Meler B4 VS Instruction Manual

Adhesive melter
Hide thumbs
Table of Contents

Advertisement

Quick Links

GLUING SOLUTIONS
ADHESIVE
INSTRUCTIONS
MANUAL
MELTER
B4 VS
MA-5082-ENG 170122

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B4 VS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Meler B4 VS

Summary of Contents for Meler B4 VS

  • Page 1 GLUING SOLUTIONS ADHESIVE INSTRUCTIONS MANUAL MELTER B4 VS MA-5082-ENG 170122...
  • Page 2 Published by: Focke Meler Gluing Solutions, S.A. Pol. Arazuri-Orkoien, c/B, nº3 A E-31170 Arazuri - Navarra - Spain Phone: +34 948 351 110 info@meler.eu - www.meler.eu Focke Group Edition Januari 2022 © Copyright by Focke Meler All rights reserved. Its reproduction, diffusion or use by electronic or other means of all or any part of this document without the express authorization of its owner is strictly prohibited.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL TABLE OF CONTENTS 1. SAFETY GUIDELINES General Symbols Mechanical components Electrical components Hydraulic components Pneumatic components Thermal components Materials Noise emission declaration Intended use Limited use 2. INTRODUCTION Description Intended use...
  • Page 4 MELER GLUING SOLUTIONS TABLE OF CONTENTS Installation requirements Free space Electrical consumption Compressed air Other factors Unpacking Contents Mounting the equipment Electrical power supply connection Pneumatic connection Hose and applicator connection Programming parameters Programming working temperatures Selecting the overheating value...
  • Page 5 TABLE OF CONTENTS MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL Setting the clock Setting the current day and time Programming equipment activation/deactivation Disabling the equipment activation/deactivation program Programming the activation/deactivation of the equipment’s standby function Disabling the equipment standby function program...
  • Page 6 MELER GLUING SOLUTIONS TABLE OF CONTENTS 5. MAINTENANCE External cleaning System depressurisation Cleaning the tank Changing adhesive type Cleaning burnt adhesive Emptying the tank Filter maintenance Pump maintenance Leakage inspection Gear motor maintenance Cleaning the motor fan Checking the lubricant...
  • Page 7 TABLE OF CONTENTS MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL 8. PNEUMATIC DRAWINGS Components list Pneumatic by-pass valve control system (optional) Air drying system (optional) 9. SPARE PART LIST A. TANK GROUP B. DISTRIBUTOR UNIT C. MOTOR- PUMP UNIT D. ELECTRIC PANEL AND AUXILIARY COMPONENTS E.
  • Page 8 MELER GLUING SOLUTIONS TABLE OF CONTENTS A6. TECHNICAL CHARACTERISTICS A-11 General A-11 Dimensions A-12 Melting unit A-12 Accesories A-12 Level control system A-12 Air drying system for PUR adhesives A-12 A7. ELECTRICAL DRAWINGS A-13 A8. PNEUMATIC DIAGRAM A-15 Component list...

  • Page 9: Safety Guidelines

    SAFETY GUIDELINES MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL 1. SAFETY GUIDELINES General The information contained in this section applies not only to everyday equipment operation, but also to any procedure carried out on it, whether for preventive maintenance or in the case of repairs and the replacement of worn out parts.

  • Page 10: Mechanical Components

    FOCKE MELER GLUING SOLUTIONS SAFETY GUIDELINES Mechanical components The hot-melt installation, which is installed to this device, requires moving parts that can cause damage. Use the equipment correctly, and do not remove the safety guards while the equipment is in operation; prevent the risk of possible entrapment due to moving mechanical parts.

  • Page 11: Thermal Components

    Safety Information Sheet of the adhesive. Materials Meler systems are designed for use with hot-melt adhesives. They should not be used with any other type of material, and especially not with solvents, which may cause personal injury or damage to internal system components.

  • Page 12: Intended Use

    Note: Do not modify the equipment or use components that were not supplied by Meler. For any modification of a component of the equipment or part of the installation, you must firstly consult the After-Sales Service...

  • Page 13: Introduction

    B4 VS ADHESIVE MELTER MANUAL 2. INTRODUCTION In this manual you will find information about the installation, use and maintenance of ‘B4 VARIABLE SPEED’ (hereingafter B4 VS), adhesive melter of Meler. It is designed to be used commonly in manual applications with EVA based...

  • Page 14: Description

    Limited use The B4 VS melter should be used as intended and under no circumstances should it be used in the following conditions: •...

  • Page 15: Melter Identification

    INTRODUCTION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL Control of external pumping and internal speed_Switches in the position ok ‘ext’ and ref ’int’. This mode of operation is performed through external pumping control and manual speed control. Control of external pumping and speed_Switches in the position ok ‘ext’...

  • Page 16: Main Components

    FOCKE MELER GLUING SOLUTIONS INTRODUCTION Main components 1. Front control card. 7. Purge valve. 2. Pumping control card. 8. Filter pump. 3. Hose- applicator electrical connection. 9. Pump system connection switch (optional). 4.Hose- applicator hydraulic connection. 10. Warning light (optional).

  • Page 17: Optional Equipment

    INTRODUCTION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL Optional Equipment In order to provide the melting equipment with more functions, the following optional elements may be added: • Air-tight lid. • Air drying system for use with PUR adhesives. • Automatic feeding system.

  • Page 18: Pumping Control Card Components

    FOCKE MELER GLUING SOLUTIONS INTRODUCTION Pumping control card components 1. Main switch ON/OFF. 2. External start-stop LED. 3. External speed control LED. 4. Pumping permission LED. 5. Up/down arrow keys for selecting values. 6. Left/right arrow keys for selecting options.

  • Page 19: Installation

    Introduction The B4 VS melter is supplied with all the components required for its installa- tion. However, some components must be supplied by the user depending on the location and connections in each specific installation: •...

  • Page 20: Electrical Consumption

    The B4 VS melter should be installed with a power switch to disconnect it from its power supply source. A circuit breaker should be installed as personal protection against earth leakages.

  • Page 21: Unpacking

    Fit the retaining flanges onto the base and position the four fastening screws. Electrical power supply connection The B4 VS melter is designed to be connected to the electrical power supply with single-phase 230 VAC and neutral, depending on the power consumption.

  • Page 22: Pneumatic Connection

    Hose and applicator connection The B4 VS melter can use standard Meler components. The entire range of Meler hoses and applicators may be connected to this equipment. The B4 VS melter has two outputs for connecting the hose-applicator for only one installed pump.

  • Page 23: Programming Parameters

    Once the melter and its components have been installed, the correct working parameters must be programmed for the specific application to be performed. The B4 VS melter simplifies this task as much as possible, allowing the operator to change only those parameters which are necessarily variable for each application.

  • Page 24: Keeping A Component On Display

    FOCKE MELER GLUING SOLUTIONS INSTALLATION 3. Use the up-down arrows on the right of the front card to select the desired value. - - - The value displayed corresponds to the increase in real temperature over the set point temperature permitted without activating the alarm message (between 10 and 25).

  • Page 25: Temperature Ok

    INSTALLATION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL • Motor start up_for each pump installed, the motor start up may be controlled by closing an external non-voltage contact. • Motor speed set point_for each pump installed, the rotational speed of the motor (and therefore, the pump) may be controlled by means of a 0 to 10V DC external signal.

  • Page 26: Starting Up The Motor (Ok Ext)

    FOCKE MELER GLUING SOLUTIONS INSTALLATION 2. Remove the six screws fastening the connection support plate and power switch, on the left side of the equipment. Pass the signal cable (Ø4-8 mm) through the bushing Pg9 and attach to the internal fitting, ensuring that the cable reaches the control board connector at the point where it is to be installed (CN4).

  • Page 27: Motor Speed Set Point Reference (Ref Ext)

    INSTALLATION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL Motor speed set point reference (ref ext) 1. If this is the only signal being connected, use 0.5 mm two-wire cable. Install an electrical wall bushing Pg9 on the equipment base plate next to the electrical supply input.
  • Page 28 FOCKE MELER GLUING SOLUTIONS INSTALLATION 5. Check that the cable is correctly connected and that its passage through the electric cabinet presents no risk of jamming, being cut or any other accidental damage. Warning: It must be connected to 24 AC or DC voltage with a maximum current of 1A.

  • Page 29: Melter Operation

    MELTER OPERATION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL 4. MELTER OPERATION This section explains how to operate the melter. Although the equipment is very easy to operate, it should not be used by untrained personnel. Warning: Improper use may cause damage to the equipment itself or the person using it and can even result in death.

  • Page 30: Loading The Adhesive

    FOCKE MELER GLUING SOLUTIONS MELTER OPERATION Loading the adhesive To fill the tank: 1. Open the tank lid. 2. Use a shovel or a ladle to fill the tank with adhesive. Do not fill the tank above the loading opening level. The lid must be able to close normally.

  • Page 31: Melter Displays

    20°C below the set point temperature. Melter displays The control panel on the B4 VS melters have two displays, each with three sets of 7 segments to display the temperature values (set point and actual temperature), the programmable parameters and alarms.

  • Page 32: Temperature Display For Each Component

    To permanently remove a component from the display, simply press any of the up-down arrows. Alarm display The B4 VS melters inform the user when there is a malfunction in the unit, by sending messages that can be seen on the control panel display. E r r...

  • Page 33: Temperature Adjustment

    MELTER OPERATION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL Actions Code Cause Heating Pump Main machine signal tank broken sensor only tank off hose1 broken sensor only hose1 off applicator1 broken sensor only applicator1 off hose2 broken sensor only hose2 off...

  • Page 34: Programming The Melter Parameters

    FOCKE MELER GLUING SOLUTIONS MELTER OPERATION Programming the melter parameters 1. Simultaneously press the buttons with the clock symbol and down arrow to enter the special menu. The choice of temperature display units (°C or °F) appear on the display.

  • Page 35: Setting The Clock

    MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL Setting the clock The B4 VS melter has a weekly programmable system to control the connection and disconnection of the equipment and activate and deactivate the standby function. Before programming these functions, the day and time the system will use to execute these programs must be entered into the control panel.

  • Page 36: Programming Equipment Activation/Deactivation

    FOCKE MELER GLUING SOLUTIONS MELTER OPERATION Programming equipment activation/deactivation An activation and deactivation time can be set for each day of the week, from Monday (1) to Sunday (7). Time is expressed in increments of 15 minutes, starting with 10.0 (10 hours 0 minutes), then 10.1 (10 hours 15 minutes), 10.2 (10 hours 30 minutes) and 10.3...

  • Page 37: Disabling The Equipment Activation/Deactivation Program

    MELTER OPERATION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL Disabling the equipment activation/deactivation program The programmed equipment activation/deactivation can be disabled without having to cancel the daily programming. In this way the programmed data is saved but the programming has no effect on the equipment.

  • Page 38: Disabling The Equipment Standby Function Program

    FOCKE MELER GLUING SOLUTIONS MELTER OPERATION 3. Use the up-down button under the display to select the value for the desired day of the week, Monday (1) to Sunday (7). 4. Press the button with the clock symbol again. 0 7 . 2 0 7 .

  • Page 39: Special Function Buttons

    1 6 0 1 6 0 Special function buttons The simple programming of the B4 VS melters means that the special function buttons are only used for the standby function. This manual function allows you to alternate between operating mode and standby mode.

  • Page 40: Pump Start-Up

    FOCKE MELER GLUING SOLUTIONS MELTER OPERATION However, take into consideration that PUR adhesive undergoes moisture curing and deteriorates easily at high temperatures and therefore the more time the equipment is left on without pumping, regardless of whether it is left to heat as normal or is in standby mode, the greater the possibility that the adhesive will deteriorate.

  • Page 41: Pumping Safety Measures

    MELTER OPERATION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL Pumping safety measures To prevent the equipment from starting up unexpectedly, the control panel features by default a safety option that prevents pumping from commencing until enabled by pressing the ON-OFF button on the control card. This function may be disabled in the ‘User configuration menu’.

  • Page 42: Led Indicators

    FOCKE MELER GLUING SOLUTIONS MELTER OPERATION menu’, on pressing any key (except the control card ON/OFF and pumping ON/OFF buttons) a password will be required. When the password is entered correctly, the control card can be left operational by setting it to ‘0’. When using this method to access the control card security configuration options, i.e., when the password has been entered, the buttons on the control card...

  • Page 43: Modes Of Operation

    MELTER OPERATION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL 5. Ext on LED: when the equipment is operating in external start-stop (OK) mode, and the external permission contact is closed, this LED will be illuminated; if the external contact is open, this LED is turned off. This LED is green in colour.

  • Page 44: Mode Of Operation With Internal Pumping Control And External Speed Control

    FOCKE MELER GLUING SOLUTIONS MELTER OPERATION The pump will stop whenever: • The control card is disabled with its ON/OFF button. • The pumping ON-OFF button is pressed (red LED is illuminated). • When a variator error signal is activated (E5).

  • Page 45: Mode Of Operation With External Pumping Control And Internal Speed Control

    MELTER OPERATION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL 3. Modify the speed ramp (see section ‘Configuring speed ramp’). Keeping the ‘Vin’ key pressed will show the voltage sent by the main machine. The pump will stop whenever: • The control card is disabled with its ON/OFF button.

  • Page 46: Mode Of Operation With External Pumping Control And External Speed Control

    FOCKE MELER GLUING SOLUTIONS MELTER OPERATION At this moment, the pump will start to rotate at the speed indicated on the display. 4. Adjust the rotation speed to the value required for the application. The selected value is set pressing the right arrow key after blinking three times.

  • Page 47: User Configuration Menu

    ‘User configuration menu’, ‘1. MAXIMUM RPM’. The pump control card is designed with certain parameters programmed at Meler that can be modified if necessary to meet your requirements. Modifications may be made through the user configuration and programming speed ramp menus.

  • Page 48: Displaying Alarms And Reset Function

    FOCKE MELER GLUING SOLUTIONS MELTER OPERATION 1. MAXIMUM RPM ALARM: this will be a value set between 0 and the value programmed in the MAXIMUM RPM field. If we do not wish this alarm to be operational it must be programmed to the MAXIMUM RPM value. The default value is 100 (consequently, alarm not operational).

  • Page 49: Variator Alarm

    MELTER OPERATION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL • To reset this error, you must turn off and start up the control card with its ON/OFF button. Variator alarm This alarm is triggered when the control card input is activated by a variator error signal.

  • Page 50: Programming Speed Ramp

    FOCKE MELER GLUING SOLUTIONS MELTER OPERATION • If, at any point, the maximum value for Vin = 10 V is entered, the corresponding values for Vin and RPM at higher points will be automatically updated according to the value for this point.

  • Page 51: Current Vin Voltage Display

    MELTER OPERATION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL which means that the input voltage value is being programmed for point 4; with the up/down arrow keys the value may be modified, within a range from 00.0 to 10.0 (to one decimal place); press the right arrow key to go to the next...

  • Page 52: Adjusting The Manual Valve

    FOCKE MELER GLUING SOLUTIONS MELTER OPERATION Adjusting the manual valve Follow the steps below to set the pressure using this type of valve (approximate): 1. Screw the spindle in as far as possible in the clockwise direction. In this position, the maximum pressure is 81,5 kg/cm (80 bar).

  • Page 53: Maintenance

    Equipment change - Equipment change or repair Dettaching equipment from base If the equipment does not work or works incorrectly, called to your Meler Technical Assistance Service or to the Main Office. External cleaning To continue to take advantage of the melters benefits and to ensure the perfect mobility of its components, it is necessary to keep all its parts clean, especially the ventilation grates on the of the machine.

  • Page 54: System Depressurisation

    4. Follow steps 1 to 3 in reverse order to close the control panel. System depressurisation The B4 VS melter is a pressurised application system with the corresponding risks that such a system entails. This equipment includes a safety valve (bypass valve) which limits the maximum pressure in the system, particularly during continuous pumping with closed application applicators.

  • Page 55: Cleaning The Tank

    MAINTENANCE MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL Before disconnecting any hydraulic component or opening any distributor outlet, the following steps must be performed: 1. Disconnect the equipment’s power switch located on the side, next to the power supply input. 2. Manually purge (or using the corresponding programmer control) the applicator used.

  • Page 56: Emptying The Tank

    FOCKE MELER GLUING SOLUTIONS MAINTENANCE 2. Clean the adhesive remains and burnt material inside the tank. Do not use sharp objects that might damage the inside coating. Warning: Use appropriate protective equipment for high temperatures. 3. Add the appropriate type and quantity of adhesive and wait for it to melt.

  • Page 57: Filter Maintenance

    MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL Filter maintenance B4 VS melter equipment is equipped with a 100 mesh pump filter. The filter prevents impurities and burnt adhesive remains from being pushed out from the tank by the pump. When the filter is removed from its housing, all the impurities remain inside so that the inside of the distributor stays perfectly clean.

  • Page 58: Pump Maintenance

    Replace the gasket system in the shaft or the gaskets in the seating pump and reassemble. However, before making any changes and in case of doubt should check with the Technical Assistance Service of Meler. Warning: Always wear protective gloves and safety glasses. Risk of burns. Gear motor maintenance Cleaning the motor fan Regularly check the condition of the motor fan and its vent grid.

  • Page 59: Safety Thermostat

    MAINTENANCE MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL Safety Thermostat If there is a deactivation of the thermostat, dismantle the tank casing with the cover and slide the electrical cabinet along. When you can see the thermostat, press the button indicated to reset it.
  • Page 60 FOCKE MELER GLUING SOLUTIONS MAINTENANCE This page is intentionally left blank.

  • Page 61: Technical Characteristics

    TECHNICAL CHARACTERISTICS MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL 6. TECHNICAL CHARACTERISTICS General Tank volume 4 litres Maximum pump flow rate (*) between 1,2 and 15,6 Kg/hr with 2 cc/rev pump Maximum melting rate (*) 6,0 kg/h Number of pumps Number of electrical outputs...

  • Page 62: Dimensions

    FOCKE MELER GLUING SOLUTIONS TECHNICAL CHARACTERISTICS Dimensions Melting unit Base plate * For ML-240-ST series replacement.

  • Page 63: Accessories

    ). Ask you adhesive supplier for more information. Automatic tank filling system Meler pellet loaders ensure a continuous level of adhesive inside the tanks of the melting units, eliminating the need for manual loading by the user. Each time the tank detector detects a low level of adhesive, it sends a signal to the suction system, which transfers a load of pellets to the melting tank from the adhesive container (or directly from the bag it comes in).
  • Page 64 FOCKE MELER GLUING SOLUTIONS TECHNICAL CHARACTERISTICS This page is intentionally left blank.

  • Page 65: Electrical Drawings

    ELECTRICAL DRAWINGS MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL 7. ELECTRICAL DRAWINGS...
  • Page 66 FOCKE MELER GLUING SOLUTIONS ELECTRICAL DRAWINGS This page is intentionally left blank.

  • Page 67: Pneumatic Drawings

    PNEUMATIC DRAWINGS MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL 8. PNEUMATIC DRAWINGS Components list Pneumatic by-pass valve control system (optional) Pressure regulator 1-10 bar Pressure gauge 0-10 bar Pneumatic limit control valve AIR INPUT...

  • Page 68: Air Drying System (Optional)

    FOCKE MELER GLUING SOLUTIONS PNEUMATIC DRAWINGS Air drying system (optional) - 1 Filter– 1st stage Solids/ Oil 5µ < 1ppm - 2 Filter – 2nd stage Solids/ Oil 0,01µ < 0,01ppm - 3 Membrane dryer (Dry air 99,98%) - 4 3/2 solenoid valve...

  • Page 69: Spare Part List

    B4 VS ADHESIVE MELTER MANUAL 9. SPARE PART LIST The most common spare parts list of the B4 VS adhesive melters is shown in this chapter to give you a quick and sure guideline to choose them. The spare parts are listed by groups in a natural order as they are located on the units.
  • Page 70 FOCKE MELER GLUING SOLUTIONS SPARE PART LIST This page is intentionally left blank.

  • Page 71: Tank Group

    SPARE PART LIST MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL A. TANK GROUP Nº Ref. Description 150112110 Complete tank assembly 150026180 PTFE coated tank 150028970 Insulation mantle 150112090 Tank port housing 150024650 Tank gasket 150115280 Tank grid 150021790 Plug with o-ring...

  • Page 72: Distributor Unit

    FOCKE MELER GLUING SOLUTIONS SPARE PART LIST B. DISTRIBUTOR UNIT Nº Ref. Descriptionn 150113810 Relief valve assembly 12330087 Relief valve assembly o-ring 150112820 Relief valve red spring 150026060 Relief valve closing needle 150090390 Relief valve seeger ring 150090360 Tank-distributor seating o-ring...

  • Page 73: Motor- Pump Unit

    SPARE PART LIST MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL C. MOTOR- PUMP UNIT Nº Ref. Description 150026110 2cc/rev gear pump 150090410 Pump seating o-rings 150096570 Seal Ø10+O-ring gear pump set 150026090 Motor coupling 150129260 Gearmotor Wanshin 3~ACΔ VF-B4 (*) 150129230...

  • Page 74: Electric Panel And Auxiliary Components

    FOCKE MELER GLUING SOLUTIONS SPARE PART LIST D. ELECTRIC PANEL AND AUXILIARY COMPONENTS Nº Ref. Description 10000204 Control card 150112410 Fuse 6,3A 5x20 ultra fast 150115650 Fuse 10A 6x32 ultra fast 10010401 Fuse 1A 5x20 150117100 Pumping control card 16010003...
  • Page 75 SPARE PART LIST MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL F5 CH. 2 F4 CH. 1 F1 TANK F2 GENERAL...

  • Page 76: Warning Light Unit (Optional)

    FOCKE MELER GLUING SOLUTIONS SPARE PART LIST E. WARNING LIGHT UNIT (OPTIONAL) Nº Ref. Description 150113710 Colourless warning light R0006220 Lamp 24V 150110140 Capacitive detector 150110150 Rechner amplifier 150090430 24V AC 2- contact relay...

  • Page 77: A1. Safety Guidelines

    General This appendix belongs to ‘B4 VARIABLE SPEED’ version but its operation and working process are identical to this B4 VS series (see chapter ‘1. Safety guidelines’ in this manual). The information contained in this section applies not only to everyday machine operation, but also to any procedure carried out on it, whether for preventive maintenance or in the case of repairs and the replacement of worn out parts.
  • Page 78 FOCKE MELER GLUING SOLUTIONS AIRTIGHT LID This page is intentionally left blank.

  • Page 79: A2. Introduction

    B4 VS MANUAL APPENDIX A2. INTRODUCTION This appendix belongs to B4 VS version and it will find information about the installation, use and maintenance of the hot-melt adhesive melter B4 VS WITH AIR-TIGHT LID to get more information see chapter ‘2. Introduction’ in this manual.
  • Page 80 FOCKE MELER GLUING SOLUTIONS AIRTIGHT LID This page is intentionally left blank.

  • Page 81: A3. Installation

    Installation requirements Before installing B4 VS WITH AIR-TIGHT LID series melter equipment, we must make sure that the space assigned to it permits installing, connecting and using the entire system. Similarly, we must check to see that the electrical and pneumatic supplies meet the necessary requirements of the melter equipment being installed see chapter ‘3.
  • Page 82 FOCKE MELER GLUING SOLUTIONS AIRTIGHT LID This page is intentionally left blank.

  • Page 83: A4. Melter Operation

    AIRTIGHT LID MA-5082-ENG B4 VS MANUAL APPENDIX A4. MELTER OPERATION Airtight lid An airtight lid is incorporate to close the tank. This option is appropriate when the equipment is going to be used with PUR adhesives. PUR adhesives need a totally dry environment before being applied, since in touch with the dampness of the environment they go hard.

  • Page 84: Filling The Tank

    FOCKE MELER GLUING SOLUTIONS AIRTIGHT LID After loading new adhesive or each time that the unit’s tank cover is opened, we recommend using the manual injection method for approximately 60 s. To do this, activate the button on the system’s electrovalve.

  • Page 85: A5. Maintenance

    B4 VS MANUAL APPENDIX A5. MAINTENANCE This part of the appendix refers to B4 VS WITH AIR TIGHT LID. To carry out the maintenance in other parts of the equipment, follow the steps in section ‘Maintenance’ of the B4 VS manual.
  • Page 86 FOCKE MELER GLUING SOLUTIONS AIRTIGHT LID This page is intentionally left blank. A-10...

  • Page 87: A6. Technical Characteristics

    AIRTIGHT LID MA-5082-ENG B4 VS MANUAL APPENDIX A6. TECHNICAL CHARACTERISTICS General Tank volume 4 litres Maximum pump flow rate (*) between 1,2 and 15,6 Kg/hr with 2 cc/rev pump Maximum melting rate (*) 6,0 kg/h Number of pumps Number of outputs...

  • Page 88: Dimensions

    The B4 VS WITH AIR TIGHT LID melting equipment ensures a dry environment thanks to the addition of an air-drying system to these models, which provides a level of dehumidification above 99.98%.

  • Page 89: A7. Electrical Drawings

    AIRTIGHT LID MA-5082-ENG B4 VS MANUAL APPENDIX A7. ELECTRICAL DRAWINGS A-13...
  • Page 90 FOCKE MELER GLUING SOLUTIONS AIRTIGHT LID This page is intentionally left blank. A-14...

  • Page 91: A8. Pneumatic Diagram

    AIRTIGHT LID MA-5082-ENG B4 VS MANUAL APPENDIX A8. PNEUMATIC DIAGRAM Component list Air drying system (optional) - 1 Filter– 1st stage Solids/ Oil 5µ < 1ppm - 2 Filter – 2nd stage Solids/ Oil 0,01µ < 0,01ppm - 3 Membrane dryer (Dry air 99,98%)
  • Page 92 FOCKE MELER GLUING SOLUTIONS AIRTIGHT LID This page is intentionally left blank. A-16...

  • Page 93: A9. Spare Part List

    B4 VS MANUAL APPENDIX A9. SPARE PART LIST The most common spare parts list of the B4 VS WITH AIR TIGHT LID adhesive melters is shown in this chapter to give you a quick and sure guideline to choose them.

  • Page 94: Air Tight Lid

    FOCKE MELER GLUING SOLUTIONS AIRTIGHT LID A. AIR TIGHT LID Nº Ref. Description 150113880 PTFE coated tank 150028970 Insulation mantle 150114550 Tank gasket 150113870 Lid gasket 150117410 Magnetic detector (cover tank) A-18...

  • Page 95: Air Dryer System

    AIRTIGHT LID MA-5082-ENG B4 VS MANUAL APPENDIX B. AIR DRYER SYSTEM Nº Ref. Description 150110060 Air dryer cartridge W07M 150110400 Air filter Norgren F92G-NNN-AT1 (G1/4) 150110390 Air filter Norgren F92C-NND-AT0 (G1/4) 10110031 Pressure regulator 150029540 Pressure regulator 0,1-0,7 bar 150029550...

  • Page 96: Warning Light Unit (Optional

    FOCKE MELER GLUING SOLUTIONS AIRTIGHT LID C. WARNING LIGHT UNIT (OPTIONAL) Nº Ref. Description 150113710 Colourless warning light R0006220 Lamp 24V 150110140 Capacitive detector 150110150 Rechner amplifier 150090430 24V AC 2- contact relay A-20...

  • Page 97: Ec Declaration Of Conformity

    EC DECLARATION OF CONFORMITY Original Declaration The manufacturer, Focke Meler Gluing Solutions, S.A. P.I. Arazuri-Orkoien, c/B, nº3 A E - 31170 Arazuri - Navarra - Spain — Focke Group — declaring that the machinery, Type: Model: Serial Number: fulfils all the relevant provisions of the Directive 2006/42/EC on machinery,...
  • Page 98 For more information speak with your Focke Meler representative: Focke Meler Gluing Solutions, S.A. Pol. Arazuri-Orkoien, c/B, nº3 A E-31170 Arazuri - Navarra - Spain Phone: +34 948 351 110 info@meler.eu - www.meler.eu Focke Group...

This manual is also suitable for:

B4 variable speed

Table of Contents
