MOD-6202
HARDWARE HEADBOARD
1 JCBC BOLT M6 x 35mm
2 M6 SPRING WASHER
3 M6 FLAT WASHER
4 M4 ALLEN KEY
STEP 1
1.1 Align pre-drilled support stand holes over the pre-drilled headboard holes according to your
desired headboard height.
1.2 Secure each HB support stand by using 2x JCBC Bolt [1] and 2x M6 Spring Washer [2] and 2x M6 Flat Washer [3].
Tighten with supplied Allen Key [4].
Repeat the same procedure to secure the other side.
Note: Hardware may loosen over time.
Periodically check that all connections are tight.
4
1
2
