Compatible with PNI CB radios:
•
PNI Escort HP 8000L
•
PNI Escort HP 8001L
•
PNI Escort HP 8024
•
PNI Escort HP 9001 PRO
•
PNI Escort HP 9500
•
PNI Escort HP 8900
Compatible with other 6-pin CB radios, by pins configuration.
MAIN FEATURES:
•
Number of pins: 6
•
Channel change buttons: Yes
•
ASQ on / off button: Yes
•
Dimensions: 60 x 30 x 110 mm
PINS CONFIGURATION
PIN1 - GND
PIN4 - ASQ
PIN2 - MIC
PIN5 - UP
6-pin microphone for PNI Escort HP 8000L CB radio (code PNI-MK9500)
PIN3 - PTT
PIN6 - DOWN
PRODUCT DESCRIPTION:
In addition to the PTT (Push to Talk) button used to transmit, the microphone is equipped with Up
and Down buttons to change the channel and ASQ button to activate / deactivate the automatic
squelch.
6-PIN MICROPHONE FOR CB RADIOS
UP
ASQ
DOWN
PTT
MIC
EN
1. GND (braid)
2. MIC (white)
3. TX (yellow)
4. ASQ (red)
5. UP (green)
6. DOWN (black)
