CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use.
Remove wooden furniture from standing water. Dust regularly with small brush or vacuum
Spills should be taken care of immediately before they harden or
stain with a slightly dampened sponge.
NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* This item may require periodic tightening
Part List and Hardware List
PIECE
DESCRIPTION
Chair/Right Frame
1
Chair/Left Frame
2
Chair/Back Frame
3
Chair Seat
4
Chair Front Panel
5
Long Table Top Frame
6
Short Table Top Frame
7
Middle Table Top Frame
8
Table Leg
9
Table Wood
10
Seat Cushion
11
Allen Bolt(M6x20 mm)
A
Allen Bolt(M6x30 mm)
B
C
Allen Bolt(M6x40 mm)
D
Flat Washer
E
Allen Key
QUANTITY
6X
6X
6X
6X
6X
2X
2X
1X
4X
2X
6X
20X
36X
30X
86X
3X
Weight Capacity : 275 Ibs (single seat)
Warning : Do not stand on bench
Warning : Do not over torque bolts/screws
Model# PAT7717-1/3
Product Dimensions:
59.06"x35.43"x29.13"H (Table)
22.83"x22.44"x34.65"H (Chair)
550 Ibs (two person seat)
1-4
