- Page 1 Pressalit 1000 User Manual Showering table 1000 – Operation and maintenance manual Height Adjustable Changing Table R8402 (Child Size) R8403 (Adult Size) MAX-Ability, Inc. 800.577.1555 info@max-ability.com...
- Page 2 For more information about this product, click here or go to max-ability.com/product/pc-1000-adult-changing-table/ The guarantee covers faults or defects in material or manufacture within a period of 5 years. Products are subject to minor technical modifications and design deviations. E.&O.E. 800.577.1555 info@max-ability.com...
-
Page 3: Table Of Contents
A mounting instruction is included with the product . It can also be downloaded from www .pressalit .com . Operational signage An operational signage is included with the product . It can also be downloaded from www .pressalit .com . 800.577.1555 info@max-ability.com... -
Page 4: Symbols Used In This Manual
Electricity or potentially Head injury warning . warning dangerous voltage . Specific safety CAUTION • Never leave a person lying on the changing table without supervision. Always be careful when moving a person to and from the table. • 800.577.1555 info@max-ability.com... -
Page 5: General Safety
Assembly instruction . • Pressalit cannot be held liable if the product is used in any way which differs from that described in the guide . • We reserve the right to amend this manual without prior notice . 800.577.1555 info@max-ability.com... -
Page 6: Product Label
Pressalit A/S, Pressalitvej 1 DK-8680 Ry +45 8788 8777, www.pressalit.com ⑩ ⑪ ⑫ ⑬ ⑭ ① Article number ② Production date ③ Maximum user weight ④ Consult manual for use ⑤ Safe working load ⑥ Mains voltage ⑦ Frequency 800.577.1555 info@max-ability.com... - Page 7 Directive 2007/47/EEC . It also complies with all relevant requirements in the Council Directive 2006/42/EC (of 17 May 2006) on machinery and with Council Directive 2011/65/EC (of 8 June 2011) on RoHS . A declaration of conformity can be found at www .pressalitcare .com . 800.577.1555 info@max-ability.com...
-
Page 8: Intended Use
Salt and chloride have a corrosive effect on the products components and will cause a decrease in the life expectancy of the product . The damaging effects can, however, be reduced if the product is showered with tap water on a daily basis . 800.577.1555 info@max-ability.com... -
Page 9: Versions
Versions www.max-ability.com R8402 R8403 800.577.1555 info@max-ability.com... -
Page 10: Operating Instructions
. The safety rail will automatically lock into position . To fold the safety rail away: Release the two locks simultaneously and ② swing the safety rail down under the shower table . 800.577.1555 info@max-ability.com... -
Page 11: Height Adjustment
Press and hold the Up button to raise the shower table, and press and hold the Down button to lower the shower table . Make sure that there is no objects under the shower table when operating the height adjustment system. 800.577.1555 info@max-ability.com... -
Page 12: Cleaning
.com CAUTION Always read the material safety data sheet (MSDS) and supplied instructions of the cleaning, disinfecting or de-scaling agent and comply with instructions for safe use, dilution, rinsing, drying, handling and storage of the agent . 800.577.1555 info@max-ability.com... -
Page 13: Maintenance
Disconnect mains before removing the covers. Maintenance inspection • Check the hinges on the shower table and the safety rail . Tighten if ① ② necessary . • Check the canvas for damage and replace if necessary . ③ 800.577.1555 info@max-ability.com... - Page 14 . • Oil moving parts, especially the sliding brackets ⑥ • Check all electrical connections to the control ⑦ • Put the unit cover back again and tighten the retaining screws . • Reconnect mains . 800.577.1555 info@max-ability.com...
-
Page 15: Trouble-Shooting
Trouble-shooting www.max-ability.com Symptom Cause Action The changing table The gas cylinders is Contact MAX-Ability. does not stay in defective . upright position . The product will not Fault in power supply . Check that all wires and work, even though... -
Page 16: Technical Data
IPX6 . The product may not be immersed in water, but is designed to withstand powerful jets (12 .5 mm nozzle) of water from any direction . Power specifications Max consumption 70 W Voltage Mains connection: 230V/120V/100V Frequency 50/60 Hz Current 0,3 A 800.577.1555 info@max-ability.com... -
Page 17: Dimensions (Mm)
Dimensions (mm) www.max-ability.com 1 1 5 7 5 0 R8402 1 1 5 7 5 0 R8403 800.577.1555 info@max-ability.com... -
Page 18: Dimensions (Inches)
Dimensions (inches) www.max-ability.com 4 . 5 2 2 9 . 5 2 R8402 4 . 5 2 2 9 .5 2 R8403 800.577.1555 info@max-ability.com... -
Page 19: Disposal And Recycling
. Electronics The electronic components should be collected separately and returned to the designated recycling service . 800.577.1555 info@max-ability.com...
