LED Solar Powered
Landscape Accent Light
Motion Activated
PACKAGE CONTENTS
Adjustment
screw
Thumbscrew
Stake
Monocrystalline
Solar Panel
Motion Sensor
Shroud
Shatter-Resistant
Polycarbonate Lens
Friction lock
LED Facts:
Lumens: 100
Color Temperature: 5000K
CRI: 70
Efficacy (Lumens Per Watt): 100
Rated Watts: 1W
LED Life: 50,000 hours
Operating temperature: -13° to 122°F
(-25° to 50° C)
Beam Angle: 80°
Power Factor: 0.9
This fixture is IP65 rated and therefore is suitable for
indoor and outdoor use in wet locations.
1
MODEL No:
L-100-M
5.75 in.
14,6 cm
Product Features:
Detection Angle: 180°
Detection Range: 5 ft.
Operating Voltage: DC 3.7v
Time On: 45 Sec. (Fixed)
Battery Type: (1) 3.7v 350mAh
Lithium-Ion Polymer Battery
(Non-Replaceable)
Run Time: 500 cycles
Revision Date: 04-11-2018
Advertisement
Table of Contents
Related Manuals for StonePoint L-100-M
Summary of Contents for StonePoint L-100-M
- Page 1 MODEL No: L-100-M LED Solar Powered Landscape Accent Light Motion Activated PACKAGE CONTENTS Monocrystalline Solar Panel Motion Sensor Shroud Shatter-Resistant Polycarbonate Lens Adjustment screw Thumbscrew 5.75 in. 14,6 cm Friction lock LED Facts: Product Features: Lumens: 100 Detection Angle: 180°...
- Page 2 SAFETY AND PRECAUTIONS 1. Suitable for both indoor and outdoor wet locations. 2. Do NOT look directly into LED lights. 3. The LED modules used in this fixture are not serviceable. 4. Do not use this product if damaged or missing parts. 5.
- Page 3 OPERATION 2. The spot light has a solar panel at the top of the light head that can be adjusted by loosening the adjustment screw (Fig. 4). The solar panel can be adjusted all the way up (nearly touching the motion sensor) and all the way down (Fig. 5). The solar panel can be rotated for further adjust- ments (Fig.
- Page 4 SOLAR PANEL ORIENTATION • Avoid locating the light in shadows. Shadows inhibit the solar panel’s ability to convert the sunlight. • Check the position of the light every 3-4 months and adjust for maximize sun exposure to the sunlight. • Charges off of direct sunlight. WINTER MONTHS: During the short daylight hours of winter, fully charging the battery pack may be nearly impossible.
