Toshiba Tecra A7-ST7712 Series Specifications

Tecra A7-ST7712 Series Detailed Product Specification
Model Name Description
A7-ST7712 Genuine Windows Vista Business™, Intel® Core™ 2 Duo Processor T5500, 512MB
DDR2, 60GB 5400rpm (S-ATA), CD-RW/DVD-ROM, 15.4" widescreen WXGA, NVIDIA®
Quadro NVS 300M w/128MB, ExpressCard™, 6-in-1 Bridge Media Adapter, 1Gbps
LAN, 1-year standard limited warranty
Section 1.01 Operating System
• Genuine Windows Vista™ Business
Section 1.02 Processor and Chipset
• Choice of processors:
o Intel® Core™ 2 Duo Processor T5500
1.66GHz, 2MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor T5600
1.83GHz, 2MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor 7200
2.00GHz, 4MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor T7400
2.16GHz, 4MB L2, 667MHz FSB with
64-bit
o Intel® Core™ 2 Duo Processor T7600
2.33GHz, 4MB L2, 667MHz FSB with
64-bit
• Chipset:
o Mobile Intel® 945PM Express Chipset
4
Section 1.03 Memory
• Configured with 512MB PC4200 DDR2 SDRAM (1 slot occupied
and 1 available)
• 512MB (Min)/4096MB (Max), with 256MB, 512MB, 1024MB or
2048MB PC4200 or PC5300 DDR2 memory modules.
Section 1.04 Hard Disk Drive
• Choice of: 60GB (5400 RPM), 80GB (5400RPM), 100GB
(5400RPM), 120GB (5400 RPM) or 100GB (7200RPM); Serial-
ATA (SATA) hard disk drive; 9.5mm height; user removable
Section 1.05 Choice of Fixed Optical Disk Drive
• CD-RW/DVD-ROM
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x)
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (10x:write), DVD-ROM
(8x:read), DVD-R (Single Layer, 8x:write), DVD-R
(Double Layer, 2x: write), DVD-RW (4x:write), DVD+R
(Single Layer, 8x:write), DVD+R (Double Layer,
2.4x:write), DVD+RW (4x:write), DVD-RAM (5x:write)
7
Section 1.06 Display
• 15.4" diagonal widescreen TFT active-matrix LCD display at
1280x800 native resolution (WXGA)
• 15.4" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x800 native resolution (WXGA)
Section 1.07 Graphics
o NVIDIA® Quadro NVS 300M with 128MB or 256MB of
dedicated graphics memory
2
3
CPU_64
CPU_64
CPU_64
CPU_64
CPU_64
5
6
Choices
8
© Copyright 2005 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra A7-ST7712 BTO Rev. 1.01 2007-03-12 {SK} T20060621 CB1.60
1
Part Number
PTA73U-00F00S
Section 1.08 Sound
• Built-in stereo speakers
• Sound Volume Control Dial
Section 1.09 Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Toshiba Assist button to launch Toshiba Assist control
panel
o Presentation button to quickly connect to projectors
Section 1.10 Communications
• Toshiba V.92 software modem
• Intel® PRO/1000 Network Connection - 10/100/1000 Base-TX
Ethernet
• Choice of Optional Integrated Wireless-LAN:
o Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
o Atheros® 802.11a/b/g wireless-LAN
• Optional Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
with Toshiba Bluetooth driver software
• Fast Infrared (4Mbps) port for FIR
Section 1.11 Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• ExpressCard™ slot supporting ExpressCard/34 and
ExpressCard/54
• 6-in-1 Bridge Media Adapter
o Secure Digital, miniSD™ (with adapter) Memory Stick™,
Memory Stick PRO™, SmartMedia™, Multi Media Card,
xD Picture Card [shared slots]
o Secure Digital slot supports SDIO
Section 1.12 Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o USB v2.0 – 4 ports
o RJ-45 LAN port
o RJ-11 modem port
o Parallel port
o 240-pin docking connector
Section 1.13 Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 14.2" (360.0mm) x 10.5"
(267.0mm) x 1.17" (29.8mm)[F]/1.45" (36.8mm)[R] without feet
UPC
032017667464
9
10
Page 1 of 5
