Tennsmith LM1010 Operation, Parts & Maintenance Manual

Power back gauge mechanical shear
Hide thumbs

Advertisement

Quick Links

Download this manual
MODEL LM1010 POWER BACK GAUGE
OPERATION, PARTS & MAINTENANCE MANUAL
Model:
Serial #:
6926 Smithville Hwy., McMinnville, TN 37110
931-934-2211 / Fax: 931-934-2220
www.tennsmith.com
MECHANICAL SHEAR
Purchased From:
Date Received:
Model LM1010 Performance "R"

Advertisement

loading
Need help?

Need help?

Do you have a question about the LM1010 and is the answer not in the manual?

Questions and answers

Related Manuals for Tennsmith LM1010

Summary of Contents for Tennsmith LM1010

  • Page 1 Model LM1010 Performance “R” MODEL LM1010 POWER BACK GAUGE MECHANICAL SHEAR OPERATION, PARTS & MAINTENANCE MANUAL Model: Purchased From: Serial #: Date Received: 6926 Smithville Hwy., McMinnville, TN 37110 931-934-2211 / Fax: 931-934-2220 www.tennsmith.com...
  • Page 2 TABLE OF CONTENTS SUBJECT PAGE NUMBERS SHEAR SPECIFICATIONS WARRANTY INFORMATION SAFETY LABELING AND INSTUCTIONS INSTALLATION OPERATING INSTRUCTIONS 11-13 BLADE CLEARANCE/ADJUSTMENT BLADE ROTATION/REPLACING 15-16 BACKGAUGE INFORMATION HOLDDOWN INFORMATION SHEET SUPPORT SYSTEM INFORMATION MAINTENANCE 20-21 PARTS VIEW AND DESCRIPTIONS 22-29 ELECTRICAL DIAGRAM 30-31 MOTOR AND GEARBOX INFORMATION 32-43...

  • Page 3: Year Limited Warranty

    9,500 lbs. 3-YEAR LIMITED WARRANTY TENNSMITH machinery and component parts are carefully inspected at various stages of production and are tested and inspected prior to shipment. We agree that for a period of twelve (12) months from the date of delivery from our authorized distributor to replace, at our option, any machine (or component part thereof) proving defective within the above period.
  • Page 4 Please verify that the following safety decals are attached to the LM Shear. If you do not locate all of the decals, please contact Tennsmith to replace any missing or unreadable safety labels. NEVER operate this machine without the proper safety labeling.

  • Page 8: Safety Instructions

    SAFETY INSTRUCTIONS Do not operate service or perform maintenance prior to reading and understanding the instruction manual. Become familiar with and understand the hazards and limitations of your shear. Wear approved eye protection and protective footwear while operating the machine. Be certain this machine is properly wired and grounded to conform to the National Electric Code.
  • Page 9 DANGER! Do not attempt to remove the hold down before inserting and bottoming out the hold down compression bolts (71). The compression bolts were shipped with the machine. When receiving the shear the bolts are located inside of the electrical box. Please remove them and store them in a location to be accessible.

  • Page 10: Electrical Specifications

    The unit is shipped with a lifting bolt attached on the top of the cutter head. The shear should be lifted and positioned by using a sling or chain passed through the lifting bolt. CAUTION! The LM1010 shear weighs approximately 10,000 lbs. net. Be sure to verify the maximum load permissible for a given chain or sling.
  • Page 11 LM Operator’s Control Panel MODE OF OPERATION SWITCH: 1. CONTINUOUS 2. SINGLE or 3. JOG PULL: TURN ON MACHINE (ILLUMINATED RED WHEN ON) PUSH: TURN OFF MACHINE PUSH: EMERGENCY STOP 3-PHASE ELECTRICAL POWER DISCONNECT SWITCH...
  • Page 12 Please note if your switch does not illuminate in the out position, you must immediately replace the bulb located within the switch. It is unsafe to operate this shear without the illuminated switch. Please contact Tennsmith if you need assistance replacing the bulb. 2. To the right of the Push/Pull Switch is the Jog/Run Switch: This selector type switch is designated 2 on the previous page.
  • Page 13 4. Stroke Selector Switch: This switch is located towards the bottom of the panel and is designated 5 on the previous page. The switch has two options: Cont – This is for continuous operation of the cutter head of the shear. To engage the continuous mode, select run on switch 2 (Jog/Run Switch) and select Cont.

  • Page 14: Blade Clearance

    BLADE CLEARANCE The blade clearance on the LM1010 was set at the factory to .004 in. on the ends of the blades with a .003 gap in the center of the machine. At this setting, your shear should provide satisfactory results over a broad range of materials and thickness.
  • Page 15 REPLACING/ROTATING BLADES The blades on the LM Series shears are four edged blades constructed of high carbon, high chromium tool steel. Top and bottom blades are interchangeable. Upon utilizing all four edges of you blades, you may return the blades to the factory for re-sharpening or to a qualified blade re-sharpener, such as a blade manufacturer.
  • Page 16 Reposition the hold down assembly. BACKGAUGE INFORMATION The LM1010 shear is fitted with a front operated powered back gauge as standard equipment. The gauge was installed and calibrated at the factory and shipped intact mounted on the shear. Inspect the gauge carefully to determine any possible movement or damage in transit.
  • Page 17 USING THE DRO BACKGAUGE To operate the backgauge: 1. Press and hold the “IN” button located on the control box to move backgauge in. 2. Press and hold the “OUT” button located on the control box to move backgauge out. NOTE: FORWARD AND REVERSE OVER-TRAVEL SWITCHES ARE INSTALLED TO PREVENT BACKGAUGE CRASHES.

  • Page 18: Hold Down Adjustment

    Hold Down Adjustment The following is the instructions to raise the hold down height to reduce the pressure (Hold down) on your LM shear: Using the jog mode, depress the jog button until the machine cutter head reaches the bottom or its lowest position.
  • Page 19 SHEET SUPPORT SYSTEM a. Single Stroke: When the foot pedal is activated, the sheet support will drop down and remain down until the cycle is complete and then return to the up position. b. Continuous Stroke: When the foot pedal is activated, the sheet support will drop down and stay down as long as the foot pedal is activated.

  • Page 20: Maintenance

    MAINTENANCE On a monthly basis, remove the top cover (11) of each side panel and grease the gib plates (9, 10, 15). This can be best accomplished by jogging the cutter head down to the extreme down-stroke position, thus exposing a majority of the gib surface. WARNING! MAKE SURE THE POWER TO THE MACHINE HAS BEEN TURN OFF WHEN APPLING LUBRICATES.
  • Page 22 LM Machine PARTS View...
  • Page 23 MODEL LM1010 PARTS LIST ITEM# LM PART# DESCRIPTION QTY. 1010001 CUTTER HEAD 101002L GIBB PLATE LEFT 101002R GIBB PLATE RIGHT 1010003 BLADE TOP & BOTTOM 1010004 SET SCREW, ROD MOUNTING 1010005 BOLT, BLADE MOUNTING 1010006 LOCK WASHER, BLADE 1010007 DOWEL PIN, GIBB PLATE...
  • Page 24 MODEL LM1010 PARTS LIST Continued ITEM# LM PART# DESCRIPTION QTY. 1010041 ELECTRIC CONTROL BOX 1010042 SWITCH, FORWARD REVERSE 1010043 BOLT, TABLE MUNTING, TOP 1010044 BOLT, MATERIAL GUIDE BAR MOUNTING 1010045 MATERIAL GUIDE BAR 1010046 SCREW, SCALE MOUNTING, TABLE 1010047 SCALE, TOP...
  • Page 25 Power Back gauge Parts View...
  • Page 26 Power Back gauge Bill of Material Part No. Description No. Req’d LM1012-PBG-612 ADJUSTING TUBE LM1012-PBG-ARM-AS ARM ASSEMBLY LM1010-FTBG-ANGLE BACK STOP ASSEMBLY LM1012-PBG-625 BALL BEARINGS – BALL SCREW LM1012-PBG-634 BALL NUT – BALL SCREW LM1012-PBG-659 BALL SCREW – LH LM1012-PBG-660 BALL SCREW – RH LM1012-FTBG-372 BEARINGS –...
  • Page 27 LM Four Foot Squaring Arm...
  • Page 28 LM Four Foot Squaring Arm Parts List ITEM# LM PART# DESCRIPTION QTY. 40005 BOLT, TABLE, SQUARING ARM MOUNTING 40006 LOCK WASHER, BOLT, TABLE SQ ARM MOUNTING 2 40046 SET SCREW, SCALE 40181 NUT, LOCK HANDLE, BLOCK SQ ARM 40185 RATCHET STUD, LOCK HANDLE, BLOCK SQ ARM 40186 HANDLE, LOCK HANDLE, BLOCK SQ ARM 40187...
  • Page 29 LM Rear Sheet Support System LM Rear Sheet Support System Parts List ITEM# LM PART# DESCRIPTION QTY. RS5197 SCREW, BRACKET MOUNTING RS5198 LOCK WASHER, BRACKET MOUNTING RS5199 WASHER, RACK MOUNTING RS5200 TEFLON WASHER, RACK MOUNTING RS5201 STRIPPER BOLT, RACK MOUNTING RS5202 BRACKET, AIR CYLINDER MOUNTING RS5203...
  • Page 30 LM1010 3 Phase - Rear Sheet Support High Voltage Mains, AC Circuit Cutter Head Main Forward Disconnect Overload Reverse 12.5hp 208 V 3 PH 45 AMP 230 V 3 PH 42 AMP 460 V 3 PH 21 AMP Transformer 0.75 kva...
  • Page 32 OPERATING INSTRUCTIONS Gearmotors and Gear Reducers 01 805 52 US GENERAL SHAFT MOUNTED REDUCERS These operationg instructions are intended to help you install and SEW-Eurodrive supplies the recommended hollowshaft mount- operate the drive. For trouble free service, proper installation and ing paste with every hollowshaft reducer.
  • Page 33 LUBRICANTS LUBRICATION SCHEDULE FOR SEW-EURODRIVE GEAR UNITS Gear Ambient air Reducer Lubrication temperature Viscosity Mobil CHEVRON Shell Texaco Kluber Type Type range °F Grade Oil Co. Oil Co. Oil Co. Oil Co. Oil Co. Oil Co. Chevron Non-Leaded Mobilgear Shell Omala BP Energol Kluberoil VG220...
  • Page 34 LUBRICANTS The approximate lubricant in US gallons and liters per mounting position is as follows: Mounting Position Gear Unit Gallons Liters Gallons Liters Gallons Liters Gallons Liters Gallons Liters Gallons Liters RX57 0.16 0.21 0.34 0.34 0.24 0.24 RX67 0.21 0.21 0.45 0.50...
  • Page 35 LUBRICANTS The approximate lubricant in US gallons and liters per mounting position is as follows: Mounting Position Gear Unit Gallons Liters Gallons Liters Gallons Liters Gallons Liters Gallons Liters Gallons Liters 0.16 0.21 0.18 0.18 0.16 0.16 0.26 0.32 0.18 0.32 0.26 0.29...
  • Page 36 LUBRICANTS The approximate lubricant in US gallons and liters per mounting position is as follows: Mounting Position Gear Unit Gallons Liters Gallons Liters Gallons Liters Gallons Liters Gallons Liters Gallons Liters 0.13 0.26 0.26 0.34 0.26 0.26 0.21 0.34 0.40 0.53 0.42 0.42...
  • Page 37 LUBRICANTS The approximate lubricant in US gallons and liters per mounting position is as follows: Mounting Position Gear Unit Gallons Liters Gallons Liters Gallons Liters Gallons Liters Gallons Liters Gallons Liters 0.07 0.25 0.11 0.13 0.16 0.11 0.11 0.18 0.09 0.35 0.21 0.29...
  • Page 38 Motors and Brakemotors OPERATING INSTRUCTIONS 09 793 67 US Type BM (G) Brakes ≥ 230000 ohms = value of at least 1000 x V (e.g. at V = 230VAC: R insul 0.23M ohms). If the measured value is smaller, the motor should be dried Every SEW-Eurodrive motor is thoroughly tested, checked, and properly before use (for example, with hot air up to a maximum of 90°C or by re- packed prior to shipment.
  • Page 39 Brake Coil Resistance Motor Frame DT71-80 DT80 DT90-100 DT100 DV112-132S DV132M-160M DV160L-225 Brake Size BM(G)05 BM(G)1 BM(G)2 BM(G)4 BM(G)8 BM15 BM30/31/32/62 Brake Torque (lb-ft) 0.89 - 3.7 4.4 - 7.4 3.7 - 14.8 17.7 - 29.5 7.00 - 55.3 18.4 - 110.6 36.9 - 442.5 (Ω) BRAKE VOLTAGE...
  • Page 40 There are specific instances when the brake voltage can be tapped from the motor's terminal block. The advantage of brake systems wired in this way is when power is applied to the motor, the brake releases, (requiring no additional brake supply power wiring). The brake can be wired to the motor terminal block under the following conditions: a single speed motor;...
  • Page 41 At the motor, measure the line voltage, line current and motor resis- A properly adjusted brake air gap is critical for correct operation. The fol- tance of all three phases. lowing table indicates the required air gap measurement. If all three phases read a similar current value the following condi- tions may exist: Motor Size Brake Size...
  • Page 42 BM(G) Brake Cross Section and Exploded Views (1) Brake end shield (16) Dowel pin (2) Rubber sealing collar (17) Fan (3) Braking springs (18) N/A (4) Hand release lever (19) Brake adjustment nut (5) Releasing screw (20) Retaining stud (6) Closing plate (21) Brake coil body (7) Release arm (22) Stationary disc...

  • Page 43: Troubleshooting Chart

    Troubleshooting Chart PROBLEM CAUSE REMEDY Motor not connected for proper supply Check connection diagram on conduit box voltage cover and correct the wiring. Supply voltage varies outside the allow- able tolerance causing an undervoltage or Assure correct supply voltage. overvoltage condition. Insufficient cooling air volume due to: Increase air flow: a.
