Wall Mount
Security Light
Switch Operated
PACKAGE CONTENTS
2x (short)
machine screws
3x (long)
machine screws
2x
Wood screws
Mounting bracket
Mount fixture above 5ft.
Electrical requirements can be found on fixture.
Use with a Minimum 90° supply conductors.
Contact terminals
Mounting plate
Front Access Panel
Tapered posts
LED Facts:
Color temperature: 4000K
Lumen: 700 LM
Lumen Efficiency: 80
Input Voltage: AC120/60Hz
Rated Watts: 9W
Equivalent: 75W incandescent, 23W CFL
Power Efficiency: 88%
LED Emitter Life: 50,000 hours
Cold start operating temperature: -13° F to 122° F (-25° C to 50° C)
1
MODEL No: JJ-700-SB
Contact pins
5.75 in.
14,6cm
4.5 in.
11,43cm
6 in.
15,24 cm
