Summary of Contents for AV Access eShare W80
- Page 1 Hybrid Conference System with BYOD eShare W80 User Manual...
-
Page 2: Table Of Contents
Table of Contents Introduction ......................2 Overview ..........................2 Features ............................ 2 Package Contents ........................2 Panel ............................3 Application ......................4 Key Functions ....................... 6 Screen Mirroring ........................6 Screen Mirroring over Airplay (for Apple Devices) ..........6 Screen Mirroring over Miracast (for Android Phones & Windows PCs) ..7 Screen Mirroring over Dongle .................. -
Page 3: Introduction
Introduction Introduction Overview The eShare W80 is a high-performance BYOD presentation switcher with wireless presentation capability. It equips two built-in Wi-Fi modules and offers multiple access approaches, including Airplay Mirroring, Miracast, Dongle and physical HDMI ports, with which you can project the screen contents of your computers (Mac/Windows) or mobile devices (iPhone/iPad/ Android phone) to a display. -
Page 4: Panel
Introduction Panel Front Panel Name Description The device’s working status LED indicator. • Blinking quickly: The device is booting. / The device is being upgraded. • Lighting constantly: The device has started. / The Status LED device is working properly. •... -
Page 5: Application
Application Name Description USB peripheral device. Connect to a U-disk for firmware upgrade. More information, see Firmware Upgrade section. HDMI Out 1-2 Connect to HDMI displays. Connect to an audio receiver for unbalanced analog audio output. Audio Out Important: This port automatically outputs the audio from the latest connected source. - Page 6 Application Features: • Plug a dongle into the laptop after the dongle is paired with the device successfully, the laptop can connect to the device wirelessly via the dongle as well as access the camera and speakerphone at the device. •...
-
Page 7: Key Functions
Wi-Fi SSID: as same as the device name and can be obtained from OSD at the upper right of the display screen. By default, it is set as eShare W80. Password: can be set through Web UI and can be obtained from OSD at the upper right corner of the display screen. -
Page 8: Screen Mirroring Over Miracast (For Android Phones & Windows Pcs)
Key Functions Screen Mirroring over Miracast (for Android Phones & Windows PCs) For Android smartphone (take Samsung Galaxy series for example): 1. Enable the Wi-Fi or WLAN feature of your smartphone. Smart View 2. On your phone, swipe down from the top and tap Wireless to select appropriate mirroring device (the device name Projection... -
Page 9: Screen Mirroring Over Dongle
Key Functions mirroring with Miracast due to compatibility issues. Tip: Both the Airplay mirroring and Miracast support access code. If you see the PIN entry window appears on your devices, input the access code that can be obtained through OSD (see section for more information). -
Page 10: Dual View Display
Key Functions Dual View Display When only one HDMI output port (either HDMI OUT1 or HDMI OUT2) is attached to an HDMI display, the device supports Dual View Display, that is, up to two video sources can be displayed on one single screen. If two video sources are being played in Dual View Display mode on the display screen of HDMI OUT1/HDMI OUT2, connect an additional video source to the device, this latest input source will replace the... -
Page 11: Display Of Hdmi Out1 And Hdmi Out2 Outputs
Key Functions Display of HDMI OUT1 and HDMI OUT2 Outputs When both HDMI OUT1 and HDMI OUT2 are connected to display screens respectively, dual view display function is disabled and the two HDMI outputs function as follows: (1) Each of the HDMI outputs display in single view on its corresponding display screen. -
Page 12: Guide Screen
The device outputs Guide Screen image when no active video source is detected. The Guide Screen can be personalized to convey customized connection instructions through the device’s Web UI page. Device/SSID: eShare W80 No Access Code IP: 172.16.18.20 SSID PWD: 12345678... -
Page 13: Osd
Key Functions The device supports OSD (on screen display) to convey device basic information, including video source’s information, Access code, device name and IP address, etc. Here are two different OSD examples in different scenarios. Example 1-- Displays in single view: Figure 2 –... -
Page 14: Web Ui
Web UI Example 2 – Displays in dual view Figure 3 -- OSD Example 2 Web UI The Web UI designed for this device allows for basic controls and advanced settings. It can be accessed through a modern browser, e.g. Chrome, Safari, Firefox, IE10+, etc. - Page 15 Web UI Input the password (default password: admin) and click Login. Set up a new login password in the following dialog box and click Save and Continue to enter the main page. The password shall be alphanumeric only with 4 to 16 characters in length. The main page includes seven submenus: Wireless Setting, Output Setting, Network Setting, Web UI Logon Password, Guide Screen Change, Firmware Upgrade and Version Information.
-
Page 16: Wireless Setting
Airplay and Miracast. Note: The name must be 1~20 characters in length, including letters, numbers, space, “_” or “-”, space shall not at the beginning or end. By default, it’s set as eShare W80. WiFi Configure the WiFi password. Password The password must be 8~20 characters in length, including letters, numbers, “_”... -
Page 17: Output Setting
Web UI UI Element Description PIN shown on Enter a four-digit PIN code (0000~9999) to help the screen prevent users from accidentally connecting to an unintended device protect from unauthorized access. • When the PIN code is set, it will appear on the upper right corner of the display. - Page 18 Web UI UI Element Description HDMI out1 Set the output resolution of HDMI out1. Two resolution operation methods are offered in the following: Auto: select to output the maximum resolution supported by the display based on the display’s EDID. e.g. If display supports up to 4K@30Hz, the device will output 4K@30Hz video.
-
Page 19: Dongle Cast Setting
Web UI UI Element Description Note: If the connected display doesn’t support CEC, the word “Standby” appears in the middle of the Guide Screen. • If it’s set to 0 minute, it means this function is disabled, you cannot set the display to standby mode. -
Page 20: Network Setting
Web UI Network Setting UI Element Description IP Mode Select an IP mode from DHCP and Static. By default, it’s set as DHCP. IP Address Set IP address manually for the device when Static mode is selected. Netmask Set subnet mask manually for the device when Static mode is selected. -
Page 21: Web Ui Logon Password
Web UI Web UI Logon Password UI Element Description Old Password Input the previous login password. Input a new password for the device to login web UI page. Password Note: The password must be 4 to 16 characters in Confirm new length, alphanumeric only. -
Page 22: Firmware Upgrade
Web UI Firmware Upgrade UI Element Description Browse Click to browse for the local upgrade file. Apply Click to upload the firmware file to the device and perform firmware upgrade. Reboot Click to reboot the device. Reset to Click to restore the device to its factory defaults. Factory You can also perform this task by using the Reset Default... -
Page 23: Firmware Upgrade
Firmware Upgrade Firmware Upgrade The device supports firmware upgrade through either Web UI or USB-A ports on rear panel. To upgrade firmware through Web UI, see Firmware Upgrade section. To upgrade firmware through USB-A port on rear panel, perform the following: Name the upgrade file package “FSC630-update.zip”. -
Page 24: Specifications
Specifications Specifications Technical 2 x HDMI In; 1 x LAN, 10/100/1000Mbps Ethernet; Input Video Port 1 x WLAN • HDMI: HDMI 1.4, HDCP 1.4 Input Video Signal • LAN/WLAN: H.264 HDMI: 640x480 , 800x600 , 1024x768 , 1280x768 , 1280x800 1280x1024 , 1360x768 , 1366x768... - Page 25 Specifications Technical 1920x1080 (1080p24), 1920x1080 (1080p25), 1920x1080 (1080p30), 1920x1080 (1080p50), 1920x1080 (1080p60) 1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at 30 Hz, 6 = at 50 Hz, 7 = at 59.94 Hz, 8 = 60 Hz Audio Input Audio Port 2 x HDMI;...
-
Page 26: Warranty
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide.
