General Safety Precautions Thanks for purchasing this product. Please read the instructions carefully before using this product. Please keep this manual for future reference. This manual is a general manual, the pictures are for reference only, please refer to the real product. �...
Page 6
Clean the power plug regularly. • Continued use of this product may cause fire or electric shock if the plug is not clean for a long time. • Pull out the power plug before cleaning it with a dried cloth Do not put items on the top of the product.
Page 7
Keep the product away from the radio. The product complies with the international EMI standard to pervent radio interference. However, interference may still exists and causes noise in the radio. If noise occurs in the radio, try the following solutions. •...
Product Appearance � Parts Parts LCD Panel Touch TP Power Button IR Receiver Light Sensor Proximity Sensor Power Port & Switch Stylus Pen box Speakers Rear Port 1 Rear Port 2 Computer Port (OPS) i3TOUCH PX Series - Manual...
� Rear Ports Warning! The voltage/current of the rear power output port is 5 V/2 A (maximum). Purchase the power code/ AC adapter according to customer needs. Please do not connect any products with different power require- ment. Otherwise it may cause the damage to products or fire. Port Function MIC IN...
� Remote control Caution! To avoid probable faults, please read the following instructions and use the remote controller properly: • Do not drop or beat the remote controller. • Do not spill water or other liquid on the remote controller. •...
� Range of Remote control Use the remote control within a range of about 5 meters in front of the remote control receiver of this product and about 30 degrees on both sides. about 3 meters within a 30 degrees angle about 5 meters i3TOUCH PX Series - Manual...
� Installation Precautions Weight Loading • When using a mobile stand, ensure that the weight of the product is less than the loading capacity of the mobile stand. • When using the wall-mount bracket, ensure that the wall can support the weight of the product. We recommend that the wall surface be reinforced and have a loading capacity 4 times of the weight of the product.
Ventilation Ensure adequate ventilation and/or an air conditioned environment. We recommend keeping certain dis- tances from the side of the product to the wall or panels. Ventilation requirements are shown in following figure: * Refer to CAS 132-2006 standard � Installing the Built-in OPS Computer (Optional) Caution: The built-in computer does not support hot plugging.
Page 15
Step 1 Unscrew the screws by hand to remove the built-in computer shielding cover. Note: This step is optional and applies to models with shielding cover. Step 2 Push the built-in computer into the port at the rear of the machine from right to left. Step 3 Secure the built-in computer to the machine by using the screws.
Turning On/Off � Power On Step 1 Use AC power (100V~240V, 50Hz/60Hz) as the machine power source. Make sure the power plug fully inserted and that the ground wire of the outlet is properly connected. Step 2 Turn on the rocker switch (on the rear side of the machine, next to the power socket) after a power source has been connected.
� Power Off Step 1 Press the Power button on the remote control or long press the Power button to turn the machine power off. The indicator light turns red. Step 2 Step 2 If you want to completely turn off the machine, turn off the rocker switch on the rear of the machine (next to the power socket) and unplug the power cord.
Home Interface All our i3TOUCH devices are available with a BIZ or EDU Studio, bringing ease of use and simplicity to your desired workspace. You can choose which studio you want to use at first boot or through the settings menu. BIZ STUDIO EDU STUDIO The BIZ studio equips the display with a...
Start presenting� Content from other devices can be streamed to the display with a push-of-a-button. PRESENT Tap the present button. 2. Choose your platform of choice. 3. Follow the setup guide on screen. Hamburger menu� Use your favourite applications during meetings. Press the hamburger icon on the left or right side of the display to open the menu.
� Video input source The following options are visible when a video signal is connected. Clicking the video input button will make the menu appear with a number of options: Switch to the Android video source 2. Switch to the USB-C video input source 3.
Settings When opening the settings menu, you get an overview of all the settings you can adjust. � Network & Internet Settings Make a connection to your network and internet via Wi-Fi or Ethernet cable. i3TOUCH PX Series - Manual...
� System Firmware Update After connecting to the internet, verify that your display is running the latest firmware. In the settings application, press System Management, and About Device. Press the System Update button to validate your firmware version online (OTA). If a newer system version is available, this button will provide instructions to update your device.
� Audio Settings Adjust the audio settings in Device Settings and pre-define the audio environments. � System Management Startup and Shutdown Options 1. Define the active video channel after startup: 2. Define when the OPS Built-in computer should startup (if installed): A.
Whiteboard � Initial calibration Upon first start-up of the whiteboarding application, you will be asked to calibrate the four-finger erase gesture. Follow the instructions on screen to calibrate and activate this quick-erase gesture. � Floating tools menu Clicking on the floating tools menu will activate it and show 6 options. Close i3NOTES, this will Pen, normal writing also delete all pages...
Page 25
Marker, Pen & Eraser By selecting one of the canvas tools (marker, pen or eraser) it will open a second level of options. Each tool has its own options, so changing width or color on one tool will not change it for another. The slider is used to select the tool line thickness, the number at the top indicates the selected thickness ranging from 1 to 10.
Page 26
You can email the content of the whiteboard to yourself and/or others using one of the 3 available mail options. Use i3NOTES This option will use the i3-Technologies mail service. Enter the email address to whom you want to send the PDF to. You can enter multiple email addressess separated by a space (" "). Use Microsoft Exchange This option uses your Outlook account to send the mail.
Page 27
Required: your network firewall will need to allow peer-to-peer connections. Use cloud The cloud option will export the PDF to the i3-Technologies cloud server and make it publicly available to download for everyone that scans the QR code. After 2 hours the PDF will automatically be removed from our server.
Page 28
Delete The delete option will remove all contents of the current open page without deleting the page from your tab bar. After pressing OK your notes will be permanently removed. Whiteboard bar The tab bar is used to switch between different pages. Each page is numbered by an incremental id that defines the export order.
Annotating The annotate interface is very similar to the whiteboard interface. This consists of 2 main parts: 1. Floating Tools Menu 2. Annotation Canvas � Floating tools menu Clicking on the floating tools menu will activate it and show 6 options. Close i3OVERLAY, this Pen, normal writing will also delete all notes...
Page 30
Marker, Pen & Eraser By selecting one of the canvas tools (marker, pen or eraser) it will open a second level of options. Each tool has its own options, so changing thickness or colour of one tool will not change it for another. The slider is used for selecting the tool writing thickness, the number at the top indicates the selected width ranging from 1-10.
Browsing For browsing the web, the i3SIXTY provides the Google Chrome application. Usage instructions for the Google Chrome browser can be found at https://support.google.com/chrome. Present Meeting attendees often bring their own devices to the meeting room. Laptops, smartphones, tablets, etc. The i3TOUCH EX provides multiple tools for streaming to and from other devices.
Page 32
i3ALLSYNC Menu and Settings When opening the present feature, this is the interface you will see. The i3ALLSYNC application offers some settings and tools in the floating circular menu. Stop video stream Press this button to stop the shared content from all connections. Start annotating Press this button to start the annotating function of the i3TOUCH EX.
Page 33
NOTE: Touch functionality only works via the i3ALLSYNC Transmitting clients on Windows and MacOS. Use the i3ALLSYNC HDMI transmitter (optional accessory) i3-Technologies also offers the i3ALLSYNC HDMI Transmitter (purchased separately) for meeting attendees (guests) that can’t or won’t install the client software. Once the i3ALLSYNC HDMI Transmitter is paired only once with the display, you only need to plug in the HDMI and USB cable and press the button to immediately share the HDMI content on-screen.
Quick Troubleshooting Device fails to work normally Remote control Check whether there are other objects between remote control and equipment failure control receiving window, thus leading to failure of remote control. Check whether the battery electrode in the remote control is correct. Check whether the batteries of the remote-control needs to be replaced.
Audio problems Image but no sound Check whether mute button is pressed for mute. Press VOL + / - to adjust volume. Check whether audio line is connected correctly. Only one speaker Adjust sound balance in menu. has sound Check whether computer sound control panel only sets up one sound channel. Check whether audio line is connected correctly.
