- Page 1 Installation Drawing Pub. May 2020 Page 1/8 Pressalit 1000 Height Adjustable Changing Table R8403 (Adult Size) R8402 (Child Size) Find more product information on our website: R8403 -- Adult Size R8402 -- Child Size Subject to change without further notice.
-
Page 2: Installation Drawing
Installation Drawing Pub. May 2020 Page 2/8 Mounting Instruction Please read and carefully follow these instructions. Find the product number on the product label and ensure that these assembly instructions match your product. WARNING: Failure to comply with these instructions may result in accidents involving serious personal injury or the product being damaged. - Page 3 Installation Drawing Pub. May 2020 Page 3/8 V8608 Ø10 x 70 fischer SX 12 Concrete >B25 V8608 Ø10 x 70 fischer SX 12 Solid Brick >= Mz12 V8608 Ø10 x 70 fischer SX 12 Solid Sand Lime Brick >= Hlz12 V8658 Ø10 x 70 fischer GB 14...
- Page 4 Pub. May 2020 Page 4/8 3500 mm Control box with transformer 230V, 50/60HZ R8402 / R8403: 120V International protection rating: IPX6 Water projected in powerful jets -- from a nozzle up to 12.5 mm in size -- against the product from any 3500 mm direction shall have no harmful effects.
- Page 5 Mounting Dimensions/ Wiring Options Pub. May 2020 Page 5/8 Wall socket/Hard wire within install room Fig. 2 54 0 (2 1 34 0 (1 3 2 0 ( 1 0 3 0 ( 4 0 ) 9 0 ( 3 130 (5 80-100 Hard wire/wall socket to an adjacent room through wall or ceiling...
- Page 6 Installation Drawing Pub. May 2020 Page 6/8 1 1 5 7 5 0 ( 2 9 1 1 7 0 ( 4 6...
- Page 7 Pressalit 1000 Height Adjustable Changing Table Dimensions Pub. May 2020 Page 7/8 735 (28 285 (11 115 (4 1640 1240 ( 34 ⁄ ) ( 18 ⁄ )
- Page 8 Pressalit 1000 Height Adjustable Changing Table Dimensions Pub. May 2020 Page 8/8 75 0 R8402 Child Size 1 1 5 75 0 R8403 Adult Size...
- Page 9 Wall Reinforcement Guide 2019-06-07 · 1/7 Load bearing installation recommendations Pressalit can only be held responsible for installations carried out by Pressalit’s own installers. Pressalit can not be held responsible for reinforcements made in a faulty manner. The below recommendations are based on experience and internal test results. The below recommendations are to be considered as guidelines only.
- Page 10 FTP K 6 M5 x 50 88 Ibs Please refer to installation drawings and specification pages (go to max-ability.com) for further information about which types of bolts/anchors are recommended on specific wall types. MAX-Ability provides concrete anchors at no additional charge.
- Page 11 Wall Types 2019-06-07 · 3/7 Choose the appropriate anchor for your wall Concrete > B25 Plug Anchor Maximum load fischer SX 12 Ø10 x 70/80 375 Ibs. fischer SX 10 Ø8 x 70/80 265 Ibs fischer SX 6 Ø5 x 50 143 Ibs Solid brick >= Mz12 Plug...
- Page 12 Wall Types 2019-06-07 · 4/7 Drywall Anchor Maximum load (2 X 0.5”) water-resistant, re-enforced with wood Ø10 x 70/80 265 Ibs Ø8 x 70/80 220 Ibs Ø5 x 50 88 Ibs Drywall Anchor Maximum load (2 X 0.5”) water-resistant, re-enforced with 1” plywood fischer KD8 toggle 293 Ibs Wingit...
- Page 13 Reinforcement Diagram 2019-06-07 · 5/7 Reinforcement of wall with 1.5-2” wood Reinforcements of walls should always comply with national standards. Metal or wood studs Drywall (2 X 0.5” water-resistant) Wood (1.5-2”) Please refer to mounting instructions for indication of the placement in height of wood plate.
- Page 14 Reinforcement Diagram 2019-06-07 · 6/7 Reinforcement of wall with plywood Reinforcements of walls should always comply with national standards. Metal or wood studs Drywall (2 X 0.5” water-resistant) Plywood (1 X 0.5”) Please refer to mounting instructions for indication of the placement in height of plywood plate.
- Page 15 Reinforcement Diagram 2019-06-07 · 7/7 Reinforcement of wall with steel Reinforcements of walls should always comply with national standards. Metal studs Drywall (2 X 0.5” water-resistant) Steel plate (1 X 0.1”) Please refer to mounting instructions for indication of the placement in height of steel plate.
