Twist Pair Passive User Manual Model : TTP111HDLF HD-TVI/AHD/HDCVI/CVBS Video Balun with Pigtail (F Connector) Smart Cabling & Transmission Corp. V1.0...
Page 2
User Manual TTP111HDLF Introduction TTP111HDLF is a video balun that can use a single cost-effective twisted pair cable to extend HD-TVI/ AHD/ HDCVI/ CVBS signal and power, with the transmission distance up to 400M and the resolution up to 4K (8MP).
Page 3
User Manual TTP111HDLF Specification ITEM NO. TTP111HDLF Support Video Format HD-TVI, AHD, HDCVI, CVBS Max. Video Resolution 8MP (4K) Transmission Distance 400M (Max) over UTP (Unshielded Twisted Pair) CAT5e/CAT6 Bandwidth 50Hz-60MHz (-3dB) Ports & Interfaces Video Input 1 x BNC Female (1V p-p, 75Ω)
