Swidget Z-WAVE Manual page 2

Command Ver Required Supported
Class Security Swidget
Class Wiring
Devices
Multilevel 4 Highest Dimmer
Switch Granted Switch only
Security
Class
Association 2 Highest All
Granted
Security
Class
Meter 6 Highest All except
Granted Auxiliary
Security Control
Class Switch and
20-40-60
Control
Switch
Configuration 4 Highest All
Granted
Security
Class
Multi-Channel 4 Highest 15A and
Granted 20A
Security Outlets
Class and USB
Insert
Multi-Channel 3 Highest 15A and
Association Granted 20A
Security Outlets
Class and all
Inserts
Association 3 Highest All
Group Granted
Information Security
Class
Transport 2 None All
Service
Version 3 Highest All
Granted
Security
Class
Manufacturer 2 Highest All
Specific Granted
Security
Class
Device Reset 1 Highest All
Locally Granted
Security
Class
Indicator 3 Highest All
Granted
Security
Class
Powerlevel 1 Highest All
Granted
Security
Class
Security 1 None All
2 ©2023 SWIDGET CORP. ALL RIGHTS RESERVED.
IMPORTANT SAFETY INSTRUCTIONS
Command Ver Required Supported
Class Security Swidget
Class Wiring
Devices
Security 2 2 None All
Supervision 1 None All
Firmware 5 Highest All
Update Granted
Security
Class
Basic Command Class Support
If the Z-Wave Insert registers as a Binary Switch
Device Type in a non-multi-channel environment,
then the Basic Command Class functions are
mapped to the Binary Switch Command Class
functions.
If the Z-Wave Insert registers as a Binary Switch
Device Type in a multi-channel environment, then
the Basic Command Class functions are mapped
to the Binary Switch Command Class functions
for Endpoint 1 (the Root node). For Endpoint 2, no
mappings exist for the Basic Command Class, so
any Basic Commands received by Endpoint 2 will
be ignored, and no report will be generated.
If the Z-Wave Insert registers as a Multilevel
Switch Device Type, then the Basic Command
Class functions are mapped to the Multilevel
Switch Command Class functions.
FCC Compliance Statement
This device complies with part 15 of the FCC
and ISED Canada license-exempt RSS standard(s).
Operation is subject to the following two
conditions:
1. this device may not cause harmful
interference, and
2. this device must accept any interference
received, including interference that may
cause undesired operation.
FCC Note
The manufacturer is not responsible for
any radio or TV interference caused by
unauthorized modifications to this equipment.
Such modifications could void the user's authority
to operate the equipment.
Note:
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Important Note:
To comply with the ISED Canada and FCC RF
exposure compliance requirements, no change
to the antenna or the device is permitted.
Any change to the antenna or the device
could result in the device exceeding the RF
exposure requirements and void user's authority
to operate the device.
Swidget FCC
Contains FCC ID: 2AR26-SWIDGETZW100
Contains IC: 24603-SWDTZW10100
Z-Wave Interoperability
This product can be operated in any Z-Wave
network with other Z-Wave certified devices
from other manufacturers. All mains operated
nodes within the network will act as repeaters
regardless of vendor to increase reliability of the
network.
Warranty
After having been installed according to your
local electrical code and by a certified electrician
when applicable, and having been used within
normal operating conditions, Swidget Corp. will
repair or replace (at Swidget's discretion) any
product that fails due to manufacturing defects
for a period of 5 years for Swidget Host Devices
and for a period of 2 years for Swidget Inserts.
Any repair or replacement of defective products
will extend the warranty by 90 days or the time
remaining on the original warranty, whichever is
longer. Post warranty repairs are not available.
Swidget shall not be held liable under
this warranty for reasonable wear and
tear, or damage(s) caused by the following:
misuse, neglect, improper installation, abnormal
operating conditions, unauthorized modifications
or attempts to repair the product.
Any claims to Swidget made under this warranty
shall not exceed the cost of the repairs or
replacement of the product.
This warranty applies only to Swidget products
purchased from an authorized distributor or
retailer, and as such, Swidget reserves the
right to request proof of purchase, and reject
claims for purchases made through unauthorized
distributors or retailers.
Please direct warranty claims to Swidget
Corp. by telephone at 1-855-202-1144,
email at support@swidget.com with subject
Warranty Claim. Each warranty return must
be accompanied by a completed Return
Merchandise Authorization (RMA) form provided
by Swidget Customer Service
Problems Or Questions:
If you have any problems with or questions about
the Swidget device or Insert, contact our tech
support team: support@swidget.com
Z-Wave Control + USB Insert Instructions
