket, please use a wall mount bracket where the device is adequately • ... -
Page 22: Connections (Notifications)
Connections (notifications) • This feature improves the sensitivity to weak RF Signal in poor reception areas. LG’s built-in booster is auto-activated at weak signal level. It strengthens signal level and minimizes picture Connect various external devices to the TV and switch input modes to colour noise. -
Page 23: Ci Module Connection
4K @ 50/60 Hz Support Format Colour Depth / Frame rate Chroma Sampling Resolution (Hz) 8 bit 10 bit 12 bit YCbCr 4:2:0 YCbCr 4:2:0 50.00 YCbCr 4:2:2 3840 x 2160p 59.94 4096 x 2160p YCbCr 4:4:4 60.00 RGB 4:4:4 1 : Only supported when HDMI ULTRA HD Deep Colour turned “On”. - Page 24 Licenses Supported licenses may differ by model. For more information about licenses, visit www.lg.com. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
-
Page 25: Open Source Software Notice
• The ISF function is only available on some models. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such... - Page 26 To set additional picture options To use HDMI ULTRA HD Deep Colour SETTINGS PICTURE Picture Mode Picture Option SETTINGS PICTURE HDMI ULTRA HD Deep Colour HDMI (1/2) ULTRA HD Deep Colour [Depending on model] [Depending on model] Adjusts detailed setting for images. HDMI port provides ULTRA HD Deep Colour, You can watch more clear • ...
- Page 27 Connect LG audio device with the logo to the optical digital • Disc playback : Manages the multimedia device with the TV audio output port. LG audio device allows you to enjoy rich powerful remote control. sound easily. • Power off all devices : When you power off the TV, all connected devices are turned off.
-
Page 28: Supported Video Formats
Using a USB storage device - warning • .mkv [Video] MPEG-2, MPEG-4 Part2, DivX3.11, DivX4, DivX5, DivX6, • If the USB storage device has a built-in auto recognition program or XVID, H.264/AVC uses its own driver, it may not work. [Audio] HE-AAC, Dolby Digital, MPEG-1 Layer III (MP3), *DTS, LPCM • ... -
Page 29: To See Web Manual
When connecting to the PC (HDMI), ‘No signal’ or ‘Invalid Format’ is displayed. • Turn the TV off/on using the remote control. To obtain detailed User Guide information, please visit www.lg.com. • Reconnect the HDMI cable. • Restart the PC with the TV on. -
Page 30: Specifications
Specifications 32LF51** 43/49LF51** Manufacturer : Lien Chang Model : LCAP25B Manufacturer : Honor Manufacturer : Lien Chang Model : ADS-45EI-19 19040GPI, Model : LCAP40 AC/DC Adapter ADS-40LSI-19-2 19040G, Manufacturer : APD ADS-45SN-19-2 19040G Model : DA-65F-19 Manufacturer : APD Model : WA-40D19FI In : AC 100 - 240 V ~ 50/60 Hz In : AC 100 - 240 V ~ 50/60 Hz Out : DC 19 V... - Page 31 3D supported mode (Only 3D models) Video, which is input as below media contents is switched into the 3D screen automatically. The method for 3D digital broadcast may differ depending on the signal environment. If video is not switched automatically into 3D, manually convert the settings to view 3D images.
- Page 32 HDMI-DTV supported mode HDMI-PC supported mode Use HDMI IN 1 for PC mode (Except for UF67**) Vertical Horizontal Resolution Frequency Frequency (kHz) (Hz) Horizontal Vertical Resolution 31.46 59.94 Frequency (kHz) Frequency (Hz) 640 x 480 31.50 60.00 640 x 350 31.46 70.09 31.47...
-
Page 33: Environmental Information
5. To locate a nearest collection centre or call for pick-up (limited area only) for disposal of this appliance, please contact Toll Free No. 1800-180-9999 for details. All collection centre and pick up facilities are done by third parties whith LG Electronics India Pvt. Ltd. merely as a facilitator. For more... - Page 36 Record the model number and serial number (Only DTV) of the TV. Refer to the label on the back cover and quote this information to your dealer when requiring any service. MODEL SERIAL...
-
Page 37: External Control Device Setup
OWNER’S MANUAL EXTERNAL CONTROL DEVICE SETUP Please read this manual carefully before operating the set and retain it for future reference. www.lg.com... -
Page 38: Key Codes
KEY CODES kEy CODES • This feature is not available for all models. Code Code Function Note Function Note (Hexa) (Hexa) CH +, PR + R/C Button List R/C Button CH -, PR - R/C Button Exit R/C Button Volume + R/C Button PIP(AD) R/C Button... -
Page 39: Usb To Serial Converter With Usb Cable
(TV) (PC) • LGTV supports PL2303 chip-based (Vendor ID : 0x0557, Product ID : 0x2008) USB to serial converter RS-232C IN which is not made nor provided by LG. (CONTROL & SERVICE) (PC) (TV) • It can be purchased from computer stores that carry accessories for IT support professionals. -
Page 40: Customer Computer
EXTERNAL CONTROL DEVICE SETUP (TV) (PC) (TV) (PC) Phone jack Type RS-232C IN • You need to purchase the phone-jack to RS-232 cable required for the connection between the PC and (CONTROL & SERVICE) (PC) (TV) the TV, which is specified in the manual. RS-232C IN (CONTROL &... -
Page 41: Communication Parameters
EXTERNAL CONTROL DEVICE SETUP Communication Parameters • Baud rate : 9600 bps (UART) • Stop bit : 1 bit • Data length : 8 bits • Communication code : ASCII code • Parity : None • Use a crossed (reverse) cable. Command reference list (Depending on model) DATA... -
Page 42: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV. (j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the [Set ID] to choose desired monitor ID number in option menu. Adjustment range in TV is 1 to 99. - Page 43 EXTERNAL CONTROL DEVICE SETUP * Commands may work differently depending on model and signal. 01. Power (Command: k a) Ack [d][ ][Set ID][ ][OK/NG][Data][x] ► To control Power *On or Off of the set. * In case of video mute on only, TV will display On Transmission[k][a][ ][Set ID][ ][Data][Cr] Screen Display(OSD).
- Page 44 EXTERNAL CONTROL DEVICE SETUP Data Min : 00 to Max : 64 * (Depending on model) Ack [i][ ][Set ID][ ][OK/NG][Data][x] 14. Bass (Command: k s) 09. Tint (Command: k j) ► To adjust Bass. ► To adjust the screen tint. You can also adjust in the AUDIO menu.
- Page 45 EXTERNAL CONTROL DEVICE SETUP Set ID = All = 00 5th Band 20(decimal) Data 00 & 01 = Channel Data is 10 = 00 0a Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x] Data 02 = Analog Antenna TV = 00 Result = ma 00 00 0a 00 * It depends on model, and can adjust when sound mode is EQ adjustable value.
- Page 46 EXTERNAL CONTROL DEVICE SETUP Number Data 05 = Digital Antenna TV = 02 - 22 : Antenna TV (DTV) – Don’t Use Physical Total = ma 00 00 00 11 00 01 02 Channel Number - 26 : Cable TV (CADTV) - Don’t Use Physical 2.
- Page 47 11 11 EXTERNAL CONTROL DEVICE SETUP 24. Input select (Command: x b) (Main Picture Input) ► To select input source for main picture. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data X : don’t care 00 : DTV 01 : CADTV 02 : Satellite DTV 10 : ATV Ack [t][ ][Set ID][ ][OK][Data00][Data01][Data02] ISDB-BS (Japan)
- Page 48 EXTERNAL CONTROL DEVICE SETUP 27. Auto Configure (Command: j u) (Depending on model) ► To adjust picture position and minimize image shaking automatically. It works only in RGB (PC) mode. Transmission [j][u][ ][Set ID][ ][Data][Cr] Data 01 : To set Ack [u][ ][Set ID][ ][OK/NG][Data][x]...
