- Page 1 INSTRUCTIONS FOR ASSEMBLY AND USE OF THE MOBILUS PR TUBULAR MOTOR MOBILUS MOTOR Spółka z o.o. ul. Miętowa 37, 61-680 Poznań, PL tel. +48 61 825 81 11, fax +48 61 825 80 52 VAT NO. PL9721078008 www.mobilus.pl...
- Page 2 L2 - phase 2 - black. INSTALLATION OF THE Tubular motor The version of the MOBILUS PR M35 tubular motor is available only in the variant with the MOBILUS head. The MOBILUS PR M45 tubular motor is available in two variants: a) equipped with a MOBILUS head - standard M35 and M45 series holders are used for as- sembly.
- Page 3 POWER SUPPLY SCHEME 230V~ 50Hz Fig. 1 a) TUBULAR MOTOR PHASE L1 / DIRECTION 1 b) CONNECTION BOXING BOX PHASE L2 / DIRECTION 2 c) MONOSTABLE SWITCH [UNSTANDING]. N - NEUTRAL PROTECTIVE Fig. 2 CHANGING THE DIRECTION OF THE Tubular motor BY CHANGING THE WIRES If we press the UP direction button on the switch and the armour goes DOWN, change the direction of rotation of the drive.
- Page 4 NOTES...
