Toshiba Satellite 1715XCDS Specifications

TOSHIBA
Satellite ® 1715XCDS
Product Highlights:
Performance
Mobile Intel® Celeron™ processor,
600MHz
64MB SDRAM, expandable to 192MB
No-Hassle All-in-one design!
6.0BB hard disk drive, 24X max. speed
CD-ROM and diskette drive
Blasting Multimedia!
13.0" diagonal Color bright dual-scan
display
4MB SGRAM Video Memory (external)
Sensational 3D graphics controller and
Toshiba sound system
Get On-Line!
V.90 /K56Flex modem
VirtualTech™ online services
FreedomWare. Special discounts that
save you time and money!
Toshiba Great Software Offer!
Lotus SmartSuite Millennium Edition plus
a choose of two additional titles
Product Specification
Processor
Mobile Intel® Celeron™ processor 600MHz
Integrated co-processor
128KB Level 2 cache integrated on die
Data/Address Bus Width: 64-bit/32-bit
100MHz Front side bus
Memory
64MB standard, expandable to 192MB
128Mbit PC 100 SDRAM, 3.3V, 8ns
Internal memory expansion slot
BIOS
ACPI V1.0b; PnP V4.3; VESA V2.0; DPMS;
DDC2.0; PCI BIOS
System Architecture
PCI Bus V2.1
Hard Disk
6.0 billion bytes Enhanced IDE, 2.5"
Service removable
9.5 mm height or 8.45mm height
13ms average access time
Supports PIO Mode4 or Ultra DMA33
Diskette Drive
Built-in 3.5", 1.44MB
CD-ROM
Built-in 24X max. speed CD-ROM
120-95ms average access time
3,600KB/s maximum data transfer rate
Compatibility: CD-ROM, CD-R (read only),
CD-RW (read only)
Video
ATI Mobility-C
64-bit Graphics Accelerator
2x AGP bus
BitBLT hardware
4MB SGRAM Video Memory (external)
Display
13.0" diagonal Color Bright Dual Scan
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 2000 TAIS satellite_1715XCDS.doc Rev. 3 08/31/00
Internal display supports up to 16M colors at
800 x 600
External Color Support
640 x 480; 60/70/72/75/85Hz Non-Interlaced
@ 16M
800 x 600; 60/70/72/75/85Hz Non-Interlaced
@ 16M
1024 x 768; 60/70/72/75/85Hz Non-Interlaced
@ 16M
1280 x 1024; 60Hz Non-Interlaced @ 16M
Audio
Crystal 4281 Controller
16-bit stereo, Windows Sound System
Ver.2.0, Sound Blaster® Pro compatible (in
DOS box only)
3D Sound Support with HRTF 3D positional
audio
Direct 3D Sound
Hardware acceleration for DirectSound
Full Duplex support
Sound volume controlled by dial
Microphone and Headphone ports
Two stereo speakers
Communications
Integrated V.90/56K flex modem
Data and fax support
Built-in RJ-11
Keyboard
Full sized 86 keys with 12 function keys
3mm travel
Dedicated Windows® keys
Integrated AccuPoint® II pointing device with
scroll buttons
Expansion
Two PC Card slots support two Type II or one
Type III PC Cards; 32-bit CardBus ready
RJ-11 telephone port
SVGA video port
PS/2™ mouse/keyboard port (Y-connector
supported)
Two Universal Serial Bus port
ECP parallel port
Headphone-out jack, Microphone port
User Control Keys
Control buttons for CD playback functionality
Play / Pause
Stop / Eject
Next
Previous
Internet Button
Dimensions (LxWxH)
12.6" x 10.9 " x 1.5"
Weight
6.9 lbs
Power Supply
45W Autosensing External AC Adapter
90-264V input voltage
47-63 Hz frequency
4.3 (W) x 2.4 (H) x 1.2 (D), 0.7 lbs
Battery
Rechargeable, removable NiMH battery (9.6V
x 4500 mAh)
2.0+ hours battery life
5.5 (W) x 4.3 (H) x 0.9 (D), 1.2 lbs
Battery life may vary depending on
applications, power management settings
and features utilized. Recharge time varies
depending on usage.
System Management
Toshiba Configuration Builder-customized
software image tool
Year 2000 Compliance: NSTL Hardware
Tested
ACPI V1.0b support
Security
Power-on password
Cable lock slot
Memory, HDD and Modem (by screw only)
Operating System
Microsoft® Windows Millennium Edition
Additional Software
Lotus® SmartSuite Millennium Edition
Intuit Quicken Basic 2000
Norton AntiVirus™
AT&T WorldNet Services
Customizable Toshiba/My Yahoo! Start Page
Microsoft Internet Explorer
Toshiba Custom Utilities
Satellite Series Online Documentation
online services
VirtualTech™
Toshiba Great Software Offer:
Satellite notebook, you will receive your
choice of two software titles. The software
selection includes titles from the following:
Lotus® SmartSuite Millennium Edition,
productivity, education/reference, creativity
and entertainment titles.
Warranty
1 year parts, labor and battery.
warranty upgrades available.
Environmental Specifications
Temperature:
O O O
Operating: 5 to 35 C (41 to 95
O O
Non-operating: -20 to 65 C (-4
F)
Thermal gradient:
O
Operating: 15 C per hour maximum
O
Non-operating: 20 per hour maximum
Relative Humidity:
Operating: 20% to 80% non-condensing
Non-operating: 10% to 95% non-condensing
Altitude (relative to sea level):
Operating: -60m to 3,000m (-197' to 9,842')
Non-operating: -60m to 10,000m (-197' to
32,808')
Shock:
Operating: 10G (11ms)
Non-operating: 60G (66ms)
Vibration:
Operating: 0.5G
Non-operating: 1G
Satellite 1715XCDS Part Number and UPC
PS171U-11K93H Satellite 1715XCDS
UPC: 032017068902
With each
SelectServ™
O
F)
O O
to 149
