Svan SVMW821EIB Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
SVMW821EIB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SVMW821EIB and is the answer not in the manual?

Questions and answers

Related Manuals for Svan SVMW821EIB

Summary of Contents for Svan SVMW821EIB

  • Page 1 SERVICE MANUAL SVMW821EIB...
  • Page 2 November, 2017 This document is published to be used for after sales service only. The content are subject to change without prior notice. In interest of user safety the appliance should be restored to its original condition and only parts identical to those should be applied.

  • Page 3: Table Of Contents

    CONTENTS CAUTIONS INSTALLATIONS SERVICE INFORMATION TOOLS AND MEASURING INSTRUMENTS MICROWAVE LEAKAGE TEST MEASUREMENT OF MICROWAVE POWER OUTPUT DISASSEMBLY AND ADJUSTMENT 1. Trim Assembly Removal 2. Outer Case Removal 3. Power Supply Cord Removal 4. Control Panel Assembly Removal 5. Door Assembly Removal 6.

  • Page 4: Cautions

    CAUTIONS Unlike other appliances, the microwave oven is MICROWAVE RADIATION high-voltage and high-current equipment. Personnel should not be exposed to the Though it is free from danger in ordinary use, microwave energy which may radiate from the extreme care should be taken during repair. magnetron or other microwave generating device if it is improperly used or connection.

  • Page 5: Installations

    INSTALLATIONS BEFORE YOU BEGIN, READ THE FOLLOWING INSTRUCTIONS COMPLETELY AND CAREFULLY. INSTALLING EARTHING INSTRUCTIONS This microwave oven is designed to be used in a fully 1. Empty the microwave oven and clean inside it with earthed condition. a soft, damp cloth. Check for damage such as It is imperative, therefore, to make sure it is properly misaligned door, damage around the door or dents earthed before servicing...

  • Page 6: Service Information

    SERVICE INFORMATION TOOLS AND MEASURING INSTRUMENTS NECESSARY TOOLS NECESSARY MEASURING INSTRUMENTS Tools normally used for TV servicing are sufficient. • TESTER(VOLTS-DC, AC., Ohmmeter) Standard tools are listed below. • Microwave survey meter • Diagonal pliers - Holaday HI-1500 • Long nose pliers HI-1501 •...
  • Page 7 MEASUREMENT WITH A FULLY MEASUREMENT WITH OUTER CASE ASSEMBLED OVEN REMOVED • • After all components, including the outer case, are fully When you replace the magnetron, measure for assembled, measure for microwave energy leakage microwave energy leakage before the outer case is around the door viewing window, the exhaust opening, installed and after all necessary components are and air inlet openings.

  • Page 8: Measurement Of Microwave Power Output

    MEASUREMENT OF MICROWAVE POWER OUTPUT • Microwave power output measurement is made with is measured while the microwave generator is the microwave oven supplied at its rated voltage and operating at full power. Magnetron filament heat-up operated at its maximum microwave power setting with time is not included.

  • Page 9: Control Panel Assembly Removal

    REMOVAL 1) Discharge the high voltage capacitor. 2) Disconnect the leadwire from magnetron, high voltage transformer, and capacitor. 3) Remove the screw holding the high voltage transformer to the baseplate. ORIFICE ASSEMBLY REMOVAL 1) Discharge the high voltage capacitor. 2) Disconnect the leadwire from fan motor, noise filter and high voltage capacitor.

  • Page 10: Capacitor And Diode Removal

    9. AIR GU IDE ASSEMBLY REMOVAL 11. TURNTABLE MOTOR REMOVAL 1) Disconnect the leadwire from lamp, A.C Relay and 1) Remove the glass tray. 2) Remove the pulley shaft VERY CAREFULLY monitor resistor and magnetron. 3) Lay the unit down on its back. 2) Remove the screw to the cavity.

  • Page 11: 2. Pcb Assembly Removal

    2. PCB ASSEMBLY REMOVAL 3) INSTALLATION AND ADJUSTMENT OF THE 1) Remove the control panel assembly from the LATCH BOARD TO THE OVEN ASSEMBLY cavity. • Mount the latch board to the oven assembly. 2) Remove screws which hold the PCB to •...

  • Page 12: Interlock Continuity Test

    INTERLOCK CONTINUITY TEST WARNING : FOR CONTINUED PROTECTION AGAINST EXCESSIVE RADIATION EMISSION, REPLACE ONLY WITH IDENTICAL REPLACEMENT PARTS. TYPE NO. KW3A FOR SWITCHS 2 . SECONDARY INTERLOCK SWITCH TEST 1 . PRIMARY INTERLOCK SWITCH TEST Disconnect the wire lead from the secondary When the door release button is depressed slowly switch.

  • Page 13: Component Test Procedure

    COMPONENT TEST PROCEDURE CAUTIONS 1. DISCONNECT THE POWER SUPPLY CORD FROM THE OUTLET WHENEVER REMOVING THE OUTER CASE FROM THE UNIT. PROCEED WITH THE TEST ONLY AFTER DISCHARGING THE HIGH VOLTAGE CAPACITOR AND REMOVING THE WIRE LEADS FROM THE PRIMARY WINDING OF THE HIGH VOLTAGE TRANSFORMER.
  • Page 14 COMPONENTS TEST PROCEDURE RESULTS Antenna Gasket Chassis Filament NOTE: When testing the magnetron, be sure to install the magnetron gasket in the correct position and be sure that the gasket is in good condition. HIGH VOLTAGE Measure the resistance. Normal: Momentarily indicates CAPACITOR (Ohm-meter scale: Rx1000) several ohms, and then...
  • Page 15 COMPONENTS TEST PROCEDURE RESULTS FUSE Check for continuity of the fuse with an Normal Abnormal multi-meter. NOTE: If the fuse is blown, check the primary, the secondary, and the monitor switches, H.V.D. and H.V.C. before replacing the fuse. If the fuse is blown by improper switch operation replace the defective switch and the fuse at the same time.
  • Page 16 COMPONENTS TEST PROCEDURE RESULTS Check for P.C.B. connector. L.V.Transformer of P.C.B Normal Abnormal Disconnect the 3 pin (Refer to schemetic diagram) connector from P.C.B. 1 3 5 Cooking Start RELAY 2, RELAY 3 Relay 3 OF P.C.B. (Wire leads removed.) Relay 1 Note: Relay Relay 1: Fan motor...

  • Page 17: Trouble Shooting

    TROUBLE SHOOTING WHEN YOU GET A COMPLAINT FROM YOUR CUSTOMER, EVALUATE THE COMPLAINT CAREFULLY. IF THE FOLLOWING SYMPTOMS APPLY, PLEASE INSTRUCT THE CUSTOMER IN THE PROPER USE OF THE MICROWAVE OVEN. THIS CAN ELIMINATE AN UNNECESSARY SERVICE CALL. CAUTIONS 1. Check grounding before checking for trouble. 2.
  • Page 18 (TROUBLE 1) The following visual conditions indicate a probable defective control circuit. 1. Incomplete segments. • Segment missing. • Partial segment missing. • Digit flickering (NOTE: Slight flickering is normal.) 2. Colon does not turn on or blink. 3. A distinct change in the brightness of one or more numbers in display. 4.
  • Page 19 (TROUBLE 2) Oven does not operate at all ; Display window does not display any figures and no input is accepted. CONDITION CHECK RESULT CAUSE REMEDY Malfunction of the Replace primary Check continuity 1. Fuse blows. Continuity. monitor switch. and monitor of monitor switches.
  • Page 20 (TROUBLE 3) Display shows all figures set, but oven does not start cooking while desired program times are set and START pad is touched. CONDITION CHECK RESULT CAUSE REMEDY Replace Defective Check continuity 1.Setting time does No continuity. secondary switch. secondary switch.
  • Page 21 (TROUBLE 5) No microwave oscillation even though oven lamp and fan motor run (Display operates properly) CONDITION CHECK RESULT CAUSE REMEDY No microwave Disconnect the Defective P.C.B Replace P.C.B No continuity. oscillation. wire leads from assembly assembly relay 2 and check continuity Continuity.
  • Page 22 (TROUBLE 6) Oven does not cook properly when programmed for the set power level (Operates properly on HIGH) CONDITION CHECK RESULT CAUSE REMEDY Defective P.C.B. Replace P.C.B. Output is full when Disconnect the Abnormal. assembly. assembly. you set lower wire leads from power level.
