Summary of Contents for BenQ SH753P

  • Page 1 SH753P V 1.00...

  • Page 2: Table Of Contents

    Table of contents Important safety Operating in a high altitude environment..........42 instructions ....3 Adjusting the sound ....... 42 Introduction ....7 Using the test pattern ......43 Using the quick install ......44 Projector features ........7 Controlling the projector through a Shipping contents ........

  • Page 3: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before Always open the lens shutter...
  • Page 4 Safety Instructions (Continued) Do not block the projection lens with Never replace the lamp assembly or any objects when the projector is any electronic components unless the under operation as this could cause projector is unplugged. the objects to become heated and deformed or even cause a fire.
  • Page 5 Safety Instructions (Continued) When the projector is under Do not block the ventilation holes. operation, you may sense some - Do not place this projector on a blanket, bedding or any other soft surface. heated air and odor from its - Do not cover this projector with a cloth ventilation grill.
  • Page 6 We want you to have a pleasant experience doing so may result in accidents and using your BenQ projector, so we need to bring possible injury. this safety matter to your attention to prevent possible damage to person and property.

  • Page 7: Introduction

    3D Function supported Various 3D formats make the 3D function more flexible. By presenting the depth of the images, you can wear BenQ 3D glasses to enjoy the 3D movies, videos and sporting events in a more realistic way. •...

  • Page 8: Shipping Contents

    Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated. Projector Remote control with battery Power cord...

  • Page 9: Projector Exterior View

    Projector exterior view Lamp compartment cover External control panel Front/upper side (See "Projector" on page 11 details.) Zoom ring Vent (cool air intake) Focus ring Projection lens Front IR remote sensor RJ45 LAN input jack HDMI-1 input jack Rear/lower side 10.
  • Page 10 Front adjuster foot Bottom side Ceiling mount holes Rear adjuster foot Introduction...

  • Page 11: Controls And Functions

    Controls and functions Projector POWER indicator light Lights up or flashes when the projector is under operation. See "Indicators" on page 69 for details. Keystone/Arrow keys ( /▲ Up) Manually corrects distorted images resulting from an angled projection. See "Correcting 2D Keystone" on page 27 details.
  • Page 12 Remote Control ECO BLANK Used to hide the screen picture. LASER Emits visible laser pointer light for presentation purposes. Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No.50, dated June 24,2007 MHL control buttons ADVANCETECH CO., LTD(FACTORY) Model No.: SN1407029 11/F-1, No.120, Qiaohe Rd., Zhonghe Dist., New Taipei City...
  • Page 13 Operating the LASER pointer 16. ► Right/ The Laser Pointer is a Increases the projector volume. presentation aid for When the On-Screen Display (OSD) professionals. It emits a menu is activated, the #3, #5, and #16 beam of red light when you keys are used as directional arrows to press it.
  • Page 14 (Available in Japan region) ECO BLANK Used to hide the screen picture. ZOOM+/ZOOM- Magnifies or reduces the projected picture size. ASPECT Selects the display aspect ratio. FREEZE Freezes the projected image. 10. NETWORK SETTING Displays the Network Settings OSD menu. 11.
  • Page 15 16. SOURCE Displays the source selection bar. 17. PAGE +/PAGE - Operate your display software program (on a connected PC) which responds to page up/down commands (like Microsoft PowerPoint). 18. MIC/VOL +/MIC/VOL – Microphone input level adjustment. 19. MUTE Toggles projector audio between on and off.
  • Page 16 Remote control effective range Infra-Red (IR) remote control sensor is located on the front and the rear of the projector. The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensor to function correctly. The distance between the remote control and the sensor should not exceed 8 meters (~ 26 feet).

  • Page 17: Positioning Your Projector

    Purchase the BenQ Projector Ceiling Note that a special rear projection screen Mounting Kit from your dealer to mount and the BenQ Projector Ceiling Mounting your projector on the ceiling. Kit are required for this installation location.

  • Page 18: Obtaining A Preferred Projected Image Size

    11556 13881 There is 5% tolerance among these numbers due to optical component variations. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector before you permanently install it, so as to make allowance for this projector's optical characteristics.

  • Page 19: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...

  • Page 20: Connecting Video Source Devices

    FN and the labeled function key simultaneously. Refer to your notebook's documentation to find your notebook's key combination. Connecting video source devices You need only connect the projector to a video source device using just one of the connecting methods, however each provides a different level of video quality. The method you choose will most likely depend upon the availability of matching terminals on both the projector and the video source device as described below: Terminal name...

  • Page 21: Playing Sound Through The Projector

    VIDEO signal, the projector can play the sound received from AUDIO (L/R). Connecting smart devices The projector can also project the content directly from your personal device(phone, tablet, NB) through optional BenQ wireless solution such as QCast dongle or InstaShow™. Please consult to your local agent if you're interested in it.

  • Page 22: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted). Check that the POWER indicator light on the projector lights orange after power has been applied.

  • Page 23: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projection angle The projector is equipped with 1 front adjuster foot and 1 rear adjuster foot. These adjusters change the image height and projection angle. To adjust the projector: Screw the front adjuster foot. Once the image is positioned where you want it.
  • Page 24 Correcting 2D Keystone 2D Keystone function enables a wider projector installation area compared to conventional projectors with limited positioning in front of the screen. To correct this, you will need to manually correct it following one of these steps. • Using the projector or remote control Press on the projector or remote...
  • Page 25 Correcting Corner Fit Manually adjust four corners of the image by setting the horizontal and vertical values. • Using the OSD menu Press MENU/EXIT and then press ◄/► Display until the menu is highlighted. Press ▼ to highlight Corner Fit and press MODE/ENTER.

  • Page 26: Using The Menus

    Using the menus The projector is equipped with On-Screen Display (OSD) menus for making various adjustments and settings. Below is the overview of the OSD menu. Main menu icon Main menu Highlight Status Sub-menu Press MENU/ EXIT to the previous page or to exit.

  • Page 27: Securing The Projector

    Securing the projector Using a security cable lock The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as a Kensington lock, to secure the projector. You can locate a Kensington lock slot on the left side of the projector.
  • Page 28 BenQ the screen. Customer Center. Write down the number and turn off your projector. Seek help from the local BenQ service Recall code: 12345678 center to decode the number. You may be required to provide proof of purchase...
  • Page 29 Changing the password Open the OSD menu and go to the System Setup: Advanced > Security Settings > Change Password menu. Press MODE/ENTER. The message 'INPUT CURRENT PASSWORD' displays. Enter the old password. • If the password is correct, another message 'INPUT NEW PASSWORD' displays.

  • Page 30: Switching Input Signal

    Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. Be sure the Quick Auto Search function in the Source menu is On (which is the default of this projector) if you want the projector to automatically search for the signals.

  • Page 31: Selecting The Aspect Ratio

    Selecting the aspect ratio The 'aspect ratio' is the ratio of the image width to the image height. Most analog TV and computers are in 4:3 ratio, and digital TV and DVDs are usually in 16:9 ratio. 16:6 aspect ratio and is aligned with the upper edge of the display region (available in SU754+). With the advent of digital signal processing, digital display devices like this projector can dynamically stretch and scale the image output to a different aspect than that of the image input signal.
  • Page 32 About the aspect ratio In the pictures below, the black portions are inactive areas and the white portions are active areas. OSD menus can be displayed on those unused black areas. Auto: Scales an image 4:3: Scales an image so that it is proportionally to fit the projector's displayed in the center of the screen native resolution in its horizontal...

  • Page 33: Optimizing The Image

    Optimizing the image Using Wall Color In the situation where you are projecting onto a colored surface such as a painted wall which may not be white, the Wall Color feature can help correct the projected picture’s color to prevent possible color difference between the source and projected pictures. To use this function, go to the Display >...
  • Page 34 Setting the User mode There is user-definable mode if the current available picture modes are not suitable for your need. You can use one of the picture modes (except the User) as a starting point and customize the settings. Press MENU/EXIT to open the On-Screen Display (OSD) menu. Go to the Picture >...
  • Page 35 Selecting a Color Temperature The options available for color temperature* settings vary according to the signal type selected. Cooler: makes the image appear bluish white. Normal: Maintains normal colorings for white. Warm: Makes images appear reddish white. *About color temperatures: There are many different shades that are considered to be "white"...
  • Page 36 Press MODE/ENTER and the 3D Color Management page displays. Highlight Primary color and press ◄/► to select a color from among Red, Green, Blue, Cyan, Magenta and Yellow. Press ▼ to highlight Hue and press ◄/► to select its range. Increase in the range will include colors consisted of more proportions of its two adjacent colors.

  • Page 37: Setting The Presentation Timer

    Setting the presentation timer Presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Follow these steps to utilize this function: Go to the System Setup: Basic > Presentation Timer menu and press MODE/ ENTER to display the Presentation Timer page.

  • Page 38: Remote Paging Operations

    Remote paging operations Connect the projector to your PC or notebook with a USB cable prior to using the paging function. See "Connection" on page 22 for details. You can operate your display software program (on a connected PC) which responds to page up/down commands (like Microsoft PowerPoint) by pressing PAGE +/PAGE - on the remote control.

  • Page 39: Locking Control Keys

    Locking control keys With the control keys on the projector locked, you can prevent your projector settings from being changed accidentally (by children, for example). When the Panel Key Lock is on, no control keys on the projector will operate except POWER.

  • Page 40: Using The Test Pattern

    Muting the sound To temporarily turn off the sound, • Using the remote control Press MUTE to temporarily turn off the sound. While the sound is off, the screen will display in the upper right corner of the screen. To restore the sound, press MUTE again. •...

  • Page 41: Using The Quick Install

    Using the quick install The projector provides a hot key to set Projector Installation, Test Pattern, and Keystone quickly. Press Quick Install on the remote control and press ▲/▼ to select: • Projector Installation: See "Positioning your projector" on page •...
  • Page 42 If the IP Address still does not display, contact your ITS administrator. Go back to System Setup: Advanced > Network Settings page. Press ▼ to highlight AMX Device Discovery and press ◄/► to select On or Off. When AMX Device Discovery is On, the projector can be detected by AMX controller.
  • Page 43 Controlling the projector remotely through a web browser Once you have the correct IP address for the projector and the projector is on or in standby mode, you can use any computer that is on the same local area network to control the projector.
  • Page 44 The tools page allows you to manage the projector, configure the LAN control settings and secure access of remote network operation on this projector. You can name the projector, keep track of its location and the person in charge of it. You can adjust the LAN Control Settings.

  • Page 45: Shutting Down The Projector

    The info page displays the information and status of this projector. Press Exit to go back to the remote network operation page. For more information, visit http://www.crestron.com & www.crestron.com/getroomview. Shutting down the projector Press POWER or OFF and a confirmation message will appear prompting you.

  • Page 46: Menu Operation

    Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. Main menu Sub-menu Options Off/Light Yellow/Pink/Light Green/ Wall clolr Blue/Blackboard Aspect Ratio Auto/Real/4:3/16:9/16:10 2D Keystone Top Left/Top Right/Bottom Left/ Corner Fit Bottom Right Position Phase...
  • Page 47 20 mins/25 mins/30 mins Operation Setting Instant Restart On/Off Disable/5 mins/10 mins/15 mins/ Blank Timer 20 mins/25 mins/30 mins Disable/30 mins/1 hr/2 hrs/3hrs/ Sleep Timer 4hrs/8 hrs/12hrs Remote Receiver Front+Rear/Front/Rear Panel Key Lock On/Off Yes/No Background BenQ/Black/Blue/Purple Color Splash Screen BenQ/Black/Blue Operation...
  • Page 48 High Altitude On/Off Yes/No Mode Mute On/Off Volume Microphone Audio Settings Volume Power On/Off Ring On/Off Tone Lamp Mode Normal/Economic/SmartEco Reset Lamp Timer Reset/Cancel Lamp Settings Lamp Usage Time/ Lamp Timer Equivalent Lamp Hour Change Password Change Security Security Setting Settings Power On Lock On/Off...
  • Page 49 Description of each menu FUNCTION DESCRIPTION Corrects the projected picture’s color when the projection surface is Wall color not white. See "Using Wall Color" on page 36 for details. There are several options to set the image's aspect ratio depending Aspect Ratio on your input signal source.
  • Page 50 FUNCTION DESCRIPTION This projector features a 3D function which enables you to enjoy the 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images. You need to wear a pair of 3D glasses to view the 3D images.
  • Page 51 FUNCTION DESCRIPTION Pre-defined picture modes are provided so you can optimize your Picture Mode projector image set-up to suit your program type. See "Selecting a picture mode" on page 36 for details. Selects a picture mode that most suits your need for the image Reference quality and further fine-tune the image based on the selections listed Mode...
  • Page 52 FUNCTION DESCRIPTION "Switching input signal" on page 33 for details. Quick Auto Search Selects an input source type for the HDMI signal. Auto is the default and recommended setting. You can also manually select the source type. The different source types carry different standards for the HDMI Range brightness level.
  • Page 53 FUNCTION DESCRIPTION Direct Power On Powers projector on automatically when the power cable is connected. Signal Power On Sets whether to turn the projector directly on without pressing POWER or ON when the projector is in standby mode and the signal is feed through the VGA cable.
  • Page 54 FUNCTION DESCRIPTION A mode for operation in high altitude areas. See "Operating in a high High Altitude altitude environment" on page 42 for details. Mode "Adjusting the sound" on page 42 for details. Mute Sets the mute function. Volume Audio Settings Adjusts the audio volume level.
  • Page 55 FUNCTION DESCRIPTION Closed Caption Enable Activates the function by selecting On when the selected input signal carries closed captions. • Captions: An on-screen display of the dialogue, narration, and Closed sound effects of TV programs and videos that are closed Caption captioned (usually marked as "CC"...
  • Page 56 FUNCTION DESCRIPTION Wired LAN "Controlling the projector through a Wired LAN environment" on page 44 for details. Network AMX Device Discovery settings When AMX Device Discovery is On, the projector can be detected by AMX controller. MAC Address Displays the MAC address for this projector. Returns all settings to the factory preset values.

  • Page 57: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.

  • Page 58: Lamp Information

    Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. The method of calculating the equivalent lamp hour is as follows: Lamp Usage Time = (hours used in Normal mode) + (hours used in Economic mode) + (hours used in SmartEco mode) Equivalent lamp hour = 1.8*(hours used in Normal mode) + 1.3*(hours used in Economic mode) + 1.00*(hours used in SmartEco mode)
  • Page 59 Setting Auto Power Off This function allows the projector to turn off automatically if no input source is detected after a set period of time to prevent unnecessary waste of lamp life. To set Auto Power Off, go into the SYSTEM SETUP: Basic > Auto Power Off menu and press ◄/►.
  • Page 60 An old lamp may cause a malfunction in the projector and in some instances the lamp may explode. Go to http://www.benq.com for a replacement lamp. The Lamp indicator light and Temperature warning light will light up if the lamp becomes too hot.
  • Page 61 • To assure optimal performance from the projector, it is recommended that you purchase a BenQ projector lamp for lamp replacement. • Ensure good ventilation when handling broken lamps. We recommend that you use respirators, safety glasses, goggles or face shield and wear protective clothing such as gloves.
  • Page 62 Loosen the two captive screws that secure the lamp. • Do not turn the power on with the lamp cover removed. • Do not insert your fingers between the lamp and the projector. The sharp edges inside the projector may cause injuries. Lift the handle so that it stands up.
  • Page 63 Connect the lamp connector properly and place as drawing before lamp compartment cover installation back. • Lamp connector must be installed flush with the connector base as shown in the image below. A gap between the lamp connector and the connector base will cause damage to the projector.
  • Page 64 Indicators Light Status & Description Power Temp Lamp Power events Orange Stand-by mode Green Powering up Flashing Green Normal operation Orange Projector is cooling. Flashing Lamp events Orange The lamp ignition is not lit up. Flashing The projector needs 90 seconds to cool down. Or Please contact your dealer for assistance.

  • Page 65: Troubleshooting

    Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC inlet on the projector, and plug the power cord into the There is no power from the power cable. power outlet. If the power outlet has a switch, make sure that it is switched on.

  • Page 66: Specifications

    Specifications Projector specifications All specifications are subject to change without notice. Optical Input terminals PC input Resolution SH753P RGB input 1920 X 1080 1080P D-Sub 15-pin (female) x 1 Display system Video signal input Single-chip DLP™ system VIDEO RCA jack x 1...

  • Page 67: Dimensions

    Dimensions 314 mm (W) x 117 mm (H) x 233 mm (D) 314.0 Unit: mm 314.0 233.0 117.0 51.2 65.2 Ceiling Mount Installation *Ceiling Mount Screws: M4 (Max. L=25, Min. L=20) 90.5 71.0 45.6 76.0 109.0 233.0 314.0 Specifications...

  • Page 68: Timing Chart

    119.989 97.551 115.500 ◎ (Reduce Blanking) 1152 x 864 1152 x 864_75 75.000 67.500 108.000 1024 x 576 BenQ NB Timing 60.000 35.820 46.996 1024 x 600 BenQ NB Timing 64.995 41.467 51.419 1280 x 720 1280 x 720_60 60.000 45.000...
  • Page 69 Refresh Clock 3D Frame 3D Top Resolution Mode Frequency Side- Rate (Hz) (MHz) Sequential Bottom (kHz) by-Side 1280 x 960_60 60.000 60.000 108.000 ◎ ◎ 1280 x 960 1280 x 960_85 85.002 85.938 148.500 1360 x 768 1360 x 768_60 60.015 47.712 85.500...
  • Page 70 Support timing for Component - YPbPr input Horizontal Vertical Dot Clock 3D Frame Timing Resolution Frequency (KHz) Frequency (Hz) Frequency (MHz) Sequential 480i 720 x 480 15.73 59.94 13.50 ◎ 480p 720 x 480 31.47 59.94 27.00 ◎ 576i 720 x 576 15.63 50.00 13.50...
  • Page 71 68.667 94.500 XGA_120 119.989 97.551 115.500 ◎ (Reduce Blanking) 1152 x 864 1152 x 864_75 75.000 67.500 108.000 BenQ 1024 x 576 60.000 35.820 46.996 Notebook Timing BenQ 1024 x 600 64.995 41.467 51.419 Notebook Timing 1280 x 720 1280 x 720_60 60.000...
  • Page 72 Refresh Clock 3D Frame 3D Top Resolution Mode Frequency Side- Rate (Hz) (MHz) Sequential Bottom (kHz) by-Side 1360 x 768 1360 x 768_60 60.015 47.712 85.500 ◎ ◎ 1440 x 900 WXGA+_60 59.887 55.935 106.500 ◎ ◎ 1400 x 1050 SXGA+_60 59.978 65.317...
  • Page 73 Supporting timing for HDMI Video input Horizontal Vertical Clock 3D Frame 3D Top Side- Timing Resolution Frequency Frequency Frame Frequency Sequential Bottom (KHz) (Hz) Packing (MHz) Side 480i 720 (1440) x 480 15.73 59.94 27.00 ◎ 480p 720 x 480 31.47 59.94 27.00...

  • Page 74: Warranty And Copyright Information

    Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.

  • Page 75: Pjlink

    PJLink PJLink protocal The network function of this projector support the PJLink class 1, and the PJLink protocal can be used to perform projector setting and projector status query operations from a computer. Control commands The following table lists the PJLink protocal commands that can be used to control the projector.
  • Page 76 Parameter Control Command /Return Remark details string Input selection list INST? SH753P 11 21 31 32 query Projector Returns the name set in [PROJECTOR NAME? xxxxx name query NAME] of [NETWORK SETUP] Manufacturer INF1? BenQ Returns manufacturer name name query...
