- Page 1 Eaton 5E Advanced User Guide 5E700UD-KR 5E1200UI-KR 5E1600UI-KR 5E2200UI-KR Copyright © 2023 EATON All rights reserved. DSD-5E2209 English...
-
Page 3: Table Of Contents
Contents 1 Special symbols ....................1 2 Introduction ..................... 2 2.1 Environmental protection ................2 2.2 Benefits ...................... 3 3 Presentation ..................... 4 3.1 Standard installation .................. 4 3.2 Front panel ....................5 3.3 Rear panel ....................5 4 Installation ......................6 4.1 Inspecting the equipment ................ -
Page 5: Special Symbols
1 Special symbols The following are examples of symbols used on the UPS or accessories to alert you to important information: DANGER: Dangerous voltage levels are present within the UPS. The UPS has its own internal power source (the battery). Consequently, the pow- er outlets may be energized even if the UPS is disconnected from the AC power source. -
Page 6: Introduction
Follow the instructions in the quick start guide and if necessary, refer to this advance user guide. To discover the entire range of Eaton products, we invite you to visit our web site at eaton.com or contact your Eaton local representative. -
Page 7: Benefits
Follow all local regulations for the disposal of packing materials. 2.1.3 End of life Eaton will process products at the end of their service life in compliance with local regulations. Eaton works with companies in charge of collecting and eliminating our products at the end of their service life. -
Page 8: Presentation
3.1 Standard installation 3.1.1 Weights and dimensions Description (UPS) Weights (kg / lbs) Dimentions (mm / inch) D x W x H 5E700UD-KR 4.3 / 9.5 288 x 100 x 148 / 11.5 x 3.9 x 5.8 5E1200UI-KR 8.2 / 18.2 330 x 133 x 180 / 13.0 x 5.2 x 7.1... -
Page 9: Front Panel
3.2 Front panel 1. USB communication port 2. ON/OFF Button 3. UPS status LED 3.3 Rear panel 5E1200UI-KR 5E1600UI-KR/5E2200UI-KR AC Input AC Output... -
Page 10: Installation
4 Installation 4.1 Inspecting the equipment If any equipment has been damaged during shipment, keep the shipping cartons and packing materials for the carrier or place of purchase and file a claim for ship- ping damage. If you discover damage after acceptance, file a claim for concealed damage. -
Page 11: Recommended Positions
4.2 Recommended positions Place the Eaton 5E on a flat, stable surface in its final location. Always keep 6” or 150 mm of free space near UPS openings for ventilation. Installation in tower position 4.3 UPS connection 4.3.1 Power supply connection... - Page 12 4.3.2 Protected outlets / Backup & Protected outlets Plug critical equipment (computer, monitor, modem, etc.) to the backup & pro- tected outlets providing battery backup power, taking care not to exceed the rated current indicated in amperes.
-
Page 13: Usb Com Port
Equipment connected to these outlets is supplied as soon as the AC cord is plugged in. These are not affected by ON/OFF button. 4.4 USB COM port Connect the UPS to the computer using the USB cable. Enhance your purchase by downloading the monitoring software “Eaton UPS Com- panion” using URL : eaton.com/downloads... -
Page 14: Operation
5 Operation 5.1 Start-up and normal operation Check that the indications on the name plate located on the back of the UPS meets to the AC power source and the true electrical consumption of the total load. 5.1.1 Battery charge The UPS charges the battery as soon as it is connected to the AC outlet, whether the ON/OFF button is pressed or not. -
Page 15: Starting The Ups On Battery
4. Verify that the indicator illuminates in green, indicating that the UPS is op- erating normally and any loads are powered and protected. The UPS should be in Normal mode. 5. The UPS will make a first battery test, the will blink for few seconds, this behavior is normal >... -
Page 16: Operating Modes
5.4 Operating modes The Eaton 5E front panel indicates the UPS status through the UPS LED indicator. 5.4.1 Normal mode When the symbol is illuminated in green, the UPS is providing protected AC power output. The UPS charges the batteries and provides power protection to your equipment. -
Page 17: Ups Maintenance
If you store the equipment for a long period, recharge the battery every 6 months by connecting the UPS to utility power. The internal batteries charge to 90% capac- ity in less than 3 hours. However, Eaton recommends that the batteries charge for 48 hours after long-term storage. - Page 18 the UPS batteries in the trash. This product contains sealed, lead acid batteries and must be disposed of properly. For more information, con tact your local recycling/reuse or hazardous waste center. Do not discard waste electrical or electronic equipment (WEEE) in the trash.
-
Page 19: Troubleshooting
7 Troubleshooting The Eaton 5E is designed for reliable, autonomous operation while providing you with notifications and alerts whenever a potential operational or performance issue occurs. Usually the alarms shown by the control panel do not mean that the output power is affected. -
Page 20: Service And Support
7.1 Service and support If you have any question or problem with the UPS, call Eaton or your local ser- vice representative in your country / region. Please have the following information ready when you call for service: •... -
Page 21: Specification And Technical Characteristics
8 Specification and technical characteristics 8.1 Electrical input Catalog Number Nominal Current Nominal Voltages Voltage Windows 5E700UD-KR 3.8A 5E1200UI-KR 6.0A 220-240V; 50/60Hz 140-300V; 46-65Hz 5E1600UI-KR 8.6A 5E2200UI-KR 8.2 Electrical output All models Normal mode Battery mode Boost1 : Vin*1.2 Voltage regulation Boost2 : Vin*1.4... -
Page 22: Battery
Short Time withstand 50ms current Transfer time 10ms for on-line to battery mode 8.3 Battery Internal batteries 700VA: 12Vdc – 1 x 12V, 7Ah 1200VA: 24Vdc – 2 x 12V, 7Ah Specifications 1600VA: 24Vdc – 2 x 12V, 7Ah 2200VA: 24Vdc – 2 x 12V, 9Ah Brand &... - Page 23 Storage 0 to 40 °C (32 to 104 °F) with battery temperature -25 to 55 °C (-13 to 131 °F) without battery Relative Storage: 0-93 % non-condensing Operation: 0-85 % non-condensing humidity Operating 2000 m altitude Transit altitude Up to 10,000 meters (32,808 ft) above sea level 700VA/1200VA: <25dBA Audible noise 1600VA/2200VA: <25dBA (Line Mode), <40dBA (Battery or AVR...
-
Page 24: Glossary
9 Glossary Time during which the load can be supplied by the UPS operat- Backup time ing on battery power. This is a battery-voltage level indicating that battery power is low Low-battery warning and that the user must take action before the UPS shuts down. Load Devices or equipment connected to the UPS output.
