User Guide
Thermia AB
Box 950
SE 671 29 ARVIKA
Phone +46 570 81300
E-mail: info@thermia.se
Internet: www.thermia.se
www.thermia.no
www.thermia.fi
Thermia can accept no responsibility for possible errors in catalogues, brochures and other printed material. Thermia reserves the right to alter its products without notice. This also applies to products already
on order provided that such alterations can be made without subsequential changes being necessary in specifications already agreed. All trademarks in this material are property of the respective companies.
Thermia and the Thermia logotype are trademarks of Thermia AB. All rights reserved.
Aura T1/
AR**NXPD******
This appliance is filled with R-32.
Document produced by Thermia AB © 2018
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Thermia AR NXPD Series
Summary of Contents for Thermia AR NXPD Series
- Page 1 Thermia can accept no responsibility for possible errors in catalogues, brochures and other printed material. Thermia reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequential changes being necessary in specifications already agreed. All trademarks in this material are property of the respective companies.
- Page 2 User Guide User Guide Thermia Thermia Aura T1 AR**NXPD****** www.thermia.se www.thermia.se www.thermia.no www.thermia.no www.thermia.fi www.thermia.fi...
-
Page 3: Table Of Contents
Contents Product Specifications Product Specifications Safety Information Safety Information At a Glance Indoor Unit Overview Display Remote Control Overview Inserting batteries Remote Control Operation Operation modes Controlling temperature Controlling fan speed Controlling air flow direction Setting the Current time Power Smart Features Cooling Operation Cool mode 2-Step cooling function... - Page 4 Energy-Saving Features Energy-Saving Operation Electricity consumption check Single user function Timed on/Timed off function good’sleep function Cleaning and Maintenance Cleaning at a Glance Troubleshooting Information about refrigerant Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
-
Page 5: Product Specifications
Product Specifications Indoor unit AR12NXPDRWKNTH Cooling capacity Min./Nom./Max. 0.90/3.50/4.20 Heating capacity Min./Nom./Max. 0.80/4.00/7.30 Cooling Min./Nom./Max. 0.18/0.89/1.15 Power input Heating Min./Nom./Max. 0.15/0.94/2.28 Energy grade A+++ Pdesign Cooling SEER Annual energy consumption kWh Energy grade Pdesign Seasonal efficiency Heating SCOP (according to EN14825) (Average climate) Annual energy consumption kWh Energy grade... - Page 6 • T he original software version used for the product range is identified in this manual. For the software version issued at the time of manufacture, please refer to the mark plate of the indoor and outdoor units. The mark plate can be physically located on the side of both the indoor (Temperature display side) and outdoor units (Compressor side). In addition, for the current software version of the air conditioner Wi-Fi control application, please refer to the front screen of the application itself.
-
Page 7: Safety Information
If you have any questions, call your nearest contact centre or find help and information online at www. thermia.se WARNING Hazards or unsafe practices that may result in severe personal injury or death. - Page 8 • Failing to do so may result in electric shock, fire, explosion, problems with the product, or injury and may also void warranty on the installed product. Install an Isolation Switch next to the Air Conditioner (but not on the panels of the Air Conditioner) and circuit breaker dedicated to the air conditioner.
- Page 9 • Failing to do so may result in abnormal vibrations, noise, or problems with the product. Install the drain hose properly so that water drains correctly. • Failing to do so may result in water overflowing and property damage. Avoid adding drain to waste pipes as odours may arise in the future.
- Page 10 It is recommended that a skilled service technician be contacted for support. Should urgent support be required then, using the information provided, contact the local Thermia office via email or telephone. English...
- Page 11 • Since this may be dangerous due to a lack of oxygen, open a window at least once an hour. Do not use means to accelerate the defrost operation or to clean, other than those recommended by Thermia. Do not pierce or burn. Be aware that refrigerants may not contain an odour.
- Page 12 If any foreign substance such as water has entered the appliance, cut off the power supply and contact the nearest service centre. • Failing to do so may result in electric shock or fire. Do not attempt to repair, disassemble, or modify the appliance yourself.
- Page 13 During transportation of the indoor unit, the pipe lines shall be covered with brackets for protection. Do not move the product with holding the pipe lines. • It may cause gas leakage. Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
- Page 14 responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. For use in Europe : This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand...
-
Page 15: At A Glance
Indoor Unit Overview The actual product may differ slightly from the image depicted below. 01 Air intake 06 Wi-Fi module 02 Air filter 07 Plasma Ion Lamp 03 Air flow blade (up and down) 08 Display 04 Air flow blade (left and right) 09 Power button / Remote control receiver 05 Room temperature sensor... -
Page 16: Remote Control Overview
Remote Control Overview 01 Set temperature indicator 02 Timer option indicator 03 Operation mode indicator 04 Options indicator 05 Low battery indicator 06 Transmit indicator 07 Fan speed indicator 08 Vertical air swing indicator 09 Horizontal air swing indicator 10 Settings indicator 11 Power button 12 Temperature button 13 Options button... -
Page 17: Remote Control Operation
Remote Control Operation You can use the air conditioner easily by selecting a mode and then by controlling the temperature, fan speed, and air direction. Operation modes You can change the current mode between Auto, Cool, Dry, Fan, and Heat by pressing the button. -
Page 18: Controlling Fan Speed
Controlling fan speed You can select the following fan speeds in each mode: Mode Available fan speeds Auto/Dry (Auto) (Auto), (Low), (Med), (High), Cool/Heat (Turbo) (Low), (Med), (High), (Turbo) Controlling air flow direction Keep the air flow in a constant direction by stopping the movements of the vertical and horizontal air flow blades. -
Page 19: Power Smart Features
Cooling Operation The smart and powerful cooling functions of the Thermia Heat Pump keep an enclosed space cool and comfortable. Cool mode Use the Cool mode to stay cool in hot weather. ► ► Select Cool. NOTE • For comfort, keep the temperature difference between the indoor and outdoor air within 5 °C in the Cool mode. -
Page 20: Dehumidifying Operation
• You cannot use the Dry mode for heating. The Dry mode is designed to produce a cooling side-effect. Air Purifying Operation The air purification function of the Thermia Heat Pump keeps the air in an enclosed space purified. Plasma Ion function Use the Plasma Ion function to purify your room with positive ions produced by the air conditioner. -
Page 21: Heating Operation
Heating Operation The heating functions of the Thermia Heat Pump keep an enclosed space warm and comfortable. Heat mode Use the Heat mode to stay warm. ► ► Select Heat. NOTE • In heating mode, the air conditioner will heat your room. -
Page 22: Quick Smart Features
Quick Smart Features There is a variety of extra functionality provided by the Thermia Heat Pump. Auto mode Use the Auto mode when you want the air conditioner to automatically control the operation. The air conditioner will provide the most comfortable atmosphere that it can. -
Page 23: Fast Function
Fast function Use the Fast function to quickly cool or heat your room. This function is the most powerful cooling and heating function provided by the air conditioner. You can select this function both in the Cool and Heat modes. ►... -
Page 24: Quiet Function
Quiet function Use the Quiet function to reduce operating noise. You can select this function both in the Cool and Heat modes. ► ► ► In the Cool or Heat mode ► Select Quiet. NOTE • You can change the set temperature and the air flow direction. -
Page 25: Wi-Fi Function
Then both of them disappear. ► ► In operation Hold down 4 seconds. NOTE • For further information regarding Wi-Fi functionality and setup: Sweden: www.thermia.se > Aura T1 Finland: www.thermia.fi > Aura T1 Norway: www.thermia.no > Aura T1 24 English... - Page 26 Energy-Saving Operation The smart energy-saving functions of the Thermia Heat Pump reduce electricity consumption. Electricity consumption check Use the Usage function to check the amount of electricity consumed by using the air conditioner. The amount consumed is displayed on the indoor unit display for a few seconds, and the set indoor temperature appears.
- Page 27 Single user function Use the Single user function to reduce electricity consumption while staying cool or warm. You can select this function in the Cool and Heat modes. ► ► ► In the Cool or Heat mode ► Select Single user. NOTE • When the Single user function starts, the pattern...
- Page 28 Timed on/Timed off function Use the Timed on/Timed off to turn on or off the air conditioner after the time that you set. • Check the current time on the remote controller before using this function. • The default time is 1 AM on the remote controller. The current time is reset to default time after changing the batteries.
- Page 29 good’sleep function Use the good'sleep function to get a good sleep at night and to save energy. You can select this function both in the Cool and Heat modes. (Select among ► ► In the Cool or Heat mode On, Off, and (Set the ►...
- Page 30 Cleaning at a Glance Running Auto clean Select [Clean] The Auto clean function is activated. When operation is off, auto clean • The indoor unit display shows : starts for 10 min. • The indoor unit display shows cleaning progress (from 1 to 99%).
- Page 31 • Do not use sulphuric acid, hydrochloric acid, or organic solvents (such as thinner, kerosene, and acetone) to clean the surfaces. Do not put any stickers on it as this can damage the surface of the air conditioner. • When you clean and inspect the heat exchanger on the outdoor unit, contact the local service centre for help.
- Page 32 Resetting the filter-cleaning reminder Indoor unit display Troubleshooting If the air conditioner operates abnormally, refer to the following chart to save time and unnecessary expenses. Problem Solution • Check the power status, then operate the air conditioner again. • Switch on the circuit breaker, plug in the power The air cord, then operate the air conditioner again.
- Page 33 Problem Solution • Check whether the set temperature is higher in the Cool mode or lower in the Heat mode than the current temperature. Press the Temperature button on the remote control to change the set temperature. • Check whether the air filter is blocked with dirt.
- Page 34 Problem Solution • Check whether the good'sleep function is I cannot change running. While this function is running, you the air flow cannot control the air flow direction. (But you direction. can control the air flow direction if this function is running in the Heat mode.) • When the Auto, Dry, or Fast mode is running or the good'sleep function is running in the...
- Page 35 Problem Solution • Check whether the air conditioner is running in a smoky area. Ventilate the room or operate the air conditioner in the Fan mode for 3 to 4 Odours permeate hours. (There are no components used in the in the room air conditioner that emit a strong odour.) during operation.
- Page 36 Information about refrigerant CAUTION If the system contains 5 tCO e or more of fluorinated greenhouse gases, it must be checked for leakage at least once every 12 months, according to regulation No. 517/2014. This activity must be covered by qualified personnel only. In the case of the situation above, the installer (or authorized person with responsibility for final check) must provide a maintenance book, with all the information recorded, according to REGULATION (EU) No.
