Toshiba Tecra A7-ST5112 Series Specifications

Tecra A7-ST5112 Series Detailed Product Specification
Model Name Description
A7-ST5112 Genuine Windows® XP Professional, Intel® Core™ Duo Processor T2300E, 512MB
DDR2, 40GB 5400rpm (S-ATA), CD-RW/DVD-ROM, 15.4" widescreen WXGA, NVIDIA®
Quadro NVS 300 w/128MB, ExpressCard™, 6-in-1 Bridge Media Adapter, 1Gbps LAN,
1-year standard limited warranty
Section 1.01 Operating System
• Genuine Windows® XP Professional
• Windows Vista™ Premium Ready
Section 1.02 Processor and Chipset
• Choice of processors:
o Intel® Core™ Duo Processor T2300E
1.66GHz, 2MB L2, 667MHz FSB
o Intel® Core™ Duo Processor T2400
1.83GHz, 2MB L2, 667MHz FSB
o Intel® Core™ Duo Processor T2500
2.00GHz, 2MB L2, 667MHz FSB
o Intel® Core™ Duo Processor T2600
2.16GHz, 2MB L2, 667MHz FSB
o Intel® Core™ Duo Processor T2700
2.33GHz, 2MB L2, 667MHz FSB
• Chipset:
o Mobile Intel® 945PM Express Chipset
5
Section 1.03 Memory
• Configured with 512MB PC4200 DDR2 SDRAM (both memory slots
are occupied)
• 512MB (Min)/4096MB (Max), with 256MB, 512MB, 1024MB or
2048MB PC4200 or PC5300 DDR2 memory modules.
Section 1.04 Hard Disk Drive
• Choice of: 40GB (5400 RPM), 60GB (5400 RPM), 80GB
(5400RPM), 100GB (5400RPM), 120GB (5400 RPM) or 100GB
(7200RPM); Serial-ATA (SATA) hard disk drive; 9.5mm height;
user removable
Section 1.05 Choice of Fixed Optical Disk Drive
• CD-RW/DVD-ROM
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x)
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (10x:write), DVD-ROM
(8x:read), DVD-R (Single Layer, 8x:write), DVD-R
(Double Layer, 2x: write), DVD-RW (4x:write), DVD+R
(Single Layer, 8x:write), DVD+R (Double Layer,
2.4x:write), DVD+RW (4x:write), DVD-RAM (5x:write)
8
Section 1.06 Display
• 15.4" diagonal widescreen TFT active-matrix LCD display at
1280x800 native resolution (WXGA)
• 15.4" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x800 native resolution (WXGA)
• 15.4" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1680x1050 native resolution (WSXGA+)
Section 1.07 Graphics
o NVIDIA® Quadro NVS 300 with 128MB or 256MB of
dedicated graphics memory
Section 1.08 Sound
• Built-in stereo speakers
2
3
4
6
7
Choices
9
© Copyright 2005 – 2006 Toshiba America Information Systems In
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra A7-ST5112 BTO Rev. 1.05 2006-07-25 {SK} T20060621 CB1.60
1
Part Number
PTA71U-08Q01P
• Sound Volume Control Dial
Section 1.09 Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Toshiba Assist button to launch Toshiba Assist control
panel
o Presentation button to quickly connect to projectors
Section 1.10 Communications
• Toshiba V.92 software modem
• Intel® PRO/1000 VE Network Connection - 10/100/1000 Base-TX
Ethernet
• Choice of Integrated Wireless-LAN:
o Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
o Atheros® 802.11a/b/g wireless-LAN
• Optional Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
with Toshiba Bluetooth driver software
• Fast Infrared (4Mbps) port for FIR
Section 1.11 Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• ExpressCard™ slot supporting ExpressCard/34 and
ExpressCard/54
• 6-in-1 Bridge Media Adapter
o Secure Digital, miniSD™ (with adapter) Memory Stick™,
Memory Stick PRO™, SmartMedia™, Multi Media Card,
xD Picture Card [shared slots]
o Secure Digital slot supports SDIO
Section 1.12 Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o USB v2.0 – 4 ports
o RJ-45 LAN port
o RJ-11 modem port
o Parallel port
o 240-pin docking connector
Section 1.13 Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 14.2" (360.0mm) x 10.5"
(267.0mm) x 1.17" (29.8mm)[F]/1.45" (36.8mm)[R] without feet
• Weight: Starting at 6.0 lbs (2.72 kg) depending upon
12
configuration
• Chassis Description
o Case material: PC+ABS Plastic
o LCD Cover Color: Titanium Silver
c. Al l Rights reserved.
UPC
032017667464
10
11
Page 1 of 5
