Hamburger menu ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 19 Video input source �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 20 Other apllications ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 20 The settings menu ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 20 Settings �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������21 Network & Internet Settings ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������21 System Firmware Update ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������22 Display & Audio Settings ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������22 System Management ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������23 i3TOUCH PXr Series - Manual...
• Use a three-wire socket and ensure that it is properly grounded. • Pull out the power plug from the socket if the product is not used for a long period. i3TOUCH PXr Series - Manual...
Page 6
Do not lay the product down in a way where the venting surface will be covered. • Do not install the product on carpet or cloth. • Do not use a cloth, such as table cloth, to cover the product. i3TOUCH PXr Series - Manual...
Page 7
On the premise of ensuring the viewing quality, energy consumption can be reduced by reducing the brightness of the display. • This product can be used with all kinds of built-in computers, which can be upgraded or replaced according to your needs. i3TOUCH PXr Series - Manual...
Product Appearance � Parts Front Back Proximity Sensor Power Button Light Sensor Power Port & Switch IR Receiver Rear Port 1 Stylus Pen box Rear Port 2 Speakers Computer Port (OPS) i3TOUCH PXr Series - Manual...
USB device is connected to OPS. HDMI Out Connect electronic video device with HDMI input. LAN IN Connect to the router. LAN out Connect to the RJ45 Port RS232 Serial port signal input interface. i3TOUCH PXr Series - Manual...
Enter the Settings application Increase the brightness Decrease the brightness Press to enter the i3NOTES whiteboard application Toggle Display Backlight Mode Switch to HDMI 1/2/3 video signal source HDMI 1/2/3 Switch to USB-C video signal source USB-C i3TOUCH PXr Series - Manual...
Use the remote control within a range of about 5 meters in front of the remote control receiver of this product and about 30 degrees on both sides. about 3 meters within a 30 degrees angle about 5 meters i3TOUCH PXr Series - Manual...
Do not install or disassemble the product if the glass is broken. • For any problem, please contact our support desk. Our company is not responsible for any damage or losses incurred by users if the users fails to follow the instructions. i3TOUCH PXr Series - Manual...
Otherwise, the display or built-in computer may be damaged. The built-in computer is not configured by default. You will need to purchase the built-in computer sepa- rately. Perform the following steps to install the built-in computer. i3TOUCH PXr Series - Manual...
Page 15
If the screen fuzzes, flashes or if no signal is received from the built-in computer channel after turning on the power, it means that the built-in computer has not been properly installed. Please check it and re-in- stall. i3TOUCH PXr Series - Manual...
The power indicator should be red.inserted and that the ground wire of the outlet is properly connected. Step 3 Press the Power button on the display or the power button on the remote control to start the machine. The indicator light turns green. i3TOUCH PXr Series - Manual...
When the machine is turned on, hold the screen for more than 3 seconds with 3 fingers to turn screen off; short press the power button, or press any button on the remote control or tap the screen to turn screen on. i3TOUCH PXr Series - Manual...
The whiteboard button opens an interactive whiteboard that allows you to take notes, make drawings or facilitate workshops. The output can be shared very easily with all participants. WHITEBOARD Tap the whiteboard button. 2. Start writing in the active tab. 3. Activate the writing options by tapping the eraser. i3TOUCH PXr Series - Manual...
3. Start the Whiteboard application. Start the Present application. Work with Annotate and make annotations on everything that appears on the screen. 6. Switch between the input sources of the display. Adjust volume of the loudspeakers. i3TOUCH PXr Series - Manual...
2. Open the file explorer app 3. Open the WPS offices app Open more apps APPS � The settings menu In the bottom right corner, you can find the button to access the settings menu. SETTINGS i3TOUCH PXr Series - Manual...
Settings When opening the settings menu, you get an overview of all the settings you can adjust. � Network & Internet Settings Make a connection to your network and internet via Wi-Fi or Ethernet cable. i3TOUCH PXr Series - Manual...
The i3TOUCH PXr also features an environment light sensor to automatically adjust the brightness. Turn Automatic Brightness Control on to activate this feature. Adjust the audio settings in Device Settings and pre-define the audio environments. i3TOUCH PXr Series - Manual...
5. Enable / Disable the Motion Sensor. If the motion sensor does not detect presence/movement in the room for 15 minutes, the display will automatically shut down. Rotation Settings Disable or Enable the automatic rotation of the screen, upon rotation of the display. i3TOUCH PXr Series - Manual...
Pencil tool, change the also delete all pages drawing color Eraser, erase parts of the Save/Export canvas Marker, you can write Delete, delete content of with semi-transparent current page Pen tool, change the writing color i3TOUCH PXr Series - Manual...
Page 25
This will close the whiteboard application and deletes all pages permanently. There is no option to retrieve deleted content. You will be asked if you want to save/export your notes first, before closing. Save / export The whiteboard application supports multiple save and export options (adjustable in admin settings). i3TOUCH PXr Series - Manual...
Page 26
You can email the content of the whiteboard to yourself and/or others using one of the 3 available mail options. Use i3NOTES This option will use the i3-Technologies mail service. Enter the email address to whom you want to send the PDF to. You can enter multiple email addressess separated by a space (" "). Use Microsoft Exchange This option uses your Outlook account to send the mail.
Page 27
Required: your network firewall will need to allow peer-to-peer connections. Use cloud The cloud option will export the PDF to the i3-Technologies cloud server and make it publicly available to download for everyone that scans the QR code. After 2 hours the PDF will automatically be removed from our server.
Page 28
This allows for the quickest note-taking experience: open whiteboard, write with stylus, erase with finger. Changing the drawing tool, or its thickness or color will modify the finger-touch behavior, until the white- board is closed and reopened again. The whiteboard canvas supports multi-touch writing. i3TOUCH PXr Series - Manual...
At the bottom there will be 2 buttons, to cancel the cropping and to submit and send it to the whiteboard application. i3TOUCH PXr Series - Manual...
Page 30
Finger writing / drawing At start-up of the annotate application, touching the canvas with a finger will activate the eraser function on default. This allows for the quickest note-taking experience: write with stylus, erase with finger. i3TOUCH PXr Series - Manual...
��� and connect to the i3TOUCH EX with i3ALLSYNC transmitter software Open the transmitting client i3ALLSYNC application on your device, and follow the instruction on-screen to insert the i3TOUCH EX credentials and cast your screen content. i3TOUCH PXr Series - Manual...
Page 32
Available only in the CLOSED Meeting Mode. Press this button to display a list with previews of the connected users that are standby to share their screen content. Press the play button on the preview to display the screen content. i3TOUCH PXr Series - Manual...
Page 33
NOTE: Touch functionality only works via the i3ALLSYNC Transmitting clients on Windows and MacOS. Use the i3ALLSYNC HDMI transmitter (optional accessory) i3-Technologies also offers the i3ALLSYNC HDMI Transmitter (purchased separately) for meeting attendees (guests) that can’t or won’t install the client software. Once the i3ALLSYNC HDMI Transmitter is paired only once with the display, you only need to plug in the HDMI and USB cable and press the button to immediately share the HDMI content on-screen.
Check whether other electronic equipment or power tools are placed around the image dithering machine. No color, color is Adjust chromatic and brightness or contrast in menu. weak, or image is Check whether signal wire is well connected. weak i3TOUCH PXr Series - Manual...
NOTE The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. i3TOUCH PXr Series - Manual...
