- Page 1 Ground Loop Isolator Series User Manual Model : GL001HP HD-TVI/AHD/HDCVI/CVBS Power Isolator DC12V 600mA Smart Cabling & Transmission Corp. V1.0...
- Page 2 GL001HP Introduction GL001HP is a power isolator designed to reduce video interference caused by power cable laid together with video/data cables. It's a perfect solution for when a video signal gets transmitted between two ends with unbalanced power line loads, which causes video interference..
- Page 3 User Manual GL001HP Specification ITEM NO. GL001HP Support Frequency 20 to10MHz (0 to 3dB) Insertion Loss 0.5dB Ground Isolation >90dB @ >50Hz Isolation Voltage DC 600V (Min) Insulation Resistance 100M Ohm Transient Voltage Suppressors 12 Vrms Ports & Interfaces Signal Input...
