PREPARATION
*
*
*
*
CARE AND MAINTENANCE
Part List and Hardware List
PIECE
DESCRIPTION
A
Left Leg Chair
B
Right Leg Chair
C
Back Chair
D
Seat Chair
E
Support Chair
CSH1
Back Cushion
CSH2
Seat Cushion
HW1
Allen Bolt: M6x0.5x60 mm
HW2
Allen Bolt: M6x0.5x25 mm
HW3
Flat Washer M6x1 mm
HW4
Split Lock Washer 6 mm
Allen Key
HW5
PICTURE QUANTITY
1X
1X
1X
1X
1X
1X
1X
2X
6X
6X
2X
1X
Model# PAT7727
Product Dimensions
25.98"W x 37.01"D x 29.13"H (Chair)
Weight Capacity : 352 lbs ( Chair)
Warning : Do not stand on Table /Chair
Warning : Do not over torque bolts/screws
1-3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Safavieh Outdoor PAT7727
Summary of Contents for Safavieh Outdoor PAT7727
- Page 1 NOTICE email Model# PAT7727 PREPARATION Product Dimensions 25.98"W x 37.01"D x 29.13"H (Chair) CARE AND MAINTENANCE Part List and Hardware List PICTURE QUANTITY PIECE DESCRIPTION Left Leg Chair Right Leg Chair Back Chair Seat Chair Support Chair CSH1 Back Cushion...
