Viotech 3200+ BIOS Manual
BIOS Setup ................................................................................................ 1
1 Main Menu ............................................................................................. 3
2 Advanced Menu...................................................................................... 6
3 PCIPnP Menu....................................................................................... 15
4 Boot Menu............................................................................................. 18
5 Chipset Menu ....................................................................................... 20
6 Performance Menu .............................................................................. 24
7 Exit Menu ............................................................................................. 28
i
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Biostar Viotech 3200+
Summary of Contents for Biostar Viotech 3200+
- Page 1 Viotech 3200+ BIOS Manual BIOS Setup ....................1 1 Main Menu ..................... 3 2 Advanced Menu..................6 3 PCIPnP Menu..................15 4 Boot Menu..................... 18 5 Chipset Menu ..................20 6 Performance Menu ................24 7 Exit Menu ..................... 28...
-
Page 2: Bios Setup
Viotech 3200+ BIOS Manual BIOS Setup Introduction The purpose of this manual is to describe the settings in the AMI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM. The power of CMOS RAM is supplied by a battery so that it retains the Setup information when the power is turned off. -
Page 3: Pci Bus Support
Viotech 3200+ BIOS Manual PCI Bus Support This AMI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component Interconnect) local bus specification. DRAM Support DDR3 SDRAM (Double Data Rate III Synchronous DRAM) is supported. Supported CPUs This AMI BIOS supports the NanoBGA2 CPU. Using Setup When starting up the computer, press <Del>... -
Page 4: System Memory
Viotech 3200+ BIOS Manual 1 Main Menu Once you enter AMI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system information. BIOS SETUP UTILITY PCIPnP Boot Main Advanced Chipset Performance Exit System Overview Use [ENTER], [TAB] or [SHIFT-TAB] to... -
Page 5: Sata Configuration
Viotech 3200+ BIOS Manual SATA Configuration The BIOS will automatically detect the presence of SATA devices. There is a sub-menu for each SATA device. Select a device and press <Enter> to enter the sub-menu of detailed options. BIOS SETUP UTILITY Main SATA Configuration While entering setup,... - Page 6 Viotech 3200+ BIOS Manual Type Select the type of the IDE/SATA drive. Options: Auto (Default) / CDROM / ARMD / Not Installed LBA/Large Mode Enable or disable the LBA mode. Options: Auto (Default) / Disabled Block (Multi-Sector Transfer) Enable or disable multi-sector transfer. Options: Auto (Default) / Disabled PIO Mode...
-
Page 7: Advanced Menu
Viotech 3200+ BIOS Manual 2 Advanced Menu The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power Management, and other system devices. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. -
Page 8: Super Io Configuration
Viotech 3200+ BIOS Manual VIA Processor Power Management Enabled: Enable CPU Power Management function; Disabled: Disable CPU Power Management function. Options: Enabled (Default) / Disabled SuperIO Configuration BIOS SETUP UTILITY Advanced Configure ITE8728 Super IO Chipset Allows BIOS to Select Serial Port1 Base Serial Port1 Address [3F8/IRQ4]... -
Page 9: Parallel Port Mode
Viotech 3200+ BIOS Manual Parallel Port Mode This item allows you to determine how the parallel port should function. Options: Normal (Default) Using Parallel port as Standard Printer Port. Using Parallel Port as Enhanced Parallel Port. Using Parallel port as Extended Capabilities Port. ECP+EPP Using Parallel port as ECP &... - Page 10 Viotech 3200+ BIOS Manual CPU Smart Fan This item allows you to control the CPU Smart Fan function. Options: Disabled (Default) / Auto / 3Pin / 4Pin Smart Fan Calibration Choose this item and then the BIOS will auto test and detect the CPU fan functions and show CPU fan speed.
-
Page 11: Hardware Health Configuration
Viotech 3200+ BIOS Manual Hardware Health Configuration This item shows the system temperature, fan speed, and voltage information. BIOS SETUP UTILITY Advanced Hardware Health Configuration Enables Hardware Health Monitoring H/W Health Function [Enabled] Device. CPU Temperature SYS Temperature CPU Fan System Fan CPU Voltage DDR Voltage... - Page 12 Viotech 3200+ BIOS Manual EuP Control When EuP is enabled, the system will meet EuP requirement. Options: Disabled (Default) / Enabled Suspend mode The item allows you to select the suspend type under the ACPI operating system. Options: S3 (STR) (Default) Suspend to RAM S1 (POS) Power on Suspend...
- Page 13 Viotech 3200+ BIOS Manual Resume by USB (S3/S4) This item allows you to enable or disable the USB resume from S3/S4 function. Options: Enabled (Default) / Disabled Resume by PS2 KB This item allows you to enable or disable the PS2 KB resume. Options: Disabled (Default) / Enabled Resume by PS2 MS...
-
Page 14: Usb Configuration
Viotech 3200+ BIOS Manual USB Configuration This item shows the USB controller and using USB device information. BIOS SETUP UTILITY Advanced USB Configuration USB1.1 Function 0 port Module Version - 2.24.5-13.4 USB Devices Enabled: OnChip UHCI1 Device [Enabled] OnChip UHCI2 Device [Enabled] OnChip UHCI3 Device [Enabled]... - Page 15 Viotech 3200+ BIOS Manual BIOS EHCI Hand-Off This item allows you to enable support for operating systems without an EHCI hand-off feature. Options: Enabled (Default) / Disabled Legacy USB1.1 HC Support This item allows you to enable to support USB1.1 HC. Options: Enabled (Default) / Disabled...
-
Page 16: Pcipnp Menu
Viotech 3200+ BIOS Manual 3 PCIPnP Menu This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. -
Page 17: Pci Latency Timer
Viotech 3200+ BIOS Manual PCI Latency Timer This item controls how long a PCI device can hold the PCI bus before another takes over. The longer the latency, the longer the PCI device can retain control of the bus before handing it over to another PCI device. Options: 64 (Default) / 0-255 Allocate IRQ to PCI VGA... -
Page 18: Reserved Memory Size
Viotech 3200+ BIOS Manual IRQ3/4/5/7/9/10/11/14/15 These items will allow you to assign each system interrupt a type, depending on the type of device using the interrupt. The option “Available” means the IRQ is going to assign automatically. Options: Available (Default) / Reserved DMA Channel 0/1/3/5/6/7 These items will allow you to assign each DMA channel a type, depending on the type of device using the channel. -
Page 19: Boot Device Priority
Viotech 3200+ BIOS Manual 4 Boot Menu This menu allows you to setup the system boot options. (The screenshot below is without any Hard Disk / CDROM / USB Drive / Bootable Add-in Cards etc.) BIOS SETUP UTILITY PCIPnP Boot Main Advanced Chipset... -
Page 20: Cd/Dvd Drives
Viotech 3200+ BIOS Manual CD/DVD Drives The BIOS will attempt to arrange the CD/DVD drive boot sequence automatically. You can also change the booting sequence. The number of device items that appears on the screen depends on the number of devices installed in the system. Options: Pri. -
Page 21: Chipset Menu
Viotech 3200+ BIOS Manual 5 Chipset Menu This submenu allows you to configure the specific features of the chipset installed on your system. This chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. BIOS SETUP UTILITY PCIPnP Boot... -
Page 22: Agp & P2P Bridge Configuration
Viotech 3200+ BIOS Manual AGP & P2P Bridge Configuration BIOS SETUP UTILITY Chipset AGP & P2P Bridge Configuration Options Primary Graphics Adapter [PCI -> PCIE -> UMA] PCI -> PCIE -> UMA UMA -> PCIE -> PCI PCIE -> UMA -> PCI UDMI will be initial after UMA Select Screen... -
Page 23: Southbridge Via Vx900 Configuration
Viotech 3200+ BIOS Manual CPU Direct Access Frame Buffer This item allows you to enable/diable CPU Direct Access Frame Buffer. Options: Enabled (Default) / Disabled SouthBridge VIA VX900 Configuration BIOS SETUP UTILITY Chipset SouthBridge VIA VX900 Configuration SATA Gen2 Support * SATA Gen2 Support [Enabled] * OnChip HD Audio Device... -
Page 24: Onboard Peripherals Configuration
Viotech 3200+ BIOS Manual Onboard Peripherals Configuration BIOS SETUP UTILITY Chipset MAC ID Information : Options Realtek PCIE NIC [Enabled] LAN Option ROM [Disabled] Disabled Enabled Select Screen Select Item Change Option General Help Save and Exit Exit vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc. MAC ID Information This area shows the MAC ID. -
Page 25: Performance Menu
Viotech 3200+ BIOS Manual 6 Performance Menu This submenu allows you to change voltage and clock of various devices. (However, we suggest you use the default setting. Changing the voltage and clock improperly may damage the device.) Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. -
Page 26: Clock Control
Viotech 3200+ BIOS Manual Clock Control BIOS SETUP UTILITY Performance Clock Control Options Spread Spectrum [Disabled] Disabled Enabled Select Screen Select Item Change Option General Help Save and Exit Exit vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc. Spread Spectrum This item allows you to control Spread Spectrum function. Options: Disabled (Default) / Enabled DRAM Clock &... - Page 27 Viotech 3200+ BIOS Manual DRAM Clock This item allows you to set the Memory Clock. Options: Auto (Default) / DDR3-800 / DDR3-1066 DRAM Timing This item allows you to choose to manually or automatically regulate the DRAM Timing. Options: Auto (Default) / Manual CAS Latency (CL) Options: 7T/8T (Default) / 3T/4T ~ NA/11T...
-
Page 28: Write Recovery Time (Twr)
Viotech 3200+ BIOS Manual Write Recovery Time (Twr) Options: 6T/8T (Default) / 2T/4T ~ 9T/11T DDR3 CAS Write Latency Options: 11T (Default) / 4T ~ 10T Tfaw – 4*Trrd Options: 15T (Default) / 0T ~ 14T... -
Page 29: Save Changes And Exit
Viotech 3200+ BIOS Manual 7 Exit Menu This menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Chipset Performance Exit Exit Options Exit system setup after saving the Save Changes and Exit changes. -
Page 30: Change Supervisor Password
Viotech 3200+ BIOS Manual Security This sub-menu allows you to provide/revise supervisor and user password. BIOS SETUP UTILITY Exit Security Settings Install or Change the password. Supervisor Password :Not Installed User Password :Not Installed Change Supervisor Password Change User Password Boot Sector Virus Protection [Disabled] Select Screen Select Item...
