Audibax Joliet 100FC Zoom User Manual

Joliet 100FC Zoom
Fixture Cleaning
Due to fog residue, smoke, and dust cleaning the internal and external optical lenses and
mirror should be carried out periodically to optimize light output. Cleaning frequency
depends on the environment in which the fixture operates (I.e. smoke, fog residue, dust,
dew). In heavy club use we recommend cleaning on a monthly basis. Periodic cleaning will
ensure longevity, and crisp output.
To clean the fixture:
1. Disconnect the fixture from power and allow it to cool for at least 10 minutes.
2. Vacuum or gently blow away dust and loose particles from the outside of the fixture with
low-pressure compressed air.
3. Clean the surfaces by wiping gently with a soft, clean lint-free cloth moistened with a
weak detergent solution. Do not rub glass surfaces hard: lift particles off with a soft repeated
press. Dry with a soft, clean, lint-free cloth or low-pressure compressed air. Remove stuck
particles with an unscented tissue or cotton swab moistened with glass cleaner or distilled
water.
4. Check that the fixture is dry before reapplying power.
Fuse Replacement
This fuse is located in a fuseholder next to the MAINS OUT socket on the connections panel.
To replace a fuse:
1. Disconnect the fixture from power and allow it to cool for at least 10 minutes.
2. Unscrew the cap of the fuseholder and remove the fuse. Replace with a fuse of the same
size and rating only.
3. Reinstall the fuseholder cap before reapplying power.
Troubleshooting
Listed below are a few common problems that you may encounter, with solutions.
The fixture does not work, no light
• Check the connection of power and main fuse. Be sure the external fuse has not blown.
• Measure the mains voltage on the main connector.
Technical specifications
Model
Power supply: AC100-240V, 50/60Hz
Light source: 100W LED
Color mixing: RGBW color mixing
Zoom scale: 25° - 65° motorized
Power connection: PowerCON in&out
Maximum power linking: 8 units
Signal connection: 3-pin XLR in&out(5-pin optional)
DMX channels: ARC.1(3CH), AR1.D(4CH), ARC.2(4CH), AR2.D(5CH), AR2.S(6CH),
HSV(3CH), STAG(12CH)
Control mode: RDM, DMX, Master-slave
Housing: Colour black, Aluminum
Size(barn door excluded): 331 x 210 x 345.7mm(13 x 8.3 x 13.6in)
Package(carton):
448 x 338 x 400mm(17.6 x 13.3 x 15.7in)
N.W.: 6.6 kg(14.5 lb)
:
Environment
IP20
Please note: All information is subject to change without prior notice. 13.11.2018
11
Joilet 100FC Zoom
Joliet 100FC
Zoom
Please read the manual before using the product
USER´S
MANUAL
