- Page 1 SCALA Digital Technology(Ningbo) Co., Ltd. Version ：V1.0 AMD R1505G Player SMPA-R1505G User Manual...
- Page 2 ：V1.1 1、Product Overview SMPA-R1505G PLAYERI is a smart player box that supports Windows and Linux operating systems. Customers can develop their own under this system. (for detailed configuration, please refer to the product configuration parameter table of SMPA-R1505G Player box). Customers can use the player box to provide multimedia content of the display through documents or network Figure 1、Product interface diagram：...
- Page 3 SCALA Digital Technology(Ningbo) Co., Ltd. Version ：V1.1 2）. External USB device: In the state of connected external display device, USB mouse and USB keyboard can be connected through USB2.0 and USB3.0 ports to realize interface switching, data input and output and other functions.
- Page 4 SCALA Digital Technology(Ningbo) Co., Ltd. Version ：V1.1 3）. Wired, wireless networking and WiFi functions: The player box can be connected to the network through RJ45 port and wifi antenna for network data transmission. Figure 4: wired and wireless networking setting interface entrance Figure 5: Bluetooth setting interface entry 4）.
- Page 5 7). Equipment reset: in case of equipment crash, the device can be forced to restart by pressing reset hidden button. 4. firmware upgrade: The player box is equipped with the best firmware at the factory. Customers need to contact Scala if they have firmware requirements. 5. packing configuration...
- Page 6 SCALA Digital Technology(Ningbo) Co., Ltd. Version ：V1.1 2. 12V / 5A adapter, 1pcs; 3. HDMI transfer line, 1pcs; 4. Install screw pack, 1pcs; SCALA Digital Technology(Ningbo) Co., Ltd. Address: No. 7 Hong Da Road , Jiang Bei District, Ning Bo,Zhe Jiang...
- Page 7 SCALA Digital Technology(Ningbo) Co., Ltd. Version ：V1.1 Network RTL8111H 1 x DC input[with anti-loose mechanism], 4 x USB3.0 2xAudio Jack (Front-L/R + ,Aux-In) 2 x HDMI Output (HDMI 2.0，up to 2160@60fps , support HDCP) 1x HDMI IN (PCIE, 1080P, Option) or 2nd 1G Ethernet...
- Page 8 SCALA Digital Technology(Ningbo) Co., Ltd. Version ：V1.1 FCC Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
