- Page 1 ：V1.1 SCALA Digital Technology (Ningbo) Co., LTD Version SMPA-R1305G PLAYER User Manual 2021 December...
- Page 2 Version 1、Product Overview SMPA-R1305G PLAYERI is a smart player box that supports Windows and Linux operating systems. Customers can develop their own under this system. (for detailed configuration, please refer to the product configuration parameter table of SMPA-R1305G Player box).
- Page 3 ：V1.1 SCALA Digital Technology (Ningbo) Co., LTD Version 3、Instructions 1）、External display： The player box HDMI out is connected with the external display HDMI in through the HDMI cable to realize the display interface output; The external device can input interface data through the player box HDMI in, and the player box can synchronously output the display interface from the HDMI out to the external display.
- Page 4 ：V1.1 SCALA Digital Technology (Ningbo) Co., LTD Version Figure 3: USB insertion display in Explorer 3）. Wired, wireless networking and WiFi functions: The player box can be connected to the network through RJ45 port and wifi antenna for network data transmission.
- Page 5 ：V1.1 SCALA Digital Technology (Ningbo) Co., LTD Version Figure 5: Bluetooth setting interface entry 4）. Audio transmission: The player box can transmit audio with external player equipment through aux port. Figure 6: sound adjustment...
- Page 6 ：V1.1 SCALA Digital Technology (Ningbo) Co., LTD Version 5）. Serial communication: The external equipment can realize the RS232 serial communication function through the COM port of the player box. 6). Extended switch machine: (it needs to be refitted professionally, temporarily omitted, you can contact the manufacturer) 7).
- Page 7 ：V1.1 SCALA Digital Technology (Ningbo) Co., LTD Version R PLAYER Product configuration parameters Spec Date: 3 JAN, 2021 Scala SMPA Play Product Descriptions SUPPORT window10，Linux-Ubuntu AMD RYZEN EMBEDDED R1305G or R1505G Graphics AMD Vega GPU with up to 3 Compute Units Hardware &...
- Page 8 ：V1.1 SCALA Digital Technology (Ningbo) Co., LTD Version 1 x DC input[with anti-loose mechanism], 4 x USB3.0 2xAudio Jack (Front-L/R + ,Aux-In) 1 x HDMI Output (HDMI 2.0，up to 2160@60fps , support HDCP) 1x HDMI IN (PCIE, 1080P, Option) or 2nd 1G Ethernet...
- Page 9 ：V1.1 SCALA Digital Technology (Ningbo) Co., LTD Version FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
