Wahuda 50200PC-WHD User Manual

13” 2-speed portable planer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Read this manual before using machine to avoid serious injury and damage
50200PC-WHD
13" 2-Speed Portable Planer
With Spiral Style Cutterhead and 4-Sided Carbide Inserts
For technical support, email
or call at 877-568-8879
techservices@wahudatools.com
VER. 08.31.20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 50200PC-WHD and is the answer not in the manual?

Questions and answers

Related Manuals for Wahuda 50200PC-WHD

Summary of Contents for Wahuda 50200PC-WHD

  • Page 1 User Manual Read this manual before using machine to avoid serious injury and damage 50200PC-WHD 13” 2-Speed Portable Planer With Spiral Style Cutterhead and 4-Sided Carbide Inserts For technical support, email or call at 877-568-8879 techservices@wahudatools.com VER. 08.31.20...

  • Page 2: Table Of Contents

    The drawings, illustrations, photographs, and specifications in this user manual represent your machine at time of print. However, changes may be made to your machine or this manual at any time with no obligation to WAHUDA.

  • Page 3: Warranty

    2 YEAR LIMITED WARRANTY WAHUDA warrants its machinery to be free of defects in workmanship and materials for a period of two (2) years from the date of the original purchase by the original owner. This warranty applies to products sold in United States only. The warranty does not apply to any product used for professional or commercial production purposes nor for industrial or educational applications.

  • Page 4: Product Specifications

    PRODUCT SPECIFICATIONS 2 Speed Feed - High/ Low 26 FPM / 18 FPM Cutterhead speed RPM 10,000 Motor RPM 23000+/-10% (No Load) Cutterhead diameter 2” Max planer capacity 6" x 13" Max depth of cut @ 6” width 1/8" Max depth of cut @ 13” width 1/16"...

  • Page 5: General Safety

    GENERAL SAFETY NOTE: The WARNING! and CAUTION! symbols indicate a potentially hazardous situation which, if not avoided, COULD result in death or serious injury. READ THIS MANUAL completely before assembling and operating this machine. WARNING! TO AVOID serious injury, death, or damage to the machine, please read, understand, and follow, all Safety and Operating Instructions before assembling and operating this machine.
  • Page 6 GENERAL SAFETY (cont.) ALWAYS keep the work area clean, well lit, and organized. DO NOT work in an area that has slippery floor surfaces from debris, grease, and wax. CAUTION! ALWAYS unplug the machine from the electrical receptacle when making adjustments, changing parts or performing any maintenance.
  • Page 7 GENERAL SAFETY (cont.) KEEP protective guards in place and in working order. CAUTION! MAINTAIN your balance. DO NOT extend yourself over the tool. Wear oil resistant rubber soled shoes. Keep floor clear of debris, grease, and wax. MAINTAIN all machines with care. ALWAYS KEEP machine clean and in good working order. KEEP all blades and tool bits sharp.

  • Page 8: Product Safety

    WARNING! DO NOT handle the plug or planer with wet hands USE only accessories as described in this manual and recommended by WAHUDA. 10. DO NOT pull the planer by the power cord. NEVER allow the power cord to come in contact with sharp edges, hot surfaces, oil or grease.
  • Page 9 PRODUCT SAFETY (cont.) 14. ENSURE that the machine sits firmly before using. Attach or clamp planer to a bench top prior to operation. 15. This machine is designed to process wood ONLY. WARNING! NEVER position fingers or thumbs near the cutterhead. 17.

  • Page 10: Grounding Instructions

    GROUNDING INSTRUCTIONS WARNING! This machine MUST BE GROUNDED while in use to protect the operator from electric shock. In the event of a malfunction or breakdown, GROUNDING provides the path of least resistance for electric current and reduces the risk of electric shock. The plug MUST be plugged into a matching electrical receptacle that is properly installed and grounded in accordance with ALL local codes and ordinances.
  • Page 11 GROUNDING INSTRUCTIONS (cont.) Make certain the extension cord is properly sized, and in good electrical condition. Always replace a worn or damaged extension cord immediately or have it repaired by a qualified person before using it. Protect your extension cords from sharp objects, excessive heat, and damp or wet areas. MINIMUM RECOMMENDED GAUGE FOR EXTENSION CORDS (AWG) 115 VOLT OPERATION ONLY 25’...

  • Page 12: Unpacking & Inventory

    NOTE: Some parts pictured may already be installed on your machine at the factory. Go through the entire manual before contacting WAHUDA. Compare the items to inventory figures and verify that all items are accounted for. If any parts are missing, do not attempt to power on the machine.

  • Page 13: Assembly

    ASSEMBLY WARNING! MAKE CERTAIN THAT THE MACHINE IS DISCONNECTED FROM THE POWER SOURCE. ATTACHING DEPTH ADJUSTMENT CRANK HANDLE Attach the raise/lower adjustment handle to the shaft located on top of the planer and fasten in place with 1 Hex Socket Head screw M5*25, Tighten screw using supplied hex wrench ATTACHING DUST PORT Facing the rear of the machine, place the outfeed table in the down position.

  • Page 14: Adjustments

    ASSEMBLY (cont) TABLE MAGNETS The table magnets keep the tables from falling during transport of the planer. The 2 long table magnets, item H page 12, should be screwed into the threaded holes on the front of the cutterhead assembly and tightened with a Phillips screwdriver (not supplied) See picture on page 4 for reference.
  • Page 15 ADJUSTMENTS (cont) Next, using the metal straight edge in the same 2 locations as above, check to see if the table is coplanar with the wear plate. It should be one continuous flat surface from the outside edge of the table going across the wear plate.
  • Page 16 ADJUSTMENTS (cont) LEVELING INFEED AND OUTFEED PULLOUT EXTENSIONS The table pullout extensions offer the user additional support for longer stock. They must be parallel to, and at the same height as, the table they are attached to. 1. With the infeed table in the down position, loosen the 2 silver knurled extension lock knobs on both sides of the table and pull the extensions to their outward position.

  • Page 17: Cleaning Cutterhead & Inserts

    NOTE: Do not get solvent on any painted portion of the machine. WAHUDA spiral cutterheads are machined with a film of oil that may be left over from the process. Removal of this oil residue, if apparent, should be done before you use your new machine.
  • Page 18 CLEANING SPIRAL CUTTERHEAD & TIPS (cont.) 7) Separate the tips from the screws and place in separate containers with a bit of mineral spirits or non-chlorinated brake cleaner. 8) Once all are removed, wipe down the bare cutterhead using rags with whichever solvent you chose mentioned above.

  • Page 19: Operations

    OPERATIONS NOTE: This operations section was designed to give instructions on the basic operations of this planer. However, it is in no way comprehensive of every planer operation. It is strongly recommended that you read books, trade magazines, or get formal training to maximize the potential of your planer while minimizing the risks.
  • Page 20 OPERATIONS (cont) 2 - SPEED SELECTOR SWITCH The 26 FPM speed of the 50250PL-WHD planer allows normal speed for production type feed rates. The slower 18 FPM speed allows for a very smooth finish even on figured stock. IMPORTANT NOTE: THE SPEED SELECTOR SWITCH SHOULD ONLY BE SHIFTED FROM ONE SPEED TO ANOTHER WHILE THE MACHINE IS SWITCHED ON (RUNNING) AND NOT PLANING ANY STOCK (NO LOAD) DOING OTHERWISE WILL DAMAGE THE SPEED MECHANISM!
  • Page 21 OPERATIONS (cont) POWER SWITCH The planer is turned ON by flipping the switch into the left position and it is turned OFF by flipping the switch to the right. This planer is also equipped with a special lockout toggle switch that prevents unauthorized use.
  • Page 22 OPERATIONS (cont) REPEAT CUT PRESET The Repeat Cut turret style dial indicator, located on the bottom right hand side of the planer, provides a simple way to preset the finished thickness of a workpiece. With the machine powered off, turn the dial indicator to the desired finished thickness. Use this feature when thickness planing multiple workpieces to ensure a uniform thickness of all workpieces.
  • Page 23 OPERATIONS (cont.) THICKNESS PLANING Thickness planing sizes the workpiece to a desired thickness, while at the same time creating a smooth and level surface. The thickness of each cut will depend on the type of wood, width of the workpiece, and condition of the lumber (i.e. dryness, grain composition, straightness, etc). Always make thin test cuts on a scrap piece of wood prior to performing final cuts.
  • Page 24 OPERATIONS (cont.) GENERAL TIPS AND GUIDELINES Thickness planing always works best when at least one side of the workpiece has a flat surface. If both sides of the workpiece are rough, feed one face of the board through the planer until the entire surface is flat. ALWAYS plane both sides of the workpiece to reach the desired thickness.

  • Page 25: Maintenance

    MAINTENANCE WARNING! MAKE CERTAIN THAT THE MACHINE IS DISCONNECTED FROM THE POWER SOURCE BEFORE PERFORMING ANY MAINTENANCE PROCEDURES Your planer should provide you with a long time of service provided you take the time to perform the following maintenance operations. CLEANING Sawdust buildup and other debris can cause the tool to plane incorrectly.
  • Page 26 Remove the 7 screws holding the top cover on the machine. 3 screws are located on top and 4 on the upper sides. Remove the top cover. On the left side panel, remove the 4 socket head screws located around the bottom edge and remove the side panel to expose the gearbox.
  • Page 27 MAINTENANCE (cont.) BRUSH REPLACEMENT Brush life will vary depending on the load placed on the motor. The brushes should be inspected every 10-15 hours of use. To inspect or replace: Remove the brush holders (A). The other is located in the same position on the rear of the motor assembly.

  • Page 28: Troubleshooting

    TROUBLESHOOTING GUIDE PROBLEM LIKELY CAUSE SOLUTION Snipe Dull Blades Replace or rotate tips. Readjust (depressions at Infeed or outfeed tables out of tables. Feed scrap of same thickness end of workpiece) adjustment. before and after workpiece. Residue on rollers. Take less depth of cut per pass See page 24 for more info Torn grain.

  • Page 29: Parts Diagram & List

    PARTS...
  • Page 30 Base Assembly PART NO. DESCRIPTION SPECIFICATION 50200-A1 Crack Handle 50200-A2 Socket Head Button Screw M4x6 50200-A3 Socket Head Button Screw M6x10 50200-A4 Socket Head Cap Screw 5x25 50200-A5 Button plug 50200-A6 Top Cover 50200-A7 Steel Pipe 50200-A8 Fixed block 50200-A9 50200-A10 Set Screw M5x6...
  • Page 31 50200-A35 Flat Head Screw M3x40 50200-A36 Extension Table Support 50200-A37 Extension Table 50200-A38 Grip 50200-A39 Bushing 50200-A40 Socket Head Button Screw M6x15 50200-A41 Socket Head Button Screw M4x10 50200-A42 Socket Head Cap Screw M6x15 ψ8xD15 50200-A43 Wave Washer 50200-A44 Fixed block 50200-A45 Socket Head Cap Screw M8x10...
  • Page 33 Head Assembly PART NO. DESCRIPTION SPECIFICATION 50200-B01 Gear Plate (Included #4 & #12) 50200-B04 Spacer 50200-B05 Gear Shaft 50200-B06 Gear 50200-B07 Gear 50200-B08 Pinion Gear 50200-B09 Rack ψ4*24mm 50200-B10 50200-B11 Shaft-Actuator 50200-B12 Spacer 50200-B13 Gear 80 T 50200-B14 Gear 75 T 50200-B15 Shaft 50200-B16...
  • Page 34 50200-B38 Spring 50200-B39 Plate 50200-B40 Outfeed Roller 50200-B41 Infeed Roller 50200-B42 Chain 11 t 50200-B43 Socket Round Head Screw M5x10 50200-B43-1 Socket Head Cap Screw M5x10 50200-B44 Cutterhead 50200-B48 Belt Guard 50200-B49 Socket Head Button Screw M4x10 50200-B50 Plate 50200-B51 Socket Round Head Screw M6x10 50200-B52...
  • Page 35 50200-B77 Shaft 50200-B78 Lock Washer 50200-B79 Bolt, Special 50200-B80 Socket Round Head Screw M4x12 50200-B81 Flat Washer 50200-B82 Flat Washer 50200-B83 Socket Round Head Screw M3x10 50200-B84 Socket Head Button Screw M4x20 50200-B86 Set Screw M4x5 50200-B88 Flat Washer M8x2t 50200-B88-1 Flat Washer M8x3t...
  • Page 37 Motor Assembly PART NO. DESCRIPTION SPECIFICATION 50200-C1 Motor (included #17 & #18) 50200-C2 Motor Carbon Brush with Cap (not shown) 50200-C3 Motor Ground wire (not shown) 50200-C4 Overload Protector Assembly 50200-C5 Switch Plate 50200-C6 Machine Screw M5x12 50200-C7 Switch 50200-C8 Motor Pulley 50200-C9 Flat Washer...
  • Page 39 Cutterhead Assembly PART NO. DESCRIPTION SPECIFICATION 50200-D1 Shaft Gear 50200-D2 Ball Bearing 6203ZZ 50200-D3 Socket Round Head Screw M5x10 50200-D4 Cutterhead 13" 50200-D4A Pin (Do not show) 50200-D5 Bearing Seat 50200-D6 Spindle Pulley 50200-D7 Nut (L. H.) M16xP2.0 50200-D8 Insert 50200-D9 Screw 50200-D10...
  • Page 41 Extension Rod Assembly PART NO. DESCRIPTION SPECIFICATION 50200-E01 Eccentric rod 50200-E02 Socket Head Cap Screw M5x22 50200-E03 Fixed block 50200-E04 Nylon Nut 50200-E05 Extension plate-Right 50200-E06 Extension plate-Left 50200-E07 Fixed rod 50200-E08 Set Screw M4*10 50200-E09 Fixed Plate 50200-E10 Hex Bolt M5x20 50200-E11 Socket Head Cap Screw...
