Wahuda 50100PC-WHD User Manual

13” portable planer with spiral style cutterhead and 4-sided carbide inserts
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Read this manual before using machine to avoid serious injury and damage
50100PC-WHD
13" Portable Planer
With Spiral Style Cutterhead and 4-Sided Carbide Inserts
For technical support, email
or call at 877-568-8879
techservices@wahudatools.com
VER. 08.31.20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 50100PC-WHD and is the answer not in the manual?

Questions and answers

Related Manuals for Wahuda 50100PC-WHD

Summary of Contents for Wahuda 50100PC-WHD

  • Page 1 User Manual Read this manual before using machine to avoid serious injury and damage 50100PC-WHD 13” Portable Planer With Spiral Style Cutterhead and 4-Sided Carbide Inserts For technical support, email or call at 877-568-8879 techservices@wahudatools.com VER. 08.31.20...

  • Page 2: Table Of Contents

    The drawings, illustrations, photographs, and specifications in this user manual represent your machine at time of print. However, changes may be made to your machine or this manual at any time with no obligation to WAHUDA.

  • Page 3: Warranty

    2 YEAR LIMITED WARRANTY WAHUDA warrants its machinery to be free of defects in workmanship and materials for a period of two (2) years from the date of the original purchase by the original owner. This warranty applies to products sold in United States only. The warranty does not apply to any product used for professional or commercial production purposes nor for industrial or educational applications.

  • Page 4: Product Specifications

    PRODUCT SPECIFICATIONS Feed Speed 26 FPM Cutterhead speed RPM 10,000 Motor RPM 23000+/-10% (No Load) Cutterhead diameter 2” Max planer capacity 6" x 13" Max depth of cut @ 6” width 1/8" Max depth of cut @ 13” width 1/16" Minimum Length of Stock 9 1/2”...

  • Page 5: General Safety

    GENERAL SAFETY NOTE: The WARNING! and CAUTION! symbols indicate a potentially hazardous situation which, if not avoided, COULD result in death or serious injury. READ THIS MANUAL completely before assembling and operating this machine. WARNING! TO AVOID serious injury, death, or damage to the machine, please read, understand, and follow, all Safety and Operating Instructions before assembling and operating this machine.
  • Page 6 GENERAL SAFETY (cont.) ALWAYS keep the work area clean, well lit, and organized. DO NOT work in an area that has slippery floor surfaces from debris, grease, and wax. CAUTION! ALWAYS unplug the machine from the electrical receptacle when making adjustments, changing parts or performing any maintenance.
  • Page 7 GENERAL SAFETY (cont.) KEEP protective guards in place and in working order. CAUTION! MAINTAIN your balance. DO NOT extend yourself over the tool. Wear oil resistant rubber soled shoes. Keep floor clear of debris, grease, and wax. MAINTAIN all machines with care. ALWAYS KEEP machine clean and in good working order. KEEP all blades and tool bits sharp.

  • Page 8: Product Safety

    WARNING! DO NOT handle the plug or planer with wet hands USE only accessories as described in this manual and recommended by WAHUDA. 10. DO NOT pull the planer by the power cord. NEVER allow the power cord to come in contact with sharp edges, hot surfaces, oil or grease.
  • Page 9 PRODUCT SAFETY (cont.) 14. ENSURE that the machine sits firmly before using. Attach or clamp planer to a bench top prior to operation. 15. This machine is designed to process wood ONLY. WARNING! NEVER position fingers or thumbs near the cutterhead. 17.

  • Page 10: Grounding Instructions

    GROUNDING INSTRUCTIONS WARNING! This machine MUST BE GROUNDED while in use to protect the operator from electric shock. In the event of a malfunction or breakdown, GROUNDING provides the path of least resistance for electric current and reduces the risk of electric shock. The plug MUST be plugged into a matching electrical receptacle that is properly installed and grounded in accordance with ALL local codes and ordinances.
  • Page 11 GROUNDING INSTRUCTIONS (cont.) Make certain the extension cord is properly sized, and in good electrical condition. Always replace a worn or damaged extension cord immediately or have it repaired by a qualified person before using it. Protect your extension cords from sharp objects, excessive heat, and damp or wet areas. MINIMUM RECOMMENDED GAUGE FOR EXTENSION CORDS (AWG) 115 VOLT OPERATION ONLY 25’...

  • Page 12: Unpacking & Inventory

    NOTE: Some parts pictured may already be installed on your machine at the factory. Go through the entire manual before contacting WAHUDA. Compare the items to inventory figures and verify that all items are accounted for. If any parts are missing, do not attempt to power on the machine.

  • Page 13: Assembly

    ASSEMBLY WARNING! MAKE CERTAIN THAT THE MACHINE IS DISCONNECTED FROM THE POWER SOURCE. ATTACHING DEPTH ADJUSTMENT CRANK HANDLE Attach the raise/lower adjustment handle to the shaft located on top of the planer and fasten in place with1 Hex Socket Head screw M5*25, Tighten screw using supplied hex wrench. ATTACHING DUST PORT Facing the rear of the machine, place the outfeed table in the down position.

  • Page 14: Adjustments

    ASSEMBLY (cont) TABLE MAGNETS The table magnets keep the tables from falling during transport of the planer. The 2 long table magnets, item H page 12, should be screwed into the threaded holes on the front of the cutterhead assembly and tightened with a Phillips screwdriver (not supplied) See picture on page 4 for reference.
  • Page 15 ADJUSTMENTS (cont) Next, using the metal straight edge in the same 2 locations as above, check to see if the table is coplanar with the wear plate. It should be one continuous flat surface from the outside edge of the table going across the wear plate.

  • Page 16: Cleaning Cutterhead & Inserts

    NOTE: Do not get solvent on any painted portion of the machine. WAHUDA spiral cutterheads are machined with a film of oil that may be left over from the process. Removal of this oil residue, if apparent, should be done before you use your new machine.
  • Page 17 CLEANING SPIRAL CUTTERHEAD & TIPS (cont.) 7) Separate the tips from the screws and place in separate containers with a bit of mineral spirits or non-chlorinated brake cleaner. 8) Once all are removed, wipe down the bare cutterhead using rags with whichever solvent you chose mentioned above.

  • Page 18: Operations

    OPERATIONS NOTE: This operations section was designed to give instructions on the basic operations of this planer. However, it is in no way comprehensive of every planer operation. It is strongly recommended that you read books, trade magazines, or get formal training to maximize the potential of your planer while minimizing the risks.
  • Page 19 OPERATIONS (cont) RAISING AND LOWERING HEAD ASSEMBLY The cutterhead assembly consists of the cutterhead, insert tips, feed rollers, roller chains, gearbox, and cutterhead dust chute. Raising and lowering of the head assembly controls the depth of cut on the planer. To raise the cutterhead assembly, turn the adjusting crank handle clockwise.
  • Page 20 OPERATIONS (cont) DEPTH-OF-CUT INDICATOR The Depth-Of-Cut Indicator, located on the front of the machine, is a convenient way to quickly determine how much material is being planed off in one pass. With the machine powered OFF, and the cutterhead raised, insert your workpiece just under the indicator arrow.
  • Page 21 OPERATIONS (cont.) THICKNESS PLANING Thickness planing sizes the workpiece to a desired thickness, while at the same time creating a smooth and level surface. The thickness of each cut will depend on the type of wood, width of the workpiece, and condition of the lumber (i.e. dryness, grain composition, straightness, etc). Always make thin test cuts on a scrap piece of wood prior to performing final cuts.
  • Page 22 OPERATIONS (cont.) GENERAL TIPS AND GUIDELINES Thickness planing always works best when at least one side of the workpiece has a flat surface. If both sides of the workpiece are rough, feed one face of the board through the planer until the entire surface is flat. ALWAYS plane both sides of the workpiece to reach the desired thickness.

  • Page 23: Maintenance

    MAINTENANCE WARNING! MAKE CERTAIN THAT THE MACHINE IS DISCONNECTED FROM THE POWER SOURCE BEFORE PERFORMING ANY MAINTENANCE PROCEDURES Your planer should provide you with a long time of service provided you take the time to perform the following maintenance operations. CLEANING Sawdust buildup and other debris can cause the tool to plane incorrectly.
  • Page 24 MAINTENANCE (cont) Remove the 7 screws holding the top cover on the machine. 3 screws are located on top and 4 on the upper sides. Remove the top cover. On the left side panel, remove the 4 socket head screws located around the bottom edge and remove the side panel to expose the gearbox.
  • Page 25 MAINTENANCE (cont.) BRUSH REPLACEMENT Brush life will vary depending on the load placed on the motor. The brushes should be inspected every 10-15 hours of use. To inspect or replace: Remove the brush holders (A). The other is located in the same position on the rear of the motor assembly.

  • Page 26: Troubleshooting

    TROUBLESHOOTING GUIDE PROBLEM LIKELY CAUSE SOLUTION Snipe Dull Blades Replace or rotate tips. Readjust (depressions at Infeed or outfeed tables out of tables. Feed scrap of same thickness end of workpiece) adjustment. before and after workpiece. Residue on rollers. Take less depth of cut per pass See page 22 for more info Torn grain.

  • Page 27: Parts Diagram & List

    PARTS...
  • Page 28 Base Assembly PART NO. DESCRIPTION SPECIFICATION 50100-A1 Crack Handle 50100-A2 Socket Head Button Screw M4x6 50100-A3 Socket Head Button Screw M6x10 50100-A4 Socket Head Cap Screw M5x25 50100-A5 Button plug 50100-A6 Top Cover 50100-A7 Steel Pipe 50100-A8 Fixed block 50100-A9 50100-A10 Set Screw M5x6...
  • Page 29 50100-A39 Bushing 50100-A40 Socket Head Button Screw M6x15 50100-A41 Socket Head Button Screw M4x10 50100-A42 Socket Head Cap Screw M6x15 50100-A43 Wave Washer 50100-A44 Fixed block 50100-A45 Socket Head Cap Screw M8x10 50100-A46 Socket Head Cap Screw M4x 10 50100-A47 Lock Washer 50100-A48 Flat Head Screw...
  • Page 31 Head Assembly PART NO. DESCRIPTION SPECIFICATION 50100-B01 Gear Plate (Included #4 & #12) 50100-B04 Spacer 50100-B05 Gear Shaft 50100-B06 Gear 50100-B07 Gear 50100-B08 Pinion Gear 50100-B12 Spacer ψ4*24mm 50100-B10 50100-B11 Shaft-Actuator 50100-B13 Gear 80 T 50100-B14 Gear 75 T 50100-B15 Shaft 50100-B16 Ball Bearing...
  • Page 32 50100-B44 Cutterhead 50100-B48 Belt Guard 50100-B49 Socket Head Button Screw M4x10 50100-B50 Plate 50100-B51 Socket Round Head Screw M6x10 50100-B52 Socket Round Head Screw M8x20 50100-B53 Hex Bolt M8x45 50100-B54 Hex Nut 50100-B55 Pointer 50100-B56 Dust Chute 50100-B57 Clamp 50100-B58 Socket Round Head Screw M5x12 50100-B59...
  • Page 33 50100-B86A Socket Round Head Screw M4x30 50100-B88 Flat Washer M8x2t 50100-B88-1 Flat Washer M8x3t 50100-B90 Warning label for Knife replacement 50100-B90-1 50100-B91 Dust collector adapter 50100-B92 Knob M5x12...
  • Page 35 Motor Assembly PART NO. DESCRIPTION SPECIFICATION 50100-C1 Motor (included #17 & #18) Motor Carbon Brush with Cap (not 50100-C2 shown) 50100-C3 Motor Ground wire (not shown) 50100-C4 Overload Protector Assembly 50100-C5 Switch Plate 50100-C6 Machine Screw M5x12 50100-C7 Switch 50100-C8 Motor Pulley 50100-C9 Flat Washer...
  • Page 37 Cutterhead Assembly PART NO. DESCRIPTION SPECIFICATION 50100-D1 Shaft Gear 50100-D2 Ball Bearing 6203ZZ 50100-D3 Socket Round Head Screw M5x10 50100-D4 Cutterhead 13" 50100-D4A Pin (Not shown) 50100-D5 Bearing Seat 50100-D6 Spindle Pulley 50100-D7 Nut (L. H.) M16xP2.0 50100-D8 Insert 50100-D9 Screw 50100-D10 Torx Wrench...
