EZ Way SMART STAND Quick Reference Manual

EZ Way, Inc.

Product Overview

NOTE: The footplate can be removed to ambulate. If using the Smart Stand for ambulation, the rear wheels
must be locked when raising or lowering the person. Connect the harness using the long loops.
WARNING: Do not remove the shin pad when ambulating. Removing could result in injury to the user. When refit-
ting, ensure the footplate is reinserted properly.
1. Fit the the harness to the resident, ensuring correct
size is used. Ensure the safety strap is buckled and
fastened securely around the person's torso and the
person's arms are outside the harness.
2. Position the Smart Stand in front of the person, open
the chassis legs if necessary, have person place their
feet on the footplate with their knees touching the shin
pad. Do not lock rear wheels when using the footplate.
3. Lower the stand arms to lowest position to aid
in hooking up the harness, and adjust shinpad if
necessary.
4. Attach the harness loops to the stand arm "pigtail"
using the shortest loops when possible.
This quick Reference guide has been created to assist healthcare professionals
and other users with only the functional aspects of the system. The guide
does not replace the general safety warnings, cautions and recommendations
provided in the product instructions for use the EZ Way Smart Stand.
REFER TO THE PRODUCT INSTRUCTIONS FOR USE BEFORE
USING THIS PRODUCT.
QUICK REFERENCE GUIDE
SMART STAND
Attach harness loops to "pigtials".
Use the hand control to operate.
Only for emergency, use the
emergency lowering handle to
lower the person.
5. Using the hand control, raise the person to a standing
position while tightening the safety strap around the
torso while they are raised.
6. Close-up legs and transfer person to desired location.
7. Position the person in front of chair, bed or toilet and
lower to a sitting position while standing beside the
person.
8. Unhook harness loops from the "pigtails" and move
the unit away from the person making sure they lift
their feet of footplate.
9. Unbuckle the safety strap and remove the harness
from around the resident.
