Twist pair passive hd-tvi/ahd/hdcvi/cvbs video balun with pigtail (f connector) (3 pages)
Summary of Contents for SC&T TVB001
Page 1
Ground Loop Isolator Series User Manual Model : TVB001 Twisted Pair Video BALUN for interference rejection Smart Cabling & Transmission Corp. V1.0...
Page 2
(between two wire connection), to find out where is the source of interference, then add one more TVB001 to compensate the Impedance Matching for clear video Image. If you are not able to check where is the source of interference, then add TVB001 on all of wire connection and camera.
Page 3
User Manual TVB001 Specification ITEM NO. TGP001H Ports & Interfaces Connection 2 x UY Connector Link Cable 2 x Twisted Pair Cable Ambient Temperature Operation 0 to 70℃ Storage -20 to 45℃ Humidity Up to 95% Physical Characteristics Dimensions 35 x 25 x 20 & 2 x 180mm Cable...
