- Page 1 W50 Hybrid Conference System with Wireless BYOD User Manual...
- Page 2 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. AV Access Technology Limited assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use.
- Page 3 Important Safety Instructions Do not expose this device to rain, moisture, dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the device. Do not install or place this unit in a bookcase, built-in cabinet, ...
-
Page 4: Table Of Contents
Table of Contents Introduction ......................4 Overview ..........................4 Features ............................ 4 Package Contents ........................5 Panel ............................5 Front Panel ........................5 Rear Panel ........................6 Installation ......................7 Application ......................8 Key Functions ....................... 9 Screen Mirroring ........................9 Screen Mirroring over Airplay (for Apple Devices) .......... -
Page 5: Introduction
Introduction Introduction Overview The eShare W50 is a high-performance BYOD presentation switcher with wireless presentation capability. It equips built-in Wi-Fi module and offers multiple access approaches, including Airplay Mirroring, Miracast, Dongle and physical HDMI and USB-C ports, with which you can project the screen contents of your computers (Mac/Windows) or mobile devices (iPhone/iPad/Android phone) to a display. -
Page 6: Package Contents
Introduction Package Contents Before you start the installation of the product, please check the package contents: eShare W50 x 1 DC 12V Power Adapter (with US, UK and EU Pins) x 1 Wi-Fi Antenna x 1 USB Type-C to USB Type-C Cable with Lock (L=2m) x 1 ... -
Page 7: Rear Panel
Introduction Name Description Reset button. When the device is powered on, use a pointed Reset stylus to hold down this button for five or more seconds and then release, the device will reboot and restore to its factory defaults. Rear Panel Name Description Connect to the DC 12V power adapter provided. -
Page 8: Installation
Installation Installation Note: Before installation, ensure the device is disconnected from the power source. Attaching the Antenna Attach an antenna provided to the threaded connector, and screw it down in clockwise. Attaching Brackets Attach the bracket to the bottom panel using screws provided in the package. -
Page 9: Application
Touch Sreen Mobile Tablet Note: If the USB-C video source (e.g. a laptop) is being displayed, all USB devices connected to USB 3.0 Type A ports of eShare W50 will be routed to the USB-C video source as well. www.avaccess.com info@avaccess.com... -
Page 10: Key Functions
Wi-Fi SSID: as same as the device name and can be obtained from OSD at the upper right of the display screen. By default, it is set as eShare W50. Password: set through Web UI and can be obtained from OSD at the upper right corner of the display screen. -
Page 11: Screen Mirroring Over Miracast (For Android Phones & Windows Pcs)
Key Functions obtained from the upper right corner of the display screen) from the pop-up menu. c. To disconnect Apple device from the device: click Stop Mirroring, the display stops displaying your device’s screen. Screen Mirroring over Miracast (for Android Phones &... -
Page 12: Screen Mirroring Over Dongle
Key Functions appropriate mirroring device (the device name can be obtained from the upper right corner of the display screen) from the pop-up menu. 3. To disconnect PC from the device: click Disconnect, the display stops displaying PC’s screen. Note: The icon and interface of the Miracast function may vary on ... -
Page 13: Automatic Signal Switching
Key Functions “Pairing successful” appears on the display screen. 2. Connect Dongle to a laptop. Insert eShare D10 into the laptop’s USB-C port, it will start running and connecting to the device’s Wi-Fi. After it is connected to the device successfully, the Dongle LED stops blinking and starts lighting constantly. -
Page 14: Guide Screen
Key Functions Guide Screen The device outputs Guide Screen picture when no video source is selected or being output. The Guide Screen can be personalized to allow customized connection instructions on the device’s Web UI page. Figure 1 – Guide Screen Image The Guide Screen image will appear automatically on the display screen after all video sources are removed from the device. -
Page 15: Osd
Key Functions The device supports OSD (on screen display) to convey device basic information, including video source’s information, PIN code, device name and IP address, etc. See Figure 2 below: Figure 1 – OSD Example www.avaccess.com info@avaccess.com... -
Page 16: Specifications
Specifications Specifications Technical 1 x USB-C In; 1 x HDMI In; 1 x LAN, 10/100/1000Mbps Input Video Port Ethernet; 1 x WLAN • HDMI: HDMI 1.4, HDCP 1.4 • Input Video Signal USB-C: DisplayPort 1.1, HDCP 1.4 • LAN/WLAN: H.264 HDMI: 640x480 , 800x600... - Page 17 Specifications Audio Input Audio Port 1 x HDMI; 1 x USB-C In; 1 x LAN; 1 x WLAN Input Audio Signal RAW PCM 2.0, 16 bit, 32/44.1/48KHz sps Output Audio Port 1 x HDMI Output Audio Signal RAW PCM 2.0, 16 bit, 48KHz sps Wi-Fi Standard IEEE 802.11 a/b/g/n/ac...
-
Page 18: Web Ui
Web UI Web UI The Web UI designed for this device allows for basic controls and advanced settings. It can be accessed through a modern browser, e.g. Chrome, Safari, Firefox, IE10+, etc. To get access the Web UI: Connect the LAN port of the device to a local area network. Ensure there’s a DHCP server in the network so that the device can obtain a valid IP address. -
Page 19: Wireless Setting
Web UI The main page includes seven submenus: Wireless Setting, Output Setting, Network Setting, Web UI Logon Password, Guide Screen Change, Firmware Upgrade and Version Information. Wireless Setting UI Element Description Device Name Input a name for the device. This name also acts as the WiFi name and the receiver of Airplay and Miracast. - Page 20 Note: The name must be 1~20 characters in length, including letters, numbers, “_” or “-” and, space shall not at the beginning or end. By default, it’s set as eShare W50. WiFi Configure the WiFi password. The name must be 1~20 characters in length, Password including letters, numbers, “_”...
-
Page 21: Output Setting
Web UI Output Setting UI Element Description Output timing Set the output timing for the input ports. Two operation methods are offered in the following: Auto: select to output the maximum resolution supported by the display based on the display’s EDID. E.g. If display supports up to 4K@30Hz, the device will output 4K@30Hz video. -
Page 22: Network Setting
Web UI UI Element Description Auto Standby Set a period of time that remains before the countdown timer begins for auto standby. • For example, when the current output is Guide Screen, 1 minute means if there’s no signal present at the display in 1 minute, the countdown timer for display standby begins;... -
Page 23: Web Ui Logon Password
Web UI UI Element Description IP Mode Select an IP mode from DHCP and Static. By default, it’s set as DHCP. IP Address Set IP address manually for the device when Static mode is selected. Netmask Set subnet mask manually for the device when Static mode is selected. -
Page 24: Guide Screen Change
Web UI UI Element Description password Apply Click to perform current settings. Guide Screen Change • Browse: click to change to a new picture for the guide screen. Note: Picture in jp(e)g format with 1920x1080 pixels is recommended. • Apply: click to upload the selected picture to the device. Firmware Upgrade UI Element Description... -
Page 25: Version Information
Web UI UI Element Description Default button on front panel. Export Log Click to export system log. Version Information UI Element Description Version Displays the device’s firmware information. Information Version Shows the device’s firmware version. Build Time Shows the time and date when the device’s firmware was built. -
Page 26: Firmware Upgrade
Firmware Upgrade Firmware Upgrade The device supports firmware upgrade through either Web UI or USB-A ports on rear panel. To upgrade firmware through Web UI, see Firmware Upgrade section. To upgrade firmware through USB-A port on rear panel, perform the following: Name the upgrade file package “FSC610-update.zip”. -
Page 27: Warranty
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide. - Page 28 AV Access Technology Limited V1.0.1...
