OBU 228
NL ES PL CZ SK HU GB
Last
First
Accessories:
•
Grid
•
Baking tray
•
Drip tray
•
Catalytic panels
1. End of cooking timer
2. Thermostat control knob
3. Thermostat indicator light
4. Oven functions selector knob
5019 100 55052
PRODUCT DESCRIPTION SHEET
OVEN
CONTROL PANEL
First...Last: Runner positions
1. Control panel
2. Cooling fan (not visible)
3. Upper heating element
4. Grill element (can be lowered)
5. Oven light
6. Fan
7. Lower heating element (not visible)
8. Door hinge
9. Oven cool door
Advertisement
Related Manuals for Whirlpool OBU 228
Summary of Contents for Whirlpool OBU 228
- Page 1 PRODUCT DESCRIPTION SHEET OBU 228 NL ES PL CZ SK HU GB OVEN First...Last: Runner positions 1. Control panel 2. Cooling fan (not visible) 3. Upper heating element Last 4. Grill element (can be lowered) 5. Oven light 6. Fan 7.
- Page 2 OVEN FUNCTIONS The oven door must be closed during the cooking cycle. Oven light Preheat the grill for about 5 minutes. Arrange the meat on the grid with the drip tray underneath. Pour water in the drip tray to cover STATIC FUNCTION the bottom to reduce smoke and fat spatters.
